1. Introduction
Thank you for choosing the SCHOCK Signus 2-Bowl Kitchen Sink. This manual provides essential information for the safe installation, proper operation, and effective maintenance of your new sink. Please read these instructions carefully before installation and retain them for future reference.
The SCHOCK Signus sink is crafted from our patented CRISTADUR® material, known for its exceptional durability, impact resistance, and ease of cleaning. Its silky-smooth finish and intense colors are designed to withstand daily use and maintain their premium appearance for the lifetime of your kitchen.
This image shows the SCHOCK Signus 2-Bowl Kitchen Sink in Silverstone, featuring two distinct basins and a modern faucet, integrated seamlessly into a dark kitchen countertop.
2. Safety Information
Please observe the following safety precautions during installation and use:
- Always ensure the water supply is turned off before beginning any installation or maintenance work.
- Use appropriate personal protective equipment (e.g., gloves, safety glasses) during installation.
- Ensure the countertop material is suitable and adequately supported to bear the weight of the sink and its contents.
- Avoid placing extremely hot items directly into the sink without protection, although Cristadur is highly heat-resistant, extreme thermal shock can be damaging.
- Do not use abrasive cleaners or harsh chemicals that could damage the sink's surface.
3. Setup & Installation
The SCHOCK Signus sink is designed for built-in (top-mount) installation. Professional installation is recommended.
3.1. Pre-Installation Checks
- Verify all components are present: sink, mounting accessories, and drain fittings.
- Ensure the countertop opening matches the specified cut-out dimensions.
- Confirm adequate space for plumbing connections beneath the sink.
3.2. Installation Steps
- Prepare the Countertop: Create a cut-out in the countertop according to the provided template or the standard cut-out dimensions (840 x 480 mm). Ensure edges are smooth and sealed if necessary.
- Apply Sealant: Apply a bead of silicone sealant around the edge of the sink opening on the countertop to create a watertight seal.
- Position the Sink: Carefully lower the sink into the prepared opening. Ensure it is centered and aligned correctly.
- Secure the Sink: Attach the mounting clips (provided with accessories) to the underside of the sink and tighten them against the countertop to secure the sink firmly in place.
- Install Drain Fittings: Connect the drain assemblies to both bowls of the sink. Ensure all connections are tight and sealed to prevent leaks.
- Connect Plumbing: Connect the sink's drain to your household plumbing system. Install the faucet according to its manufacturer's instructions.
- Test for Leaks: Turn on the water supply and fill the sink bowls. Check all connections for any signs of leakage.
This diagram illustrates the precise dimensions for the SCHOCK Signus N200 sink, including overall measurements (860x500mm), bowl sizes (348x352x170mm and 405x430x195mm), and recommended cut-out for top-mount installation (840x480mm).
4. Operating Instructions
Using your SCHOCK Signus sink is straightforward. It is designed for everyday kitchen tasks, including washing dishes, preparing food, and general cleaning.
- Water Temperature: The Cristadur material is highly resistant to high temperatures. However, avoid sudden and extreme temperature changes (thermal shock) by running cold water when pouring boiling liquids into the sink.
- Drainage: Ensure the drain stoppers are properly seated to hold water and removed completely for efficient drainage.
- Food Preparation: The non-porous surface of Cristadur makes it hygienic for food preparation. Always clean the sink thoroughly after use.
5. Maintenance & Care
The CRISTADUR® material is exceptionally easy to clean and maintain, thanks to its anti-dirt effect and smooth surface. Regular cleaning will preserve its appearance and hygiene.
5.1. Daily Cleaning
- Wipe the sink with a soft cloth or sponge and a mild dish soap solution after each use.
- Rinse thoroughly with clean water and dry with a soft cloth to prevent water spots, especially in hard water areas.
5.2. Stain Removal
- For stubborn stains, use a non-abrasive liquid cleaner specifically designed for granite or composite sinks.
- Apply the cleaner, let it sit for a few minutes (as per product instructions), then scrub gently with a soft brush or sponge.
- Rinse thoroughly and dry. Avoid using steel wool, abrasive pads, or harsh chemical cleaners (e.g., drain cleaners containing strong acids or alkalis) as these can damage the surface.
5.3. Preventing Damage
- Avoid dropping heavy or sharp objects into the sink, which could cause chips or cracks.
- Do not use the sink as a cutting surface.
- Rinse away food residues promptly to prevent staining, especially from highly pigmented foods like coffee, tea, or red wine.
6. Troubleshooting
Here are solutions to common issues you might encounter:
| Problem | Possible Cause | Solution |
|---|---|---|
| Water spots/Limescale buildup | Hard water deposits | Regularly dry the sink after use. For existing spots, use a mild descaling agent (e.g., vinegar solution) and rinse thoroughly. |
| Faint stains | Food residues, mineral deposits | Clean with a non-abrasive composite sink cleaner. For deeper stains, a paste of baking soda and water can be gently applied and rinsed. |
| Slow drainage | Clogged drain | Clear the drain trap. Avoid pouring grease down the drain. Use a non-chemical drain opener if necessary, following product instructions carefully. |
| Leaking around connections | Loose fittings, improper sealant | Check and tighten all plumbing connections. Reapply silicone sealant if the leak is from the sink's edge. If issues persist, consult a plumber. |
7. Specifications
| Feature | Detail |
|---|---|
| Model Number | SIGN200A91 |
| Overall Dimensions (L x W) | 860 x 500 mm |
| Large Bowl Dimensions (L x W x D) | 405 x 430 x 195 mm |
| Small Bowl Dimensions (L x W x D) | 348 x 352 x 170 mm |
| Minimum Base Cabinet Size | 900 mm |
| Standard Cut-out Dimensions (L x W) | 840 x 480 mm |
| Material | CRISTADUR® (up to 75% natural quartz sand, acrylic resins, pigments) |
| Color | Silverstone |
| Installation Type | Built-in (Top-mount) |
| Special Features | Prohygenic 21 (natural antibacterial), easy to clean, stain-resistant, impact-resistant, high-temperature resistant |
8. Warranty Information
SCHOCK Cristadur® sinks come with a standard 5-year warranty. This warranty can be extended up to 15 years.
To qualify for the extended warranty, your CRISTADUR® sink must have been purchased and installed after April 1, 2022. You must register your product online on the official SCHOCK website within 6 months of the purchase date.
Please retain your proof of purchase for warranty claims. The warranty covers manufacturing defects and material flaws under normal household use. It does not cover damage caused by improper installation, misuse, abuse, or failure to follow care instructions.
9. Support & Contact
If you have any questions, require technical assistance, or need to make a warranty claim, please contact SCHOCK customer support.
- Visit the official SCHOCK website for contact details and FAQs.
- Refer to your purchase documentation for specific regional support information.
Please have your model number (SIGN200A91) and purchase date ready when contacting support.
