EMEET C960 AF Webcam User Manual

1. Introduction

This manual provides detailed instructions for the setup, operation, and maintenance of your EMEET C960 AF Webcam. Designed for superior video quality and ease of use, this webcam is ideal for video calls, streaming, and online education.

Key Features:

• FHD 1080P Autofocus: Delivers up to 1080p resolution at 60fps with fast and precise PDAF autofocus (20-300cm range).
• 73° View Angle with Privacy Cover: Ideal for personal use, minimizing background distractions, and ensuring privacy when not in use.
• Built-in Dual Noise Reduction Microphones: Enhances audio clarity by reducing background noise.
• Plug and Play USB: No additional drivers required for quick setup.
• Broad Compatibility: Supports Windows, MacOS, Linux, and Android TV, compatible with major applications like Zoom, Teams, and Google Meet.
• EMEETLINK Software Support: Allows customization of webcam settings.

Visual comparison highlighting the superior clarity of 1080p at 60 frames per second provided by the EMEET C960 AF Webcam.

Demonstration of the PDAF autofocus feature, ensuring sharp and precise imagery during video calls.

2. Setup

2.1 What's in the Box

• C960 Webcam AF Version
• Privacy Cover
• User Manual

2.2 Physical Overview

The EMEET C960 AF Webcam features a compact design with integrated microphones and a lens. The adjustable stand allows for versatile placement.

Front view of the EMEET C960 AF Webcam, showing the lens and microphone grilles.

2.3 Installation

The webcam can be installed on a monitor, laptop, or tripod.

1. On a Monitor/Laptop:

   Place the webcam on top of your monitor or laptop screen. The adjustable clip base will securely rest on the top edge, with the rear foot providing stability against the back of the screen. Adjust the angle as needed.



   The EMEET C960 AF Webcam securely clipped onto the top of a laptop screen.

2. On a Tripod:

   The webcam's base includes a 1/4-inch tripod thread. Screw the webcam onto a compatible tripod. Adjust the tripod's height and position for optimal viewing.



   The EMEET C960 AF Webcam attached to a tripod, suitable for desktop placement.

2.4 Connecting to Your Computer (Plug and Play)

The EMEET C960 AF Webcam is a plug-and-play device, requiring no additional drivers for basic functionality.

1. Connect the USB-A cable from the webcam to an available USB port on your computer.
2. Your computer will automatically detect and install the necessary generic drivers. This process usually takes less than a minute.
3. Once installed, the webcam is ready for use with your preferred video conferencing or streaming application.

3. Operating Instructions

3.1 Using the Privacy Cover

The included physical privacy cover can be attached to the webcam to block the lens when not in use, ensuring your privacy and protecting the lens from dust.

1. Peel off the adhesive backing from the privacy cover.
2. Align the cover over the webcam lens and press firmly to secure it.
3. Slide the cover open to use the webcam and close it when finished.

The EMEET C960 AF Webcam showing the privacy cover in both open and closed positions.

3.2 Software Compatibility

The C960 AF webcam is broadly compatible with various operating systems and applications:

• Operating Systems: Windows 10/11, MacOS 10.14 or later, Linux, Android TV 7.0 or later.
• Applications: Zoom, Microsoft Teams, Facetime, Google Meet, OBS, Twitch, Facebook, YouTube, and more.

Image displaying the EMEET C960 AF Webcam and logos of compatible software platforms like Zoom, Teams, and Google Meet.

3.3 EMEETLINK Software Application

For advanced customization and optimal performance, download the EMEETLINK software from the official EMEET website.

1. Visit emeet.com and navigate to the "Support Center" -> "Downloads" section.
2. Download and install the EMEETLINK software compatible with your operating system (Windows or MacOS).
3. Within EMEETLINK, you can adjust various settings such as brightness, contrast, saturation, white balance, and image filters to fine-tune your video output.

3.4 Adjusting Video Resolution

You can adjust the video resolution and frame rate through your computer's camera software or within the EMEETLINK application.

1. Open your computer's native camera application (e.g., "Camera" on Windows).
2. Access the settings menu within the camera application.
3. Locate "Video Quality" or similar settings and select your desired resolution and frame rate (e.g., 1080p 60fps).

4. Maintenance

• Keep the webcam lens clean using a soft, dry cloth. Avoid abrasive materials or harsh chemicals.
• Store the webcam in a cool, dry place when not in use. Utilize the privacy cover to protect the lens.
• Avoid exposing the device to extreme temperatures or direct sunlight for prolonged periods.

5. Troubleshooting

• No Image/Video:
  • Ensure the USB cable is securely connected to both the webcam and your computer.
  • Verify that the privacy cover is open.
  • Check your application settings to ensure the EMEET C960 AF is selected as the video input device.
  • Try connecting to a different USB port on your computer.
• Poor Image Quality:
  • Ensure adequate lighting in your environment.
  • Clean the webcam lens.
  • Adjust settings (brightness, contrast, etc.) using the EMEETLINK software or your computer's camera settings.
  • Verify that the selected resolution and frame rate are appropriate for your system.
• No Audio/Poor Audio Quality:
  • Check your application settings to ensure the EMEET C960 AF is selected as the audio input (microphone) device.
  • Ensure your computer's microphone volume is not muted or set too low.
  • Reduce background noise in your environment.
• Image Display is Abnormal (e.g., incorrect colors, flickering):

  If the image display appears abnormal, such as incorrect colors or flickering, try the following steps:

  • Open the EMEETLINK software and navigate to the video settings.
  • Look for options like "Anti-flicker" and adjust the frequency (e.g., 50Hz or 60Hz) to match your region's power supply frequency.
  • Restore default settings within EMEETLINK or your computer's camera application.
  • Ensure your operating system and camera drivers are up to date.

6. Specifications

7. Warranty and Support

7.1 Warranty Information

The EMEET C960 AF Webcam comes with a 2-year warranty from the date of purchase. This warranty covers manufacturing defects and ensures reliable performance of your device.

7.2 Customer Support

For technical assistance, troubleshooting, or any inquiries regarding your EMEET product, please contact EMEET customer support:

• Visit the official EMEET website: emeet.com
• Navigate to the "Support Center" for FAQs, downloads, and contact options.
• Utilize the EMEETLINK software for device management and firmware updates.

Manufacturer: Shenzhen eMeet technology Co.,Ltd.
