YUEHEMEI Open-Ear Headphones User Manual

Product Overview

The YUEHEMEI Q2 Open-Ear Headphones are designed for ultimate comfort and a stable fit, featuring a lightweight ergonomic 120° adjustable silicone ear cushion hook. These wireless Bluetooth 5.3 earbuds deliver crystal clear sound through 16.2mm drivers and offer clear calls. They are sweat-proof and provide up to 30 hours of playtime with the charging case, ensuring situational awareness for safer use during activities like driving or running.

Image: The YUEHEMEI Q2 Open-Ear Headphones in White-Orange, shown with their compact charging case.

What's in the Box

• YUEHEMEI Q2 Open-Ear Headphones (2 earbuds)
• Charging Case
• USB-C Charging Cable
• User Manual

Setup

First Time Pairing

1. Open the charging case and take out the earbuds. Ensure any protective sticky tapes on the back of the earbuds are removed. Place the earbuds back into the case and ensure the indicator lights on the earbuds are on.
2. Turn on Bluetooth on your smartphone or device. Search for "YHM Q2" in the list of available devices and connect to it. The earbuds will automatically connect to the last paired device when taken out of the case.

Image: A smartphone screen displaying the Bluetooth settings, showing the "YHM Q2" earbuds as connected, illustrating the instant connection feature.

Wearing Instructions

1. Take the earbud out of the case.
2. Rotate the ear hook to its maximum curve.
3. Hang the earbud on the corresponding ear, ensuring the ear hook wraps closely around the ear back.
4. Rotate the earbud to the appropriate position for comfort and secure fit. Shake your head gently to confirm the earbud stays in place.

Image: A diagram illustrating the ergonomic design of the open-ear earbuds and how the 120° adjustable silicone ear hook provides a secure and comfortable fit around the ear.

Operating Instructions

Power On/Off & Charging

The earbuds automatically power on when removed from the charging case and power off when placed back into the case with the lid closed. They also begin charging automatically when placed in the case and the lid is closed.

• Earbud Charging: When earbuds are placed in the case and the lid is closed, a white light keeps on, indicating "being charged". The white light goes off when "fully charged".
• Charging Case Charging: A red light flashes when the charging case is "being charged". The red light keeps on when "fully charged". If the charging case is in low battery, a white light flashes.

Image: The charging case displaying its battery capacity (400mAh) and earbud battery capacity (50mAh), along with charging times: 1.5 hours for charging, 6 hours single playtime, and 30 hours with the charging case.

Smart Touch Controls

The YUEHEMEI Q2 earbuds feature intuitive touch controls for managing music playback, calls, and voice assistant functions.

• Play/Pause: Single-tap on either the left (L) or right (R) earbud.
• Next Song: Double-tap on the right (R) earbud.
• Previous Song: Double-tap on the left (L) earbud.
• Increase Volume: Hold the right (R) earbud.
• Decrease Volume: Hold the left (L) earbud.
• Answer/Hang up Call: Double-tap on either earbud.
• Reject Call: Hold either earbud.
• Game Mode: Triple-tap on the left (L) earbud to enter/exit game mode.
• Voice Assistant (Siri): Triple-tap on the right (R) earbud to wake up your device's voice assistant.

Image: A visual guide detailing the smart touch controls for the earbuds, including single-tap for play/pause, double-tap for switching songs or answering calls, holding for volume adjustment or rejecting calls, and triple-tap for game mode or voice assistant activation.

Maintenance

The YUEHEMEI Q2 earbuds are designed for durability and ease of maintenance.

• Sweat Proof & Water-Resistant: With an IPX4 water-resistant rating and nano coating, these headphones are protected against sweat and splashes. This makes them suitable for workouts and outdoor activities.
• Cleaning: Gently wipe the earbuds and charging case with a soft, dry cloth. Avoid using abrasive materials or harsh chemicals.
• Storage: Store the earbuds in their charging case when not in use to protect them and ensure they remain charged.

Image: A woman drinking water, with water splashing near her ear, demonstrating the IPX4 water-resistant feature of the earbuds, which protects them from sweat and splashes.

Troubleshooting

If you encounter any issues with your YUEHEMEI Q2 Open-Ear Headphones, please refer to the following common solutions:

• No Sound/Low Volume:
  • Ensure earbuds are properly seated in your ears and the volume is turned up on both the earbuds and your connected device.
  • Check if the earbuds are connected to the correct device via Bluetooth.
• Connection Issues:
  • Make sure Bluetooth is enabled on your device and the earbuds are within range (up to 33 feet).
  • Try unpairing and re-pairing the earbuds with your device.
  • Ensure the earbuds are fully charged.
• Charging Problems:
  • Verify the charging cable is securely connected to both the case and a power source.
  • Ensure the earbuds are correctly placed in the charging case.
  • Clean the charging contacts on both the earbuds and the case if necessary.
• Poor Call Quality:
  • Ensure the microphone is not obstructed.
  • Move to an area with less background noise.
  • Check your device's network connection.

For further assistance, please contact YUEHEMEI customer support.

Specifications

Warranty and Support

YUEHEMEI products are manufactured to high quality standards. For information regarding warranty coverage, technical support, or service inquiries, please refer to the contact details provided in the product packaging or visit the official YUEHEMEI website.

Please retain your proof of purchase for any warranty claims.
