Beurer IH 24 Kids Nebulizer User Manual

1. Introduction

The Beurer IH 24 Kids Nebulizer is a medical device designed for the gentle and effective nebulization of liquid medications. It is intended for the treatment of upper and lower respiratory tract conditions such as colds, asthma, and other respiratory illnesses. This device is suitable for use by children aged 6 months and older, under adult supervision for infants and independently for children aged 12 and above. Its compressor-based compressed air technology ensures a high nebulization capacity, producing very fine particles that quickly transport active ingredients deep into the lungs.

The child-friendly 'Dr. Dog' design makes inhalation a more pleasant experience for children. The device includes soft silicone masks for sensitive skin, suitable for both babies and older children.

2. Important Safety Information

Please read this entire instruction manual carefully before using the Beurer IH 24 Kids Nebulizer. Keep these instructions for future reference. Failure to follow these instructions may result in injury or damage to the device.

• This device is not a toy. Always supervise children during use.
• Use only medications prescribed by a doctor. Consult your doctor or pharmacist regarding suitable medications and their viscosity.
• Do not use the device in the presence of flammable anesthetic mixtures with air, oxygen, or nitrous oxide.
• Ensure the device is placed on a stable, flat surface during operation.
• Do not immerse the main unit in water or other liquids.
• Regularly clean and disinfect all accessories as described in the 'Maintenance and Cleaning' section to prevent infection.
• Replace the air filter regularly to ensure optimal performance and hygiene.
• Keep the power cord away from hot surfaces.
• If you experience any discomfort or adverse reactions during inhalation, stop use immediately and consult a medical professional.

3. Package Contents

Verify that all items are present and undamaged upon unpacking:

• Beurer IH 24 Kids Nebulizer unit
• Nebulizer cup
• Air hose
• Mouthpiece
• Child silicone mask
• Baby silicone mask
• Angled connector
• 10 replacement filters
• Storage bag
• Instruction manual

4. Product Overview

The Beurer IH 24 Kids Nebulizer features a compact design and efficient nebulization technology for effective respiratory therapy. Key features include:

• Compressor Technology: Ensures high nebulization performance for quick treatment.
• Fine Particle Nebulization: Produces particles of approximately 3.07 µm for deep lung penetration.
• Short Inhalation Time: Efficient delivery of medication reduces treatment duration.
• Child-Friendly Design: 'Dr. Dog' shape encourages children's cooperation during therapy.
• Soft Silicone Masks: Two masks (child and baby) are included, designed for comfort and sensitive skin, and are heat-resistant for sterilization.

5. Setup

Follow these steps for initial setup before first use and before each treatment:

1. Clean and Disinfect: Before first use, and after each subsequent use, clean and disinfect all accessories (nebulizer cup, masks, mouthpiece, angled connector, air hose) according to the 'Maintenance and Cleaning' section.
2. Place the Device: Place the main nebulizer unit on a flat, stable surface.
3. Connect Air Hose: Connect one end of the air hose to the air outlet on the nebulizer unit.
4. Assemble Nebulizer Cup: Open the nebulizer cup and pour the prescribed medication into the medication chamber. Do not overfill.
5. Attach Accessories: Close the nebulizer cup securely. Connect the other end of the air hose to the base of the nebulizer cup. Attach the appropriate accessory (mouthpiece, child mask, or baby mask) to the top of the nebulizer cup. If using a mask, you may use the angled connector for better positioning.
6. Connect Power: Plug the power cord into a suitable electrical outlet.

6. Operating Instructions

Once the device is set up and medication is loaded, follow these steps for inhalation:

1. Positioning: Ensure the child is seated comfortably and upright.
2. Start Nebulization: Press the power button on the nebulizer unit to start the compressor. The device will begin to produce a fine mist.
3. Inhale: If using the mouthpiece, instruct the child to place it between their teeth and seal their lips around it, breathing slowly and deeply through their mouth. If using a mask, ensure it fits snugly over the child's nose and mouth, and instruct them to breathe normally.
4. Duration: Continue inhalation until the medication chamber is empty or as directed by your doctor. The nebulization process is designed to be quick.
5. End Treatment: Once the treatment is complete, press the power button to turn off the device.
6. Disconnect Power: Unplug the power cord from the electrical outlet.

7. Maintenance and Cleaning

Proper cleaning and maintenance are crucial for the hygienic and effective operation of your nebulizer. Clean all parts immediately after each use.

7.1 Cleaning

1. Disassemble: Disconnect the air hose, nebulizer cup, mouthpiece, and mask from the main unit.
2. Rinse: Rinse the nebulizer cup, mouthpiece, and masks thoroughly under warm running water.
3. Wash: Wash these components with a mild detergent.
4. Rinse Again: Rinse all parts thoroughly with clean water to remove any detergent residue.
5. Dry: Allow all parts to air dry completely on a clean, dry cloth or paper towel. Do not wipe with a cloth, as this may introduce lint.
6. Main Unit: Wipe the main nebulizer unit with a soft, damp cloth. Do not use abrasive cleaners or immerse the unit in water.

7.2 Disinfection

For thorough disinfection, especially for the silicone masks, you can sterilize them by boiling in water for 5 minutes. Ensure all parts are completely submerged and do not touch the bottom of the pot. Alternatively, use a cold sterilization solution as per the manufacturer's instructions.

7.3 Filter Replacement

The air filter should be replaced regularly, typically every 10-12 uses or when it appears discolored. The package includes 10 replacement filters.

1. Locate the filter cover on the side of the main unit.
2. Remove the filter cover and carefully pull out the old filter.
3. Insert a new filter, ensuring it sits correctly.
4. Replace the filter cover.

8. Storage

After cleaning and drying all components, store the nebulizer and its accessories in the provided storage bag. Keep the device in a clean, dry place, away from direct sunlight and extreme temperatures. Ensure the air hose is not kinked during storage.

9. Troubleshooting

If you encounter any issues with your Beurer IH 24 Kids Nebulizer, refer to the table below for common problems and solutions:

10. Technical Specifications

• Model: IH 24 Kids (T2Y5-K2124)
• Brand: Beurer
• Nebulization Capacity: Approx. 0.35 ml/min
• Particle Size: Approx. 3.07 µm
• Dimensions (L x W x H): 23.5 x 23.1 x 23 cm
• Weight: 0.1 grams (main unit, without accessories)
• Power Supply: Mains operated (specific voltage/frequency not provided, refer to device label)
• Operating Conditions: (Refer to device label for specific temperature/humidity ranges)
• Storage Conditions: (Refer to device label for specific temperature/humidity ranges)

11. Warranty and Support

The Beurer IH 24 Kids Nebulizer comes with a 5-year warranty from the date of purchase. Please retain your proof of purchase for warranty claims.

For technical support, warranty claims, or further information, please contact Beurer customer service. Contact details can typically be found on the official Beurer website or on the product packaging.
