Flotide Pool Filtration Kit FSP 350-500 User Manual

1. Introduction

This user manual provides comprehensive instructions for the installation, operation, and maintenance of your Flotide Pool Filtration Kit FSP 350-500. Please read this manual thoroughly before operating the unit to ensure safe and efficient performance. Keep this manual for future reference.

2. Product Overview

The Flotide Pool Filtration Kit FSP 350-500 is a complete, ready-to-connect filter system designed for pools up to approximately 20,000 liters. It features a blow-molded polyethylene filter tank with a top-mounted 4-way valve, a pressure gauge, and a centrifugal pump with an integrated pre-filter. All components are mounted on a sturdy base plate for easy installation.

Key Features:

• Compact and robust design with a mounting plate.
• Operating pressure up to 2 bar and max. +50 °C.
• Suitable for most private pools or jacuzzis.
• Transparent cover for clear visibility of the pre-filter.
• Integrated pressure gauge for dirt level monitoring.
• Equipped with a residual current device (RCD).

Figure 2.1: Overview of the Flotide Pool Filtration Kit FSP 350-500.

Figure 2.2: Flotide Pool Filtration Kit showing key dimensions and material: PE50 mm/1 1/2" connection, Metric connection type, 2 bar working pressure, PE material.

3. Setup and Installation

Installation of the Flotide Pool Filtration Kit is designed to be simple and quick, facilitated by the included adhesive sleeves and the pre-mounted components on the base plate. Follow the diagrams carefully for proper assembly and connection.

Assembly Steps:

1. Place the filter tank and pump assembly on a stable, level surface near your pool.
2. Connect the pool's skimmer line to the pump inlet.
3. Connect the pump outlet to the filter tank inlet.
4. Connect the filter tank's return line to the pool's return jet.
5. Ensure all connections are secure and leak-free using the provided adhesive sleeves.
6. Fill the filter tank with the appropriate filter media (e.g., filter sand, not included).
7. Connect the power supply, ensuring the RCD is properly installed and functioning.

Figure 3.1: Exploded view of the Flotide Pool Filtration Kit, showing various spare parts and their positions for assembly. This diagram is crucial for identifying components during setup and maintenance.

4. Operating Instructions

The 4-way valve on top of the filter tank controls the filtration process. Familiarize yourself with its positions for different operations.

Valve Positions:

• FILTER: Normal filtration mode. Water flows through the filter media and returns to the pool.
• BACKWASH: Cleans the filter media by reversing water flow. Used when the pressure gauge indicates high pressure.
• RINSE: Used after backwashing to flush dirty water from the valve and lines before returning to FILTER mode.
• WASTE/DRAIN: Bypasses the filter and sends water directly to waste, useful for vacuuming heavy debris or lowering pool water level.
• RECIRCULATE: Circulates water without filtering, useful for chemical distribution.
• CLOSED: Shuts off flow to the filter.

Always turn off the pump before changing the valve position to prevent damage.

5. Maintenance

Regular maintenance ensures the longevity and efficiency of your filtration system. The design allows for easy access to components for cleaning and inspection.

Routine Maintenance:

• Monitor Pressure Gauge: The integrated pressure gauge indicates when the filter media needs cleaning. When the pressure rises significantly above its clean operating pressure, it's time to backwash.
• Backwashing:
  1. Turn off the pump.
  2. Set the 4-way valve to "BACKWASH".
  3. Turn on the pump and run until the water in the sight glass (if present) runs clear (typically 2-3 minutes).
  4. Turn off the pump.
  5. Set the 4-way valve to "RINSE".
  6. Turn on the pump and run for 30-60 seconds.
  7. Turn off the pump.
  8. Set the 4-way valve to "FILTER".
  9. Turn on the pump to resume normal operation.
• Pre-filter Cleaning: The transparent cover on the pre-filter allows you to visually inspect its condition. If debris accumulates, turn off the pump, open the pre-filter lid (using the clamping ring closure), remove and clean the basket, then reassemble.
• Winterization: Before freezing temperatures, drain all water from the filter tank, pump, and plumbing lines. Store the pump in a dry, frost-free location.

Figure 5.1: Detailed exploded view of the filter and pump components, including the transparent lid (Item 1), O-rings (Item 2, 4), basket (Item 3), and various pump parts. This diagram is useful for identifying parts during cleaning and replacement.

6. Troubleshooting

This section provides solutions to common issues you might encounter with your Flotide Pool Filtration Kit.

If you encounter issues not listed here or if solutions do not resolve the problem, please contact customer support.

7. Specifications

Detailed technical specifications for the Flotide Pool Filtration Kit FSP 350-500.

Figure 7.1: Graph illustrating the technical performance data (Psi/Bar vs. Q(m³/h) / Q(LPM)) for various Flotide FSP series filters, including FSP500, FSP450, FSP400, and FSP350.

8. Warranty and Support

For warranty information, please refer to the documentation provided at the time of purchase or contact your retailer. For technical support or spare parts inquiries, please contact the manufacturer or authorized service center.

Manufacturer: Flotide

ASIN: B0D14SM14Z
