1. Introduction
Thank you for choosing the Aipsun HT009 Dimmable LED Table Lamp. This portable and versatile lamp is designed to provide adjustable lighting for various indoor and outdoor settings. Featuring a durable aluminum construction, a powerful rechargeable battery, and intuitive touch controls, it offers convenience and functionality.
Please read this manual thoroughly before use to ensure proper operation and to maximize the lifespan of your product. Keep this manual for future reference.
2. Package Contents
Verify that all items are present in your package:
- 1 x Aipsun HT009 LED Table Lamp (Black)
- 1 x USB Type-C Charging Cable (5V 1A)
- 1 x User Manual
3. Product Overview
Familiarize yourself with the components of your Aipsun HT009 LED Table Lamp.
This image displays the Aipsun HT009 LED Table Lamp in black, highlighting its ability to produce three distinct light colors: warm white, neutral white, and cool white.
This detailed diagram illustrates the key components of the Aipsun HT009 lamp, pointing out the 34 LEDs with 3 color options, the touch-sensitive power/dimming button, the Type-C charging port, the internal battery, and the non-slip carbon fiber base.
- Touch Control Panel: Located on the top of the lamp shade for power, brightness, and color temperature adjustments.
- LED Light Source: Integrated LED array providing efficient illumination.
- USB Type-C Charging Port: For recharging the internal battery.
- Non-slip Base: Provides stability and prevents accidental movement.
- Aluminum Body: Durable and waterproof (IP54 rated) construction.
4. Charging Instructions
The Aipsun HT009 lamp features a built-in 5500mAh lithium-ion battery. Ensure the lamp is fully charged before its first use.
This image illustrates the charging status of the lamp, with a red indicator for active charging and a green indicator when charging is complete. It also highlights the 5500mAh battery capacity, providing 12 to 48 hours of operation depending on brightness.
- Connect the provided USB Type-C charging cable to the lamp's charging port.
- Connect the other end of the cable to a compatible USB power adapter (5V 1A to 2A recommended). Using an adapter outside this range may damage the battery.
- The indicator light on the top of the lamp will glow red while charging.
- Once fully charged (approximately 5-6 hours), the indicator light will turn green.
- A full charge provides 12 to 48 hours of operation, depending on the selected brightness level.
Battery Maintenance:
- To preserve battery life, charge and discharge the lamp at regular intervals if it will not be used for an extended period.
- Avoid overcharging or completely draining the battery frequently.
5. Operating Instructions
The Aipsun HT009 lamp features intuitive touch controls on its top panel.
This image visually represents the lamp's adjustable color temperature feature, ranging from a warm 2700K to a cool 6000K, allowing users to customize the lighting to their preference.
- Power On/Off: Single-tap the touch control panel to turn the lamp on. Double-tap to turn the lamp off.
- Adjust Color Temperature: When the lamp is on, single-tap the touch control panel to cycle through the three color temperature modes:
- 2700K (Warm White)
- 4000K (Neutral White)
- 6000K (Cool White)
- Adjust Brightness (Dimming): When the lamp is on, press and hold the touch control panel to smoothly adjust the brightness level from 10% to 100%. Release when the desired brightness is reached.
- Memory Function: The lamp will remember the last brightness and color temperature setting used when turned off and will resume these settings when turned back on.
6. Placement and Usage
The Aipsun HT009 lamp's IP54 waterproof rating and wireless design make it suitable for a variety of environments.
The image depicts the Aipsun HT009 lamp outdoors, emphasizing its IP54 rating for protection against splashing water, wind, snow, and sun, making it suitable for various environments.
- Indoor Use: Ideal for dining tables, bedrooms, living rooms, offices, and bars.
- Outdoor Use: Perfect for patios, gardens, balconies, and picnics. The IP54 rating protects against dust ingress and water splashes from any direction.
- Ensure the lamp is placed on a stable, flat surface to prevent tipping.
7. Care and Maintenance
- Cleaning: Wipe the lamp with a soft, dry, or slightly damp cloth. Do not use abrasive cleaners, solvents, or harsh chemicals, as these may damage the finish.
- Storage: If storing the lamp for an extended period, ensure it is fully charged and then partially discharged (to about 50%) to maintain battery health. Store in a cool, dry place.
- Water Exposure: While IP54 rated, avoid immersing the lamp in water or exposing it to heavy, continuous rainfall.
8. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Lamp does not turn on. | Battery is depleted. | Charge the lamp using the provided USB Type-C cable and a 5V 1A-2A adapter. |
| Lamp does not charge. | Incorrect charging cable or adapter. Damaged cable/port. | Ensure you are using the provided USB Type-C cable and a 5V 1A-2A power adapter. Check the cable and port for any visible damage. |
| Short battery life. | Frequent use at high brightness. Battery degradation over time. | Reduce brightness for longer operation. Ensure regular charging/discharging cycles for optimal battery health. |
| Light flickers or is inconsistent. | Low battery. Internal fault. | Charge the lamp fully. If the issue persists, contact customer support. |
9. Specifications
| Feature | Detail |
|---|---|
| Brand | Aipsun |
| Model | HT009 |
| Dimensions (L x W x H) | 10.7 x 10.7 x 36.5 cm |
| Weight | 1.2 Kilograms |
| Battery | 1 Lithium-ion, 5500 mAh (included) |
| IP Rating | IP54 |
| Material | Aluminum |
| Light Source | LED |
| Power | 3 Watts |
| Luminous Flux | 316 lm |
| Color Temperature | 2700K, 4000K, 6000K (adjustable) |
| Color Rendering Index (CRI) | 84.00 |
| Average Lifespan | 15000 Hours |
| Input Voltage | 5 Volts (DC) |
| Special Features | Dimmable (10-100%), Touch Control, Memory Function, Portable, Wireless |
This image displays the EU Energy Label for the Aipsun HT-009 LED Table Lamp, indicating its energy efficiency class A and 3 kWh/1000h consumption. For more detailed information, please visit the EPREL database.
10. Warranty and Support
Aipsun is committed to providing high-quality products and excellent customer service.
- Professional After-Sales Support: If you have any questions or encounter issues after purchasing your Aipsun LED table lamp, please contact us directly. Our team aims to respond and resolve your problem within 24 hours.
- Spare Parts Availability: Spare parts for this product are available for up to 2 years from the date of purchase.
For support, please refer to the contact information provided with your purchase or visit the official Aipsun website.
11. Safety Information
Please observe the following safety precautions to prevent injury or damage to the product:
- Do not disassemble, repair, or modify the lamp yourself. This may void the warranty and pose safety risks.
- Use only the provided USB Type-C charging cable and a compatible 5V 1A-2A power adapter. Using an incompatible charger may damage the battery or cause a fire hazard.
- Keep the lamp away from extreme temperatures, direct sunlight, and open flames.
- Although the lamp is IP54 rated (splash-proof), do not immerse it in water or expose it to heavy rain.
- Keep out of reach of children and pets.
- If the lamp shows any signs of damage or malfunction, discontinue use immediately and contact customer support.
