1. Introduction
Thank you for choosing AUXITO 1156 LED Bulbs. These high-performance amber yellow LED bulbs are designed to provide superior brightness and efficiency for various automotive lighting applications. This manual provides essential information for proper installation, operation, and maintenance to ensure optimal performance and longevity of your bulbs.
Image 1: AUXITO 1156 LED Bulbs (Amber Yellow)
What's in the Box:
- 1156 LED Amber Bulbs (Quantity as per package)
2. Features
- Enhanced Brightness: Resembling halogen bulb shape design and sequencing 54 4014-SMD LED chips precisely around the 1156 LED amber bulb. Delivers 360° high luminous efficiency with full amber yellow light, providing clearer and safer visibility.
- Efficient Power Consumption: Each 1156 amber bulb consumes 5.5W, which is approximately 1/4 the energy consumption of an original halogen bulb, while being 4 times brighter.
- Integrated IC Driver: Built-in smart IC driver ensures constant current, preventing radio interference.
- Instant-On Capability: Provides immediate illumination with zero warm-up time.
- Durable Construction: Features an electroplating process housing to improve oxidation resistance and reduce heat generation, contributing to a longer lifespan of over 30,000 hours.
- Unique Concave Design with Projector Lens: The high-grade shape and HD projector lens ensure stronger light penetration and a focused beam.
- Dual Brightness Mode: Operates in a dim mode for tail/running/parking lights and a bright mode for brake/turn signal/reverse lights.
Image 2: 360° Full Angle Illumination
Image 3: Low Consumption, High Output
Image 4: Electroplating Body for Heat Dissipation
Image 5: Unique Concave Design with HD Projector Lens
Image 6: Dual Brightness Functionality
3. Compatibility
These AUXITO 1156 LED bulbs are designed to be non-polarity, making them compatible with both US standard and CK sockets. They are suitable replacements for the following bulb types:
BA15S, 1156, 7506, 1003, 1141, P21W, 1073, 1093, 1129, 1147, 199, 1159, 1259, 1295, 1383, 1459, 1619, 1651, 1680, 2056, 3496, 5007, 5008, 7008, 7806, 7527, 1759, 3497, etc.
These bulbs can be used for various applications including turn signal bulbs, side marker light bulbs, blinker light bulbs, parking lights, and courtesy step lights.
Note: Vehicle compatibility filters may not always be 100% accurate. Always check your vehicle's owner manual or the existing bulb type to confirm the correct fitment before purchase.
Image 7: Methods to Determine Correct Bulb Size
4. Installation
The AUXITO 1156 LED bulbs feature a plug-and-play design for easy installation. No complex wiring or modifications are typically required.
Installation Steps:
- Locate the existing bulb you wish to replace in your vehicle's light assembly.
- Carefully remove the old bulb by twisting and pulling it out of its socket.
- Insert the new AUXITO 1156 LED bulb into the socket. Due to its non-polarity design, it will work regardless of orientation.
- Test the light function to ensure proper operation.
- Secure the light assembly back into its position.
Image 8: Easy Plug & Play Installation
5. Operation
Once installed, your AUXITO 1156 LED bulbs will operate automatically with your vehicle's lighting system. They provide instant, bright amber yellow light for improved visibility.
Image 9: Before and After LED Bulb Installation
6. Maintenance
AUXITO LED bulbs are designed for long-term durability and minimal maintenance. The electroplating process housing and efficient heat dissipation contribute to their extended lifespan of over 30,000 hours.
To maintain optimal performance, ensure the light assembly area is kept clean and free from dirt or debris. No specific maintenance is required for the bulbs themselves.
7. Troubleshooting
While AUXITO LED bulbs are designed for broad compatibility, some vehicles may experience specific issues:
- Hyper Flash or Error Warning: In certain vehicles, especially those with CANBUS systems, installing LED bulbs may cause a rapid flashing (hyper flash) of the turn signals or trigger an error warning on the dashboard. This is due to the lower power consumption of LED bulbs compared to traditional halogen bulbs, which the vehicle's system interprets as a burnt-out bulb.
- Solution: If you encounter hyper flash or error warnings, 50W 6ohm load resistors may be required. These resistors simulate the electrical load of a standard halogen bulb, resolving the issue. Load resistors are typically sold separately.
8. Specifications
| Specification | Detail |
|---|---|
| Brand | AUXITO |
| Model | 1156/7506 |
| Color | Amber Yellow |
| Voltage | 12 Volts (DC) |
| Power Consumption | 5.5W per bulb |
| LED Chips | 54 x 4014-SMD |
| Beam Angle | 360° |
| Lifespan | 30,000+ Hours |
| Fit Type | Vehicle Specific Fit |
| Item Weight | 1.13 ounces |
| Package Dimensions | 3.62 x 2.72 x 0.94 inches |
9. Warranty and Support
AUXITO is committed to providing high-quality products and excellent customer service.
Warranty:
Your AUXITO LED bulbs are covered by a 365-day replacement warranty. In the unlikely event of product defects, a hassle-free replacement will be provided.
Image 10: 365 Days Replacement Warranty
Customer Support:
Our professional service team is available 24/7 to answer any questions you may have. For technical guidance or support, please contact AUXITO customer service through the retailer's platform or the official AUXITO website.
Image 11: Professional Technical Support
Image 12: Dedicated Customer Support Service
