1. Product Overview
This document provides essential information for the proper identification, use, and care of your EasyKeys replacement key for Armstrong E367 series locks. This key is specifically cut to match the E367 code, compatible with Armstrong Key Series E101 - E801, and is designed for cam lock types.
Image 1.1: The EasyKeys replacement key for Armstrong E367. This key is made of brass and is custom cut to the E367 specification.
2. Key Identification and Setup
Before using your replacement key, it is crucial to correctly identify the lock code of your existing lock. The EasyKeys replacement key is custom cut for the Armstrong E367 code. Incorrect code identification may result in the key not functioning properly.
2.1. How to Find Your Lock Code
Your lock code can typically be found in several locations. Refer to the image below for common places to locate your lock code:
Image 2.1: This diagram illustrates common locations where you can find your lock code. These include directly on an existing key (e.g., "FR322"), on the face of the lock cylinder itself (e.g., "FR322"), on a label positioned inside or behind the lock mechanism (e.g., "CODE: G38"), or on a label affixed to the cabinet or door near the lock (e.g., "HF321").
- On the Key: The code may be stamped directly onto your original key.
- On the Lock Face: The code might be engraved or printed on the visible part of the lock cylinder.
- On a Label Inside/Behind the Lock: For some locks, the code is on a sticker or label located on the lock mechanism itself, often requiring removal of a panel to access.
- On the Cabinet/Door Label: In some installations, the code is provided on a label near the lock on the furniture or door.
Important Notes:
- Always verify the manufacturer. Lock codes are manufacturer-specific. An E367 code from one manufacturer may not be the same as an E367 from another. This key is for Armstrong locks.
- Key cuts differ significantly between brands. Even if codes appear similar, the physical cut of the key varies by brand and manufacturer.
3. Operating Instructions
Once you have confirmed that your lock requires an Armstrong E367 key, using your replacement key is straightforward.
- Insert the Key: Gently insert the key into the lock's keyway. Do not force the key. If it does not slide in smoothly, ensure the key is oriented correctly and that there are no obstructions in the keyway.
- Turn the Key: Once fully inserted, turn the key clockwise or counter-clockwise (depending on the lock mechanism) to engage the locking or unlocking mechanism. The key should turn smoothly without excessive force.
- Remove the Key: After operating the lock, return the key to its original insertion position (usually vertical) before gently pulling it out.
Caution:
Never force the key to turn or insert. Excessive force can damage the key or the lock mechanism, leading to malfunction or breakage.
4. Maintenance
Proper maintenance ensures the longevity and smooth operation of your key and lock.
- Keep Clean: Periodically wipe the key with a soft, dry cloth to remove dirt or debris.
- Avoid Harsh Chemicals: Do not use abrasive cleaners or harsh chemicals on the key, as this can damage the brass material.
- Lubrication (for lock): If the lock mechanism becomes stiff, apply a small amount of graphite lubricant or a specialized lock lubricant into the keyway. Avoid oil-based lubricants as they can attract dust and grime.
- Storage: Store the key in a dry place, away from extreme temperatures or corrosive environments.
5. Troubleshooting
If you encounter issues with your replacement key, consider the following troubleshooting steps:
| Problem | Possible Cause | Solution |
|---|---|---|
| Key does not insert fully. | Incorrect key orientation, obstruction in keyway, or wrong key for lock. | Ensure key is oriented correctly. Check keyway for debris. Verify lock code matches E367 for Armstrong locks. |
| Key inserts but does not turn. | Wrong key for lock, worn lock mechanism, or internal obstruction. | Confirm lock code is E367 for Armstrong. Apply lock lubricant to the keyway. If problem persists, the lock mechanism may require professional service. |
| Key turns but lock does not operate. | Internal lock mechanism failure. | This indicates an issue with the lock itself, not the key. Consult a locksmith or the lock manufacturer. |
| Key feels stiff or gritty when turning. | Lack of lubrication in lock, dirt/debris in keyway. | Apply graphite lubricant to the keyway. Clean the key. |
6. Specifications
- Brand: EasyKeys
- Model Name: E367
- Compatible Manufacturer: Armstrong
- Compatible Key Series: E101 - E801
- Lock Type: Cam
- Material: Brass
- Special Features: Custom Cut Key, Durable
- Dimensions (L x W x H): Approximately 0.5 x 0.5 x 1 inches
- Item Weight: Approximately 4 ounces
- Included Components: 1 Key
- ASIN: B0CZLD4BG6
7. Warranty and Support
EasyKeys stands behind the quality of its products. For specific warranty information or if you require further assistance, please refer to the EasyKeys official website or contact their customer support directly.
When contacting support, please have your product details, including the model name (E367) and ASIN (B0CZLD4BG6), readily available.
