Product Overview
The Haotao 40 cm LED Lamp with Motion Sensor is a versatile, battery-powered lighting solution designed for various indoor applications. It features a highly sensitive motion sensor, adjustable color temperature, stepless dimming, and multiple lighting modes, making it ideal for kitchens, wardrobes, hallways, and more. Its wireless design and USB rechargeable battery offer convenience and flexibility.
Image: Overview of the Haotao LED Lamp, showing its sleek design and the three available color temperatures.
Key Features
- Highly Sensitive Motion Sensor: Detects human movement by temperature changes, activating the light for 20 seconds after detection. The sensor can be adjusted from 0° to 270° for optimal coverage.
- Adjustable Color Temperature: Offers three color modes: Cool White (6500K), Warm White (2800K), and Mixed White (4000K).
- Stepless Dimming: Brightness can be adjusted continuously to suit various lighting needs.
- Four Lighting Modes: Includes two motion sensor modes (Night Sensor, All-day Sensor) and two normal modes (Always On, Off).
- Built-in Rechargeable Battery: 3500 mAh battery, easily charged via USB, providing up to 60-90 days of use in motion sensor mode.
- Wireless and Easy Installation: No cables or sockets required, features strong built-in magnets for simple mounting.
Image: Visual representation of the product's key features and versatile applications in different home areas.
Setup and Installation
Follow these steps to set up your Haotao LED Lamp:
- Charge the Battery: Before first use, fully charge the built-in 3500 mAh battery using the provided USB cable. The charging indicator will change when fully charged.
- Choose Installation Location: Select a suitable location such as under cabinets, inside wardrobes, along hallways, or near stairs. Ensure the surface is clean and dry.
- Mount the Light:
- Adhesive Mounting: Peel off the protective film from the adhesive pad on the metal mounting bracket. Stick the bracket firmly to the desired surface.
- Magnetic Attachment: The LED lamp has strong built-in magnets. Once the metal mounting bracket is in place, simply attach the lamp magnetically to the bracket.
- Adjust Sensor Angle: Rotate the motion sensor head (0° to 270°) to optimize detection range for your specific area.
Image: Step-by-step guide illustrating the simple installation process using adhesive and magnetic attachment.
Image: Illustration of the rotatable motion sensor and its effective detection area.
Operating Instructions
The Haotao LED Lamp offers various modes and adjustments for optimal lighting control.
Lighting Modes
The lamp features four distinct lighting modes, selectable via a control button:
- Constant Light Mode: The light remains continuously on. Ideal for use as a torch or camping light.
- Night Sensor Mode: The light activates only when motion is detected in a dark environment. It turns off automatically after approximately 20 seconds of no motion.
- All-day Sensor Mode: The light activates when motion is detected, regardless of ambient light conditions. It turns off automatically after approximately 20 seconds of no motion.
- Off Mode: The light is completely off.
Image: Visual guide to the different operating modes of the LED lamp.
Color Temperature Adjustment
Short press the 'S1' button to cycle through the three color temperature options:
- Warm Light (2800K): Provides a cozy, yellowish glow.
- Warm White (4000K): A balanced, neutral white light.
- White Light (6500K): A bright, cool white light.
Brightness Adjustment (Stepless Dimming)
Long press the 'S1' button to adjust the brightness continuously. Release the button when the desired brightness level is reached.
Image: Demonstrates the adjustable color temperatures and stepless dimming capabilities of the lamp.
Maintenance
Proper maintenance ensures the longevity and optimal performance of your Haotao LED Lamp.
- Cleaning: Wipe the lamp surface with a soft, dry cloth. Do not use abrasive cleaners or solvents, as they may damage the finish.
- Charging: Recharge the battery when the light dims or stops responding. Use the provided USB cable and a standard USB power adapter (not included). Avoid overcharging for extended periods.
- Storage: If storing the lamp for a long time, ensure it is fully charged and store it in a cool, dry place. Recharge every 3-6 months to maintain battery health.
- Environmental Conditions: Avoid exposing the lamp to extreme temperatures, high humidity, or direct water contact. This product is designed for indoor use only.
Troubleshooting
If you encounter issues with your Haotao LED Lamp, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not turn on. | Battery is low or depleted. | Charge the lamp fully using the USB cable. |
| Motion sensor not detecting. | Sensor angle is incorrect or obstructed. | Adjust the sensor head to cover the desired area. Ensure no objects are blocking the sensor. |
| Light turns on unexpectedly or stays on. | Sensor is in All-day mode or detecting constant movement. | Switch to Night Sensor mode if you only want it to activate in darkness. Ensure there is no continuous motion in the detection zone. |
| Brightness or color temperature cannot be adjusted. | Incorrect button press or mode. | Ensure you are long-pressing for brightness and short-pressing for color temperature. Check if the lamp is in a mode that allows these adjustments. |
If the problem persists after trying these solutions, please contact customer support.
Specifications
| Feature | Detail |
|---|---|
| Model Number | CT409 |
| Dimensions | 40 x 2.6 x 2.6 cm |
| Weight | 420 grams |
| Battery Capacity | 3500 mAh |
| Light Source | LED |
| Color Temperature | 2800K (Warm), 4000K (Neutral), 6500K (Cool White) |
| Motion Sensor Angle | 0° - 270° adjustable |
| Power Source | Battery Powered (USB Rechargeable) |
| Material | Metal, Plastic |
| Special Features | Energy Efficient, Motion Sensor, Rechargeable, Cordless |
Warranty and Support
Information regarding product warranty and customer support was not provided in the available product data. Please refer to the product packaging or the manufacturer's official website for details on warranty coverage and how to contact support for your Haotao LED Lamp.
