Introduction
This manual provides detailed instructions for the assembly, operation, and maintenance of your Vente-unique DESADO bed frame. The DESADO bed frame is designed for a 160 x 200 cm mattress and features integrated nightstands with drawers and LED lighting. Please read these instructions carefully before beginning assembly and retain them for future reference.
Overall view of the Vente-unique DESADO bed frame with integrated LED lighting and nightstands.
Safety Information
- Ensure all components are present and undamaged before assembly. Do not use damaged parts.
- Assemble the bed frame on a soft, clean surface to prevent scratches.
- Always use the correct tools as specified in the assembly guide.
- Do not overtighten screws, as this may damage the particle board.
- Keep small parts away from children during assembly.
- The maximum load for each drawer is 2 kg. The maximum load for each nightstand surface is 2 kg.
- The recommended maximum load for the entire bed frame is 120 kg.
Package Contents
Your Vente-unique DESADO bed frame is delivered in two packages. Please verify that both packages have been received and are in good condition upon delivery.
- Package N°1: Length 216 cm, Width 107 cm, Height 4 cm, Weight 47 kg
- Package N°2: Length 213 cm, Width 36 cm, Height 15 cm, Weight 51 kg
Setup and Assembly
The DESADO bed frame requires self-assembly. Follow the included graphical assembly instructions carefully. Below are general steps and important considerations:
- Unpack Components: Carefully unpack all parts and hardware. Lay them out on a protected surface.
- Identify Parts: Refer to the parts list in your separate assembly guide to identify each component.
- Assemble Frame: Begin by assembling the main bed frame structure. Ensure all connections are secure but do not fully tighten until the entire frame is aligned.
- Install Headboard: Attach the headboard to the main frame. The headboard features the natural wood finish and the integrated LED strip.
- Assemble Nightstands: Construct the integrated nightstands and attach them to the headboard structure.
- Install Drawers: Assemble the two pull-out drawers and insert them into the nightstand compartments. Ensure they slide smoothly.
- LED Lighting Connection: Connect the LED lighting system. The LEDs operate via an interrupter and require a sector plug connection. Ensure all electrical connections are secure and follow local electrical safety guidelines. The LED power is 12 W.
- Final Tightening: Once all components are in place and aligned, carefully tighten all screws and fasteners.
Detailed technical diagram showing the dimensions of the DESADO bed frame and its components, including nightstands and drawers.
View of the DESADO bed frame showing one of the integrated nightstands with a pull-out drawer.
Operating Instructions
- LED Lighting: The integrated LED lighting is controlled by an interrupter switch. Connect the bed frame to a standard power outlet to enable the LED function.
- Storage Drawers: The two integrated drawers are designed for light storage. Gently pull the drawers to open and push to close. Avoid overloading them beyond the 2 kg limit per drawer.
- Mattress and Slat Base: This bed frame is compatible with all mattresses and slat bases measuring 160 x 200 cm. (Mattress and slat base are not included).
Close-up view of the DESADO bed frame's headboard, highlighting the natural wood finish and integrated LED strip.
Maintenance
- Cleaning: Wipe the bed frame surfaces with a damp cloth. Avoid using harsh chemicals or abrasive cleaners, as these can damage the melamine finish.
- Inspection: Periodically check all screws and fasteners to ensure they remain tight. Retighten if necessary.
- LED Care: If the LED lighting malfunctions, check the power connection. Do not attempt to repair the LED strip yourself; contact customer support.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| LEDs do not light up | Power cable not connected; Interrupter off; Faulty connection | Ensure power cable is securely plugged in; Turn interrupter on; Check all LED connections. If problem persists, contact support. |
| Drawers are difficult to open/close | Overloaded drawer; Misaligned runners; Obstruction | Reduce weight in the drawer; Check that drawer runners are correctly installed and free of debris; Ensure no items are blocking the drawer path. |
| Bed frame feels unstable | Loose fasteners; Uneven floor | Check and tighten all screws and bolts; Ensure the bed is on a level surface. Use furniture pads if necessary to stabilize. |
Specifications
| Feature | Detail |
|---|---|
| Model Number | DESADO |
| Brand | Vente-unique |
| Dimensions (L x W x H) | 245.2 cm x 208.8 cm x 115.6 cm |
| Sleeping Area Size | 160 x 200 cm |
| Number of Places | 2 places |
| Material | Particle board (Bois) |
| Finish | Melamine (Mélaminé) |
| Color | Natural light and White |
| LED Power | 12 W |
| LED Color | White |
| LED Control Type | Interrupter |
| LED Connection Type | Sector plug |
| Integrated Nightstands | Yes |
| Storage Type | 2 drawers (Tiroir coulissant) |
| Max. Load per Drawer | 2 kg |
| Max. Load per Nightstand | 2 kg |
| Recommended Max. Load (Bed) | 120 kg |
| Product Weight | 98.5 kg |
| Assembly Required | Yes |
| Country of Origin | France |
Warranty and Support
This Vente-unique product is manufactured in Europe, adhering to quality standards. For any questions regarding assembly, missing parts, or product defects, please contact Vente-unique customer support. Refer to your purchase documentation for specific warranty terms and contact information.
