Introduction
This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your Segway Portable Power Station Cube 2000. Please read this manual thoroughly before using the product and retain it for future reference.
The Segway Cube 2000 is a versatile portable power station designed to provide reliable power for various applications, including camping, home backup, power outages, and off-grid use. It features a high-capacity LiFePO4 battery and expandable power options.
Safety Information
Always adhere to the following safety precautions to prevent injury or damage to the device:
- Do not disassemble, repair, or modify the unit. Incorrect reassembly may cause fire or electric shock.
- Do not expose the unit to fire or high temperatures.
- Do not use or store the unit in direct sunlight or in hot environments.
- Keep the unit away from water, moisture, and corrosive substances. The unit has an IP56 rating for water and dust protection, but it is not submersible.
- Ensure proper ventilation during use to prevent overheating.
- Keep out of reach of children and pets.
- Use only original or certified accessories.
- Dispose of the product according to local regulations.
Package Contents
Verify that all items are present in your package:
- Segway Cube 2000 Portable Power Station
- Warranty Policy × 1
- 3 mm Allen Wrench × 1 (For CUBE-2000 only)
- AC Charging Cable × 1
- Car Charging Cable × 1
Product Overview
The Segway Cube 2000 is designed for robust and versatile power delivery. Key features include:
- High-Power Performance: Delivers 2200W AC power, extendable to 4400W with R-drive function.
- Super Fast Recharging: Achieves 2048 Wh in 1.8 hours.
- Expandable Capacity: Cordless expandability up to 5kWh with BTX-1000 expansion batteries (sold separately).
- Durable Construction: LiFePO4 battery with 4000+ cycles and IP56 water/dust protection.
- Efficient Solar Charging: MPPT technology for up to 97% conversion efficiency.
- Versatile Ports: Dual 100W USB-C ports, multiple AC outlets, car outlet, DC5525 outputs, USB Type-A outputs.
- Smart APP Control: Remote control and monitoring via Segway-Ninebot App.
- UPS Function: Uninterruptible Power Supply with 0.03s switch time for appliance protection.
Image: The Segway Cube 2000 power station shown with two additional BTX-1000 expansion battery modules stacked below it, illustrating its modular and expandable design. The main unit features multiple AC outlets, USB ports, and a display screen.
Image: A diagram showing the dimensions of the Segway Cube 2000 power station. The length is 16.42 inches, width is 14.06 inches, and height is 20.08 inches when stacked with expansion units.
Setup
Initial Charging
Before first use, fully charge the Segway Cube 2000. You can charge it via AC wall outlet, car charger, or solar panels.
- AC Charging: Connect the provided AC charging cable to the AC input port on the power station and then to a standard wall outlet. The unit supports 1250W fast AC charging.
- Car Charging: Use the provided car charging cable to connect the power station to your vehicle's 12V/24V car outlet.
- Solar Charging: Connect compatible solar panels (sold separately) to the solar input port. The unit supports up to 800W solar input with MPPT technology.
Image: Illustrates the three charging methods for the Segway Cube 2000: AC wall outlet, solar panels, and a car outlet. The image shows the power station connected to solar panels in an outdoor setting.
Image: Shows the Segway Cube 2000 being recharged by both an AC wall outlet and solar panels simultaneously, highlighting its super-fast recharging capabilities with 1250W AC charging and 800W solar charging.
Expanding Capacity (Optional)
The Cube 2000's capacity can be expanded up to 5kWh by stacking up to three BTX-1000 expansion batteries (sold separately). Refer to the BTX-1000 manual for specific connection instructions.
Image: A visual representation of the Segway Cube 2000 with multiple BTX-1000 expansion batteries stacked, demonstrating its cordless expandable power capability up to 5120Wh.
Image: Illustrates the modular design of the Segway Power Station Cube Series, showing how additional battery packs can be easily added to expand the capacity from 1kWh up to 5kWh.
Operating Instructions
Turning On/Off
- To turn on the power station, press and hold the main power button until the display illuminates.
- To turn off the power station, press and hold the main power button until the display turns off.
Using AC Outlets
The Cube 2000 provides three 120V AC outlets with a maximum output of 2200W (inverter mode, pure sine wave). It also supports a bypass mode for 120V~ 60 Hz 12A Max.
- Press the AC power button to enable the AC outlets. The indicator light will turn on.
- Plug your devices into the AC outlets.
- To disable AC output, press the AC power button again.
The R-Drive function allows the Cube 2000 to power devices with power consumption up to 4400W. This function is particularly suitable for resistive devices and appliances with low sensitivity, such as electric kettles, hair dryers, electric cookers, and electric ovens.
Image: Shows the Segway Cube 2000 in an outdoor setting, powering a chainsaw, demonstrating its 2200W MAX AC output. Below, icons indicate runtimes for a hair dryer (500W, 3.6Hrs), microwave (800W, 2.6Hrs), TV (70W, 23.8Hrs), and refrigerator (150W, 11.4Hrs).
Image: Text overlay emphasizing "2200W AC Powerful Output" and explaining the R-Drive function which allows the Cube Series to power appliances up to 4400W, suitable for resistive devices like electric kettles and hair dryers.
Image: A graphic illustrating what can be powered with 1kWh capacity, showing estimated runtimes for various devices such as smartphones (87 charges), laptops (16 charges), hair dryers (1.8 Hrs), microwaves (1.3 Hrs), and refrigerators (5.7 Hrs).
Using DC Outputs (USB, Car Outlet, DC5525)
- Press the DC power button to enable the DC outputs.
- Connect your devices to the appropriate USB Type-A (18W Max), USB Type-C (100W Max), Car Outlet (136W Max), or DC5525 (68W Max) ports.
- To disable DC output, press the DC power button again.
The Cube 2000 also features car battery detection, allowing it to recharge a car battery with stabilized voltage and current. This is for charging only and cannot be used for jump-starting a vehicle. The charge cable is sold separately.
Image: A person connecting the Segway Cube 2000 to a car battery under the hood of a vehicle, illustrating its capability to charge a car battery for emergency situations. Note that the charge cable is sold separately.
Smart App Control
Download the Segway-Ninebot App to remotely control output/input functions and monitor the power status and work status of your Cube 2000 in real-time.
Image: A hand holding a smartphone displaying the Segway Smart App interface, showing remaining power, temperature, and controls for AC and DC outputs, as well as USB-C ports.
Image: A hand holding a smartphone with the Segway-Ninebot App open, emphasizing the ability to control output/input functions and monitor power status in real-time, providing full control over energy usage.
UPS Function (Uninterruptible Power Supply)
The Cube 2000 features a UPS function with a 0.03-second switch time. In the event of a power outage, the Cube Series swiftly activates, delivering stored power to protect your connected appliances.
Image: The Segway Cube 2000 connected to a kitchen appliance (oven) during what appears to be a power outage, with a lantern providing light, illustrating its use for home backup and the UPS function.
Image: A family sitting at a table with the Segway Cube 2000 providing power, emphasizing its role as a reliable home power backup with a 0.03-second UPS switch time. Data is based on specific testing conditions and UL 1778 certification.
Maintenance
Cleaning
- Wipe the unit with a dry, soft cloth.
- Do not use abrasive cleaners or solvents.
Storage
- Store the unit in a cool, dry place, away from direct sunlight and extreme temperatures.
- For long-term storage, charge the unit to approximately 50-80% every 3-6 months to maintain battery health.
- Ensure the unit is turned off before storing.
The Cube 2000 features a LiFePO4 battery designed for over 4000 cycles, ensuring long-lasting performance. Its AM60B magnesium alloy frame and multi-layered waterproof design contribute to its durability and IP56 protection rating.
Image: A cutaway view of the Segway Cube 2000 highlighting its internal LFP (LiFePO4) battery cells, emphasizing their upgraded safety and endurance with 4000+ cycles compared to other battery cells at 800 cycles.
Image: A detailed view of the internal LiFePO4 battery cells within the Segway Cube, explaining that Segway-Ninebot has produced over 20 million packs of self-developed power batteries, ensuring safety and durability with over 4000 cycles and a Battery Management System (BMS) offering ten protection mechanisms.
Image: The Segway Cube 2000 power station partially submerged in water, demonstrating its IP56 protection rating and durable construction with a multi-layered waterproof design and AM60B metal frame.
Image: The Segway Cube 2000 in a watery environment, highlighting its "Built Tough with Water Resistance" and "IP56 Battery pack" features, explaining its high-performance magnesium alloy AM60B material frame and multi-layered waterproof design.
Image: A list of 10 Battery Management System (BMS) protection mechanisms, including Over-charge Protection, Over-current Protection, Over-discharge Protection, Over-voltage Protection, Short Circuit Protection, Temperature Protection, Battery Balancing, Battery Level Calculation, Automatic Sleep, and Pre-charge Protection.
Troubleshooting
If you encounter issues with your Segway Cube 2000, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Unit does not turn on. | Battery is completely discharged; Power button not pressed long enough. | Charge the unit using AC, car, or solar input. Press and hold the power button for a few seconds. |
| AC outlets not working. | AC output not enabled; Overload protection activated. | Press the AC power button to enable. Reduce the load on the AC outlets. Check device wattage. |
| Unit is not charging. | Charging cable not properly connected; Input source issue; Temperature outside charging range. | Ensure cables are securely connected. Verify the wall outlet/car/solar panel is working. Charge temperature range: 41°F~113°F (5°C~45°C). |
| Display shows an error code. | Internal system error. | Refer to the Segway-Ninebot App for detailed error explanations or contact customer support. |
Specifications
| Feature | Detail |
|---|---|
| Model Name | CUBE-2000 |
| Battery Type | LiFePO4 |
| Capacity | 2048Wh (Expandable up to 5kWh) |
| AC Output (x3) | 120 V~20 A 60 Hz 2200 W Max (inverter mode, pure sine wave) / 120 V~ 60 Hz 12 A Max (bypass mode) |
| R-Drive Function | Up to 4400W for resistive devices |
| AC Input | 120 V~8 A 60 Hz 1250 W Max |
| Solar Panel Input | 12-60 V 800 W Max (MPPT) |
| Car Input | 12 V/24 V 8 A 200 W Max |
| USB Type-A Output (x4) | 5/9/12 V 3 A 18 W Max |
| USB Type-C Output (x2) | 5/9/12/15/20 V 5 A 100 W Max |
| Car Outlet | 13.6 V 10 A 136 W Max |
| DC5525 Output (x2) | 13.6 V 5 A 68 W Max |
| Discharge Temperature | 14°F~113°F (-10°C~45°C) |
| Charge Temperature | 41°F~113°F (5°C~45°C) |
| Dimensions (L x W x H) | 16.42"L x 14.06"W x 20.08"H |
| Item Weight | 58 Pounds |
| Material | AM60B Alloy |
| IP Rating | IP56 |
| UPC | 841450001342 |
Image: A graphic summarizing key features: Cube 2000 = 2kWh, Up to 2050W fast charging in 1.8 hours, Expandable Battery Pack up to 5kWh, Durable LiFePO4 battery (4000+ cycles), 5 years warranty, and IP56 rating battery pack.
Warranty Information
The Segway Cube 2000 is backed by a 5-year warranty, ensuring reliability and durability. Please refer to the included Warranty Policy document for full terms and conditions.
Customer Support
For further assistance, technical support, or warranty claims, please visit the official Segway website or contact their customer service department.
You can also visit the Segway Store on Amazon for product information and resources.
