Anfilank Portable Electric Kettle

1. Introduction

Thank you for purchasing the Anfilank Portable Electric Kettle. This manual provides essential information for the safe and efficient operation of your new appliance. Please read it thoroughly before first use and keep it for future reference.

Image: Anfilank Portable Electric Kettle, showcasing its sleek design and digital display.

2. Product Features

• 6-Stage Temperature Control & 12-Hour Keep Warm: Equipped with a high-quality temperature sensor, allowing precise temperature adjustment to 45°C, 55°C, 70°C, 80°C, 90°C, and 100°C. The kettle also features a 12-hour long-term keep-warm function, ensuring your water is ready when you need it.


Image: Visual representation of the 6 temperature settings and their recommended uses for various beverages.

• Wide Voltage Compatibility (AC100-240V): Built-in voltage converter allows use in both Japan and overseas without needing an additional transformer, making it ideal for international travel.


Image: Diagram illustrating the kettle's compatibility with various international voltages across a world map.

• Double-Layer Construction & Burn Prevention: Features a double-layer design with a 304 stainless steel inner layer and a heat-resistant PP outer layer, preventing burns even when the water is boiling.


Image: Exploded view showing the inner stainless steel and outer plastic layers, highlighting the double-layer construction and safety features like touch buttons and non-slip base.

• Triple Safety Protection: Includes automatic power-off after boiling, overheat protection, and boil-dry prevention functions for safe operation.
• Compact & Portable Design: Easy to carry in bags or suitcases, making it convenient for travel. The detachable power cord allows for compact storage.


Image: The portable kettle being placed into a suitcase and held in a hand, demonstrating its compact size and portability.

• Rapid Boiling: With 300W power, it can boil 200ml of water in approximately 4.5 minutes and the full 380ml capacity in about 8 minutes.


Image: A graphic illustrating the rapid boiling times for different water volumes and temperatures.

3. Safety Precautions

To ensure safe operation and prevent damage, please observe the following:

• Do not heat liquids other than water in the kettle. Heating milk, coffee, or other beverages may cause damage or safety hazards.
• Ensure the power outlet voltage matches the kettle's specifications (AC100-240V).
• Always place the kettle on a stable, flat, and heat-resistant surface.
• Do not immerse the kettle base or power cord in water or other liquids.
• Keep the kettle out of reach of children and pets.
• Unplug the kettle from the power outlet when not in use, before cleaning, or if any malfunction occurs.
• Exercise caution when pouring hot water to avoid scalding. The exterior may be warm during operation, but the double-layer construction minimizes direct heat transfer.
• Do not operate the kettle without water (boil-dry protection is in place, but it's best to avoid this).

4. Setup

1. Unpack: Carefully remove the kettle and all accessories from the packaging. Retain the packaging for storage or future transport.
2. Initial Cleaning: Before first use, fill the kettle with water up to the MAX line. Add approximately 15g of vinegar or citric acid. Boil the water, then let it sit for 1 hour. After 1 hour, discard the water and rinse the kettle thoroughly with clean water. This helps remove any manufacturing residues.
3. Placement: Place the kettle on a dry, stable, and level surface away from heat sources and direct sunlight.
4. Connect Power: Connect the detachable power cord to the kettle's power inlet, then plug it into a suitable electrical outlet.

5. Operating Instructions

1. Fill with Water: Open the lid and fill the kettle with fresh water. Do not fill below the MIN mark or above the MAX line (380ml).


Image: Step-by-step visual guide on how to use the kettle, including filling water, plugging in, opening steam cover, touching button to select temperature, and completion.

2. Close Lid: Securely close the lid before operating.
3. Power On: Ensure the kettle is plugged into a power outlet.
4. Select Temperature: Touch the button on the kettle's display to cycle through the desired temperature settings: 45°C, 55°C, 70°C, 80°C, 90°C, or 100°C. The selected temperature will be displayed.
5. Boiling Process: The kettle will automatically begin heating to the selected temperature. The digital display will show the current temperature.
6. Keep Warm Function: Once the target temperature is reached, the kettle will automatically switch to keep-warm mode for up to 12 hours. The actual temperature during keep-warm may fluctuate within ±5°C of the target temperature due to the heating program.
7. Pouring: Carefully open the steam cover before pouring. Pour hot water slowly and steadily.

6. Maintenance and Cleaning

Regular cleaning ensures optimal performance and extends the life of your kettle.

• Before Cleaning: Always unplug the kettle from the power outlet and allow it to cool completely before cleaning.
• Exterior Cleaning: Wipe the exterior of the kettle with a soft, damp cloth. Do not use abrasive cleaners, solvents, or harsh chemicals, as these may damage the surface.
• Interior Cleaning (Descaling): Over time, mineral deposits (limescale) may build up inside the kettle, especially in hard water areas. To descale:
  • Fill the kettle with water up to the MAX line.
  • Add approximately 15g of white vinegar or citric acid.
  • Boil the solution.
  • Let the solution sit in the kettle for at least 1 hour (or longer for heavy buildup).
  • Discard the solution and rinse the interior thoroughly with fresh water several times until the smell of vinegar is gone.
• Storage: When not in use for extended periods, ensure the kettle is clean and dry. Store it in a cool, dry place.

7. Troubleshooting

If you encounter any issues with your Anfilank Portable Electric Kettle, please refer to the following common problems and solutions:

If the problem persists after trying these solutions, please contact Anfilank customer support.

8. Specifications

Image: Detailed graphic showing the product dimensions and key specifications.

9. Warranty and Support

Your Anfilank Portable Electric Kettle comes with a 1-year manufacturer's warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use.

All products undergo thorough inspection before shipment. In the unlikely event of a product defect or malfunction, we offer prompt exchange, return, or refund services.

For any questions, concerns, or support needs regarding your product, please do not hesitate to contact Anfilank customer service. Please have your model number (BY-K20A-Beige) and purchase date ready when contacting support.
