1. Introduction
Thank you for purchasing the Sharp ES-K10B-WL Drum Type Washer Dryer. This appliance is designed to provide efficient and thorough washing and drying, featuring advanced technologies such as Micro High-Pressure Washing and Heater Sensor Drying, while also prioritizing water and energy efficiency. This manual provides essential information for safe installation, operation, and maintenance of your new appliance.
Figure 1: Front view of the Sharp ES-K10B-WL Drum Type Washer Dryer.
2. Safety Information
Please read all safety instructions carefully before using the appliance to prevent injury to yourself and others, and to avoid property damage. Keep this manual in a safe place for future reference.
- Ensure the appliance is installed on a stable, level surface.
- Do not operate the appliance if the power cord is damaged or if the plug is loose.
- Keep children and pets away from the appliance during operation.
- Do not wash or dry items that have been soiled with flammable substances.
- Always unplug the appliance before cleaning or performing any maintenance.
3. Product Overview
The Sharp ES-K10B-WL is a high-performance drum type washer dryer designed for modern households. Key features include:
- Micro High-Pressure Washing: Utilizes fine water droplets at high pressure to deeply clean fibers.
- Heater Sensor Drying: Dries clothes efficiently with warm air, sensing the dryness level.
- Automatic Drying Duct Cleaning: Prevents lint buildup in the drying duct for consistent performance.
- Automatic Tub Cleaning: Keeps the washing tub clean and hygienic with every rinse.
- DD Inverter Motor: Ensures quiet operation, even during high-speed cycles.
- 4 Sensors: Optimizes washing and drying based on temperature, water level, load weight, and vibration.
Figure 2: Interior view of the washer dryer with the door open, showing the drum.
4. Setup and Installation
Proper installation is crucial for the performance and longevity of your washer dryer. Please refer to the detailed installation guide provided with your appliance for specific steps.
4.1. Space Requirements
Ensure adequate space around the appliance for proper ventilation and maintenance. The main unit dimensions are approximately 645mm (width) x 732mm (depth) x 1100mm (height). The width includes the drain hose, and the height includes the water supply hose.
Figure 3: Installation dimensions and required clearances.
4.2. Waterproof Pan
The appliance can be installed on a waterproof pan with an inner depth of 540mm or more. This compact design also supports direct bottom drainage.
Figure 4: Compact drum design for easy installation.
5. Operating Instructions
This section covers the basic operation and various functions of your washer dryer.
5.1. Washing Functions
The ES-K10B-WL features advanced washing technologies to ensure your clothes are thoroughly cleaned.
5.1.1. Micro High-Pressure Washing
This technology uses over 100,000 micro-fine water droplets per minute sprayed from a high-pressure shower nozzle to penetrate deep into fabric fibers, effectively removing stubborn dirt without damaging clothes.
Figure 5: Micro High-Pressure Washing effectiveness.
5.1.2. Specialized Wash Courses
Select the appropriate course for different types of stains and fabrics:
- Extreme Wash Course: Uses 40°C warm air to loosen dirt, then applies a micro high-pressure shower to remove tough stains like mud and yellowing. (For loads up to 2kg)
- Quick Pre-Wash Course: Ideal for light food spills.
- Home Cleaning Course: Suitable for delicate items like rayon blouses.
- Time-Saving Course: For quick washing of everyday items like T-shirts and towels.
Figure 6: Extreme Wash Course for stubborn dirt.
Figure 7: Quick Pre-Wash Course for minor spills.
Figure 8: Home Cleaning Course for delicate garments.
Figure 9: Time-Saving Course for daily laundry.
5.2. Drying Functions
The appliance offers efficient drying with smart features.
5.2.1. Heater Sensor Drying
This function uses warm air and sensors to detect the dryness level of your clothes, ensuring efficient and gentle drying while preventing over-drying.
Figure 10: Heater Sensor Drying in action.
5.2.2. DD Inverter Motor
The Direct Drive (DD) Inverter motor minimizes operating noise, allowing for quiet washing and drying even at night or early morning. Operating noise levels are 26dB (wash), 39dB (spin), and 41dB (dry).
Figure 11: Quiet operation for undisturbed sleep.
5.3. Smart Features
The appliance is equipped with intelligent sensors and Plasmacluster technology for optimized performance.
5.3.1. 4 Sensors
Four sensors (temperature, water level, load weight, and vibration) work together to detect the washing conditions and select the optimal operating pattern, contributing to energy savings.
Figure 12: Four sensors for smart operation.
5.3.2. Plasmacluster Technology
Plasmacluster ions help to refresh clothes, remove odors, and suppress static electricity, even for items that cannot be washed with water, such as shoes and stuffed animals.
Figure 13: Plasmacluster for refreshing non-washable items.
6. Maintenance
Regular maintenance ensures optimal performance and extends the lifespan of your appliance. The ES-K10B-WL features several automatic cleaning functions.
6.1. Automatic Drying Duct Cleaning
Lint and detergent residue that accumulate in the drying duct and exhaust port are automatically washed away with water during the next wash cycle, preventing a decrease in drying efficiency.
Figure 14: Automatic Drying Duct Cleaning mechanism.
6.2. Automatic Tub Cleaning
The back of the washing tub is automatically washed with water during each rinse cycle, keeping unseen areas clean and hygienic.
Figure 15: Automatic Tub Cleaning process.
6.3. Water Pump System for Detergent
This system allows for easy maintenance by automatically dispensing liquid detergent and fabric softener once registered. Simply press the start button for daily washing.
Figure 16: Water Pump System for convenient detergent management.
7. Troubleshooting
If you encounter any issues with your Sharp ES-K10B-WL, please refer to the following common troubleshooting tips before contacting customer support.
- Appliance does not start: Check if the power cord is securely plugged in. Ensure the door is properly closed and latched. Verify that the water supply is turned on.
- Excessive noise or vibration: Ensure the appliance is level and all transit bolts (if applicable) have been removed. Check if the load is balanced inside the drum.
- Water leakage: Inspect water inlet and drain hoses for secure connections and damage. Check the detergent dispenser for blockages.
- Clothes not drying properly: Ensure the lint filter is clean. Check if the drying duct is clear (automatic cleaning should help, but manual check might be needed if issues persist). Do not overload the dryer.
- Error codes: Refer to the specific error code in the full instruction manual for detailed solutions.
If the problem persists after trying these steps, please contact Sharp customer support.
8. Specifications
| Feature | Specification |
|---|---|
| Brand | Sharp(SHARP) |
| Model Number | ESK10BWL |
| Product Dimensions (D x W x H) | 73.2 x 64.5 x 110 cm |
| Product Weight | 71 Kilograms |
| Capacity | 10 Kilograms (Wash) / 6 Kilograms (Dry) |
| Color | Crystal White |
| Control Type | Knob, Touch |
| Access Location | Front |
| Maximum Depth with Door Open | 124.2 Centimeters |
| Wash Dispenser Option | Detergent |
| Sensors | 4 sensors (Temperature, Water Level, Weight, Vibration) |
| Special Features | Plasmacluster, Easy design |
| Operating Noise (Wash/Spin/Dry) | 26dB / 39dB / 41dB |
| Included Components | Instruction manual, Warranty card |
9. Warranty and Support
Your Sharp ES-K10B-WL Drum Type Washer Dryer comes with a manufacturer's warranty. The maximum warranty period is 1 year, based on the provisions stated in the warranty card included with your appliance.
For technical support, service requests, or warranty claims, please refer to the contact information provided in your warranty card or visit the official Sharp website for your region.
Please retain your proof of purchase for warranty validation.
