Molift Raiser Pro Sit to Stand Lift Instruction Manual

1. Product Overview

The Molift Raiser Pro is a transfer platform designed to facilitate standing transfers over short distances. It provides secure and supportive assistance for individuals requiring mobility aid, such as the elderly or handicapped. Its design focuses on ease of use for both the user and caregiver, promoting safe and comfortable movement.

Image 1.1: The Molift Raiser Pro Sit to Stand Lift, a portable stand assist device.

Key Features:

• Safe Transfer Support: Provides secure, supportive stand assist for elderly users. A strap is available as an accessory for additional assistance.
• Compact & Maneuverable: Features an innovative low-profile base (only 1.4" high) and easy-rolling wheels for smooth positioning in tight spaces.
• High Weight Capacity: With a Safe Working Load of up to 375 lbs, this durable device supports a wide range of users.
• Comfortable & Adjustable: Designed for comfort and stability, it features padded, laterally stabilized leg supports and a soft-touch handle with multiple grip positions.
• One-Touch Braking: A central braking system locks both wheels with a single press from either side, helping caregivers stabilize the unit quickly and securely.

2. Safety Information

Read this manual thoroughly before using the Molift Raiser Pro. Failure to follow instructions may result in injury to the user or caregiver. Always ensure the user is capable of bearing some weight and can actively participate in the transfer process.

General Safety Guidelines:

• Always engage the central brake system before initiating a transfer or when the unit is stationary.
• Ensure the user's feet are securely placed on the footplate before standing.
• Adjust the leg supports to provide firm, comfortable contact with the user's shins.
• Maintain clear communication with the user throughout the transfer.
• Never exceed the maximum Safe Working Load of 375 lbs.
• Statements regarding dietary supplements have not been evaluated by the FDA and are not intended to diagnose, treat, cure, or prevent any disease or health condition.

3. Components and Features

The Molift Raiser Pro is designed with several key components to ensure safe and effective transfers:

Image 3.1: Detailed view of the Molift Raiser Pro's versatile handle, swiveling leg support, low base height, central brake system, and adjustable leg support.

• Versatile Handle Design: Soft handle with multiple grips for user and caregiver comfort.
• Swiveling Leg Support: Easy one-hand swivel leg support for optimal positioning.
• Adjustable Leg Support: Padded, adjustable leg support for stability and comfort.
• Low Base Height: Anti-slip base with foot guides, only 1.4 inches high for easy access.
• Central Brake System: One-foot central brake with sound alert, locking both wheels simultaneously.
• Easy-Rolling Wheels: Designed for smooth movement in tight spaces.

4. Setup and Assembly

The Molift Raiser Pro is designed for straightforward assembly. Follow these steps to prepare your device for use.

For detailed visual instructions, please refer to the assembly video above. Ensure all parts are securely fastened before initial use.

5. Operating Instructions

The Molift Raiser Pro facilitates safe and active transfers. Always ensure the user is comfortable and secure throughout the process.

Transferring a User:

1. Positioning: Place the Molift Raiser Pro in front of the user, ensuring the low-profile base is close to their feet. Engage the central brake.
2. Foot Placement: Guide the user's feet onto the footplate, ensuring they are flat and secure.
3. Leg Support Adjustment: Adjust the padded leg supports so they gently but firmly contact the user's shins.
4. Grip: Instruct the user to grasp the handle firmly. The caregiver should also hold the handle for support.
5. Standing: Encourage the user to lean forward and push up to a standing position, using their own strength as much as possible, while the caregiver provides support and stability.
6. Release Brake: Once the user is standing and stable, release the central brake.
7. Movement: Gently maneuver the Molift Raiser Pro to the destination (e.g., wheelchair, shower chair). The easy-rolling wheels facilitate smooth movement.
8. Sitting: Once positioned, engage the central brake. Guide the user to slowly lower themselves into the new seating surface, maintaining a firm grip on the handle.
9. Remove Device: Once the user is safely seated, disengage the leg supports and move the Molift Raiser Pro away.

Image 5.2: The Molift Raiser Pro aids in early mobilization and daily rehabilitation, ensuring natural movement and posture.

6. Maintenance

Regular maintenance ensures the longevity and safe operation of your Molift Raiser Pro.

• Cleaning: Wipe down all surfaces with a mild, non-abrasive cleaner and a soft cloth. Avoid harsh chemicals that may damage materials.
• Inspection: Periodically check all bolts, screws, and moving parts for tightness and wear. Tighten any loose fasteners.
• Wheel Functionality: Ensure wheels roll freely and the brake system engages effectively. Clean any debris from the wheels.
• Storage: Store the device in a dry, clean environment when not in use. The compact design allows for easy storage.

7. Troubleshooting

If you encounter any issues with your Molift Raiser Pro, refer to the following common troubleshooting tips:

• Difficulty Rolling: Check for debris in the wheels. Ensure the brake is fully disengaged.
• Unstable During Transfer: Verify the central brake is engaged when stationary. Ensure leg supports are properly adjusted and the user has a firm grip.
• Unusual Noises: Inspect all moving parts for any obstructions or loose components. Contact customer support if the noise persists.

For issues not covered here, please contact Molift customer support.

8. Specifications

9. Warranty and Support

For warranty information and customer support, please refer to the documentation included with your Molift Raiser Pro or visit the official Molift website. Contact details for support are typically provided in the product packaging.
