Carrera GO!!! Ferrari Power Racing Slot Car Track Set Instruction Manual

Introduction

This manual provides essential information for the safe and proper use of your Carrera GO!!! Ferrari Power Racing slot car track set. Please read these instructions carefully before assembly and operation. This set is designed for racing enthusiasts aged 6 years and older, offering an exciting racing experience for up to two players.

The Carrera GO!!! Ferrari Power Racing set features a 1:43 scale racing track and highly detailed 1:43 scale Ferrari 296 GT3 racing cars. Experience thrilling races with action-packed track elements and precise hand controllers with a turbo boost function.

Safety Information

WARNING: CHOKING HAZARD - Small parts. Not for children under 3 years.

Always supervise children during play.
Keep fingers and hair away from moving parts of the cars and track.
Do not modify the track or cars. Use only original Carrera parts.
Ensure all track connections are secure before operating.
This product is for indoor use only.
Disconnect the power supply when not in use or during maintenance.
The power adapter is not a toy.

For detailed safety information, please refer to the official safety document provided by Carrera.

Image: The Carrera GO!!! Ferrari Power Racing slot car track set box, showing the two Ferrari 296 GT3 cars and a diagram of the track layout.

Package Contents

The Carrera GO!!! Ferrari Power Racing set includes everything needed for instant racing fun. Please check that all components listed below are present in your package:

1x Carrera GO!!! Ferrari Power Racing Track Set (8.6 meters / 28.22 feet track length)
1x Ferrari 296 GT3 "AF Corse, No. 21" Slot Car (1:43 scale)
1x Ferrari 296 GT3 "Cetilar Racing, No. 47" Slot Car (1:43 scale)
2x Hand Controllers with Turbo Boost button
Track sections including straights, curves, junction, narrow section, and action curves.
Lap Counter
Power Supply (European CEE 7/16 plug)
Support pillars and track clips
Instruction Manual

Image: Detailed view of the Carrera GO!!! Ferrari Power Racing box contents, showing track pieces, two Ferrari cars, hand controllers, and accessories.

Ferrari 296 GT3 AF Corse No. 21 Slot Car Image: Close-up of the red Ferrari 296 GT3 "AF Corse, No. 21" slot car, featuring detailed livery.

Ferrari 296 GT3 Cetilar Racing No. 47 Slot Car Image: Close-up of the blue Ferrari 296 GT3 "Cetilar Racing, No. 47" slot car, featuring detailed livery.

Setup Instructions

Follow these steps to assemble your Carrera GO!!! Ferrari Power Racing track set. Assembly time is approximately 30 minutes.

Choose a Location: Select a flat, stable surface indoors. Ensure you have enough space for the track layout (approximately 250 x 145 cm or 8.20 x 4.76 ft).
Unpack Components: Carefully remove all track pieces, cars, controllers, and accessories from the packaging.
Assemble the Track: Connect the track sections according to the desired layout. Ensure each connection is firm and flush. The track diagram below illustrates a possible configuration.
Install Support Pillars: For elevated sections and action curves, attach the provided support pillars to ensure stability. Adjust the supports for steep curves to prevent cars from flying off.
Connect Power Track: Insert the power connection track piece into the layout.
Connect Hand Controllers: Plug the two hand controllers into the designated ports on the power connection track.
Connect Power Supply: Plug the power supply into the power connection track, then plug the adapter into a standard European CEE 7/16 electrical outlet.
Place Cars: Carefully place the Ferrari slot cars onto the track, ensuring the guide keels are correctly seated in the track slot and the contact brushes are touching the power rails.

Image: Diagram showing a possible track layout for the Carrera GO!!! Ferrari Power Racing set, including dimensions (250x145 cm) and various track elements like action curves, junction, narrow section, and lap counter.

Operating Instructions

Once the track is assembled and powered, you are ready to race!

Start Racing: Gently press the trigger on your hand controller to accelerate your car. The cars are track-powered.
Control Speed: Adjust the pressure on the trigger to control your car's speed. Too much speed, especially on curves, may cause the car to deslot.
Turbo Boost: For an extra burst of speed on straights, press the red Turbo Boost button on your hand controller. Use this strategically to overtake opponents.
Lap Counter: The integrated lap counter will keep track of completed laps. The first player to reach the set number of laps wins.
Fair Play: Encourage fair competition and strategic thinking during races.

Maintenance

Regular maintenance ensures optimal performance and longevity of your Carrera GO!!! set.

Track Cleaning: Keep the track surface and power rails clean and free of dust and debris. Use a soft, dry cloth. Dust accumulation can affect car performance.
Car Maintenance:
- Contact Brushes: Regularly check the contact brushes on the underside of the cars. If they are worn or bent, replace them with genuine Carrera spare parts to ensure good electrical contact.
- Guide Keel: Ensure the guide keel is clean and moves freely within the track slot.
- Wheels and Axles: Keep wheels and axles free of hair and dust.
Storage: When not in use, store the track and cars in a clean, dry place, away from direct sunlight and extreme temperatures. Disassemble the track if storing for extended periods.

Troubleshooting

If you encounter issues with your Carrera GO!!! set, refer to the following common problems and solutions:

Problem	Possible Cause	Solution
Car does not move or moves intermittently.	No power to the track. Poor contact between car and track. Worn or dirty contact brushes. Track sections not properly connected.	Check power adapter connection to outlet and track. Ensure guide keel is fully in the slot and brushes touch rails. Clean or replace contact brushes. Verify all track connections are secure and flush.
Car deslots frequently.	Excessive speed on curves. Track not level or stable. Worn tires or dirty track.	Reduce speed on curves. Ensure track is on a flat surface and supports are correctly placed. Clean track and car tires.
Lap counter not registering.	Car not passing over the sensor correctly. Sensor obstructed or dirty.	Ensure car passes smoothly over the lap counter section. Clean the lap counter sensor area.

Specifications

Model Name: Ferrari Power Racing
Model Number: 20062575
Brand: Carrera
Scale: 1:43
Track Length: 8.6 meters (28.22 feet)
Assembled Dimensions (approx.): 250 x 145 cm (8.20 x 4.76 feet)
Cars Included: 2x Ferrari 296 GT3 (AF Corse No. 21, Cetilar Racing No. 47)
Number of Players: 2
Power Source: Track-powered (Electric)
Power Plug Type: European CEE 7/16
Control Method: Wired Hand Controllers with Turbo button
Recommended Age: 6+ years
Material: Plastic
Item Weight (packaging): 3.3 kg
Assembly Time (approx.): 30 minutes
Educational Objective: Hand-eye coordination, fine motor skills, strategic thinking, competition, fair play
Usage: Indoor use only

Warranty

This Carrera GO!!! Ferrari Power Racing set is covered by a 2-year manufacturer's warranty. Please retain your proof of purchase for warranty claims. The warranty covers manufacturing defects under normal use. It does not cover damage resulting from misuse, accidents, unauthorized modifications, or normal wear and tear.

Support

For technical assistance, spare parts, or further inquiries regarding your Carrera GO!!! Ferrari Power Racing set, please contact Carrera customer support.

Manufacturer: Carrera Revell Europe GmbH

Website: www.carrera-toys.com

Please have your model number (20062575) and proof of purchase ready when contacting support.
