Hotel Collection Villa Scent Diffuser Instruction Manual

1. Safety Information

• Read all instructions before operating the diffuser.
• Keep the device away from water or other liquids.
• Ensure the power adapter is compatible with your local voltage.
• Do not attempt to disassemble or repair the unit yourself. Contact customer support for assistance.
• Use only recommended fragrance oils. Other oils may damage the device or void the warranty.
• Keep out of reach of children and pets. While the technology is residue-free, direct contact with concentrated oils should be avoided.
• Place the diffuser on a stable, flat surface.

2. Package Contents

Please check the box for the following items:

• Hotel Collection Villa Scent Diffuser Unit
• Power Adapter
• 500ml Fragrance Oil Bottle (empty, for user filling)
• HVAC Connection Kit (tubing and connectors)
• User Manual

3. Product Overview

The Hotel Collection Villa Scent Diffuser utilizes advanced cold-air diffusion technology to transform fragrance oil into a dry nano-mist. This method ensures the scent remains suspended in the air longer, providing efficient and even coverage without heat or water. It is designed for both standalone use and integration with HVAC systems, covering areas up to 1800 sq ft.

Image 1: Front view of the Hotel Collection Villa Scent Diffuser, showcasing its sleek black design and digital display.

Image 2: Key features of the Villa Scent Diffuser, including safety for pets and children, coverage area, oil capacity, and cold-air diffusion technology.

Image 3: Dimensions of the Villa Scent Diffuser, measuring 9"L x 5.25"W x 15.25"H.

4. Setup

4.1 Fragrance Oil Installation

1. Open the fragrance compartment of the diffuser.
2. Fill the provided 500ml bottle with your desired Hotel Collection fragrance oil.
3. Carefully screw the filled bottle into the diffuser's internal mechanism.
4. Close the fragrance compartment and engage the security lock to prevent tampering.

4.2 Power Connection

Connect the power adapter to the diffuser and then plug it into a standard electrical outlet.

4.3 Standalone Use

For standalone operation, place the diffuser in a central location within the desired scenting area. The built-in fan will assist in distributing the fragrance.

4.4 HVAC System Connection

The Villa Scent Diffuser can be integrated with your HVAC system for whole-home scenting. Connect the clear tubing from the HVAC connection kit to the diffuser and then to the supply air portion of your furnace. Consult a professional if you are unsure about HVAC system integration.

Image 4: Diagram illustrating how the Villa Scent Diffuser connects to an HVAC system for widespread fragrance distribution.

5. Operating Instructions

5.1 Power On/Off

Press the power button on the front panel to turn the diffuser on or off. The LCD display will illuminate when the device is active.

5.2 Setting the Timer and Schedule

The diffuser features an internal digital timer and a programmable weekly timer with up to four unique operating periods. Refer to the on-screen menu and control buttons to set specific start and end times for each period, as well as the days of the week for operation.

5.3 Adjusting Scent Intensity

The scent intensity can be adjusted to control the amount of oil diffused per hour, ranging from 0.1 ml/hour up to 20.0 ml/hour. You can also fine-tune the diffusion intervals in 5-second increments within your set operating schedule. Use the control buttons to navigate the settings menu and modify these parameters to your preference.

6. Maintenance

Regular cleaning ensures optimal performance and extends the lifespan of your diffuser. It is recommended to clean the diffuser every 1-2 months, or when switching fragrance scents.

1. Fill the Hotel Collection fragrance oil bottle (the one that came with your diffuser) with rubbing alcohol up to the second line from the bottom.
2. Screw the alcohol-filled bottle into the diffuser.
3. Run the diffuser for 15 minutes to allow the alcohol to filter through the internal components and clean them.
4. Unplug the device from the wall outlet and keep the diffuser in an upright position.
5. Wipe the exterior of the device with a damp cloth to remove any oil stains or fingerprints. Avoid using harsh or abrasive cleaning products.

Image 5: Visual guide for cleaning the Villa Scent Diffuser using rubbing alcohol.

7. Troubleshooting

8. Specifications

• Brand: Hotel Collection
• Model Name: Villa Scent Diffuser
• Color: Black
• Product Dimensions: 9"L x 5.25"W x 15.25"H
• Item Weight: 13.09 pounds
• Material: Metal
• Power Source: Corded Electric
• Capacity: 500 Milliliters (oil bottle)
• Coverage: Up to 1800 square feet
• Special Feature: Timer Setting
• Technology: Cold-Air Diffusion (Heatless, Waterless)
• Compatibility: Standalone or HVAC System

9. Warranty and Support

For warranty information, technical support, or any questions regarding your Hotel Collection Villa Scent Diffuser, please refer to the warranty card included with your purchase or visit the official Hotel Collection website. You may also contact customer service through the retailer where the product was purchased.

Online Support: Visit the Hotel Collection Store on Amazon
