HANLIM HL-108-A Portable CD Player User Manual

1. Introduction

Thank you for purchasing the HANLIM HL-108-A Portable CD Player. This device offers a versatile audio experience with its multi-function capabilities, including CD playback, Bluetooth connectivity, FM radio, MP3 playback via USB, AUX input, and microphone support. Its compact design and built-in rechargeable battery make it ideal for both indoor and outdoor use. Please read this manual carefully before operating the device to ensure proper use and to maximize its performance.

2. Package Contents

Before you begin, please check the package contents to ensure all items are present:

• HANLIM HL-108-A Portable CD Player
• Power Cable (1.2m)
• Remote Control
• User Manual

Figure 2.1: Package Contents. This image displays the portable CD player, its remote control, the power cable, and the user manual, illustrating everything included in the box.

3. Product Overview

Familiarize yourself with the various parts and controls of your HANLIM HL-108-A CD player.

Figure 3.1: Front View of the CD Player. This image highlights the main display, the central control knob, and various function buttons on the front panel of the device.

3.1. Controls and Ports

• Display Screen: Shows current mode, track information, FM frequency, etc.
• Mode Button: Switches between CD, Bluetooth, FM, USB, and AUX modes.
• Standby Button: Powers the unit on/off.
• Play/Pause/Scan Button (►/SCAN): Plays or pauses playback; initiates FM scan.
• Previous/Channel Down (◀◀/CH-): Skips to previous track/station.
• Next/Channel Up (►►/CH+): Skips to next track/station.
• Volume Knob: Adjusts the audio volume.
• USB Port: For MP3/WMA playback from USB drives (up to 32GB).
• Headphone Jack (3.5mm): For private listening.
• AUX Input (3.5mm): Connect external audio devices.
• Microphone Jack: Connect an external microphone for singing (microphone not included).
• Power Input: Connect the AC power cable.

Figure 3.2: Rear Connections. This image illustrates the microphone input jack and the 3.5mm AUX input jack located on the back of the CD player.

4. Setup

4.1. Powering the Device

The HANLIM HL-108-A can be powered by the included AC power cable or its built-in rechargeable battery.

• AC Power: Connect the power cable to the power input port on the back of the unit and plug the other end into a standard wall outlet.
• Battery Power: The unit has a built-in 2000mAh rechargeable battery. Fully charge the battery before first use. A full charge provides up to 5 hours of playback at maximum volume.

Figure 4.1: Built-in Rechargeable Battery. This image illustrates the portability of the device and highlights its 5-hour battery life, suitable for outdoor use.

4.2. Initial Power On

Press the STANDBY button to turn on the device. The display will light up.

5. Operating Instructions

This section details how to use the various functions of your CD player.

Figure 5.1: Multi-functional Portable CD Player. This image emphasizes the device's 20W output and its diverse capabilities, including CD, Bluetooth, FM radio, USB, and AUX input, along with practical features like repeat modes, resume playback, and sound equalizer options (Pop, Jazz, Rock, Classic, Flat).

5.1. CD Playback

1. Open the CD compartment cover on top of the unit.
2. Place a CD (CD/CD-R/CD-RW/MP3 format) onto the spindle with the label side facing up.
3. Close the CD compartment cover.
4. Press the MODE button until "CD" appears on the display.
5. The CD will begin playing automatically. If not, press the ►/SCAN button.
6. Use ◀◀/CH- and ►►/CH+ buttons to skip tracks.
7. Repeat Function: Press the Repeat button on the remote control to cycle through repeat modes (one song, all songs, random).
8. Resume Playback: The player will resume playback from where it was last stopped when the CD mode is re-selected.

5.2. Bluetooth Connectivity

1. Press the MODE button until "BT" or "Bluetooth" appears on the display. The device will enter pairing mode.
2. On your Bluetooth-enabled device (smartphone, tablet, computer), search for "HANLIM HL-108-A" in the Bluetooth settings.
3. Select the device to pair. Once connected, you will hear a confirmation sound.
4. You can now play audio from your connected device through the CD player.
5. Note: This device acts as a Bluetooth receiver; it does not support connecting to Bluetooth headphones.

Figure 5.2: Bluetooth Connection. This image demonstrates the ease of connecting a smartphone via Bluetooth, and also points out the USB port and headphone jack for versatile audio options.

5.3. FM Radio

1. Press the MODE button until "FM" appears on the display.
2. Press and hold the ►/SCAN button to automatically scan and store available FM stations (87.5 – 108 MHz). Up to 20 stations can be stored.
3. Use the ◀◀/CH- and ►►/CH+ buttons to navigate through the stored stations.

Figure 5.3: FM Radio Function. This image shows the device tuned to an FM frequency, illustrating its capability to receive radio broadcasts for news, stories, and music.

5.4. USB Playback

1. Insert a USB flash drive (up to 32GB, formatted as FAT32) containing MP3/WMA audio files into the USB port.
2. Press the MODE button until "USB" appears on the display.
3. The device will automatically detect and begin playing audio files from the USB drive.
4. Use ◀◀/CH- and ►►/CH+ buttons to skip tracks.

5.5. AUX Input

1. Connect one end of a 3.5mm audio cable (not included) to the AUX IN port on the back of the CD player.
2. Connect the other end of the audio cable to the headphone jack or audio output of your external device (e.g., smartphone, computer, MP3 player).
3. Press the MODE button until "AUX" appears on the display.
4. Play audio from your external device. The sound will be output through the CD player's speakers.

5.6. Microphone Input

1. Connect a microphone (not included) to the Microphone Jack on the back of the unit.
2. The microphone input will be active in any playback mode (CD, Bluetooth, FM, USB, AUX).
3. Adjust the microphone volume using the connected microphone's controls, if available, or the main volume knob on the CD player.

5.7. Headphone Output

1. Connect a pair of headphones (not included) to the 3.5mm Headphone Jack on the front of the unit.
2. Audio will automatically switch from the speakers to the headphones for private listening.

5.8. Sound Equalizer

The device offers 5 sound equalizer presets:

• Pop
• Jazz (for softer sounds)
• Rock (for more bass)
• Classic
• Flat (default)

Use the EQ button on the remote control to cycle through these sound modes.

6. Maintenance

Proper care and maintenance will ensure the longevity of your CD player.

• Cleaning: Use a soft, dry cloth to clean the exterior of the unit. Do not use abrasive cleaners or solvents. For the CD lens, use a specialized CD lens cleaner.
• Storage: When not in use for extended periods, store the device in a cool, dry place away from direct sunlight and extreme temperatures.
• Battery Care: To prolong battery life, avoid fully discharging the battery frequently. Recharge the battery regularly, even if the device is not in use.
• Handling: Avoid dropping the unit or subjecting it to strong impacts.

7. Troubleshooting

If you encounter any issues with your device, please refer to the following common problems and solutions:

8. Specifications

Detailed technical specifications for the HANLIM HL-108-A Portable CD Player.

9. Warranty and Support

HANLIM offers a one-year warranty for this product. For any questions, technical support, or warranty claims, please contact your retailer or the manufacturer directly. Please retain your proof of purchase for warranty service.

Manufacturer: HANLIM

Warranty Period: 1 Year
