NEEWER Magnetic ND/CPL Filter Set Instruction Manual

Introduction

This manual provides detailed instructions for the NEEWER Magnetic ND/CPL Filter Set, designed for use with DJI Osmo Pocket 3, Pocket 4, and Xtra Muse cameras. This set includes various filters to optimize your camera's performance in diverse lighting conditions, enhancing image quality and creative control.

What's in the Box

The NEEWER Magnetic ND/CPL Filter Set includes the following components:

• 1 x Magnetic ND16/PL Filter
• 1 x Magnetic ND32/PL Filter
• 1 x Magnetic ND64/PL Filter
• 1 x Magnetic ND256/PL Filter
• 1 x Magnetic UV Filter
• 1 x Magnetic CPL Filter
• 1 x Filter Case
• 1 x Cleaning Cloth

Image: Contents of the NEEWER Magnetic ND/CPL Filter Set, showing all six filters neatly arranged in their protective case, alongside a cleaning cloth.

Setup

The filters feature a magnetic design for quick and secure attachment to your DJI Osmo Pocket 3, Pocket 4, or Xtra Muse camera lens.

1. Ensure your camera lens is clean and free of dust or debris.
2. Select the desired filter from the protective case.
3. Align the magnetic filter with the camera lens. The filter will snap securely into place.
4. The lightweight aluminum frame (0.06oz/1.62g each) is designed to fit seamlessly without impacting gimbal calibration or storage.

Image: A hand demonstrating the magnetic attachment of a NEEWER filter to a DJI Osmo Pocket 3 camera.

Image: A close-up view illustrating the strong magnetic attraction between the filter and the camera lens, ensuring rapid and secure changes.

Image: The lightweight, form-fitting design of the filter on a DJI Osmo Pocket 3, emphasizing that it does not affect gimbal alignment or power control.

Operating the Filters

Each filter type serves a specific purpose to enhance your photography and videography:

ND/PL Filters (ND16/PL, ND32/PL, ND64/PL, ND256/PL)

These filters combine Neutral Density (ND) and Polarizing (PL) functions. They reduce the amount of light entering the camera sensor, allowing for slower shutter speeds and wider apertures, while also minimizing glare and reflections from non-metallic surfaces like water and glass. The different ND values (ND16/PL, ND32/PL, ND64/PL, ND256/PL) reduce light by 4, 5, 6, and 8 stops respectively, offering precise exposure control.

Image: A visual comparison showing the effect of an ND/PL filter versus a standard ND filter, highlighting reduced glare and enhanced color in water.

Image: A landscape scene demonstrating the light reduction capabilities of ND16/PL (4 stops), ND32/PL (5 stops), ND64/PL (6 stops), and ND256/PL (8 stops) filters.

CPL Filter

The Circular Polarizing (CPL) filter helps to reduce glare and unwanted reflections from surfaces such as water, glass, and non-metallic objects. It also enhances color saturation and clarity, making skies bluer and foliage greener. Rotate the filter to adjust the polarization effect.

UV Filter

The Ultraviolet (UV) filter shields your lens from scratches, dust, and harmful UV rays. It helps to reduce atmospheric haze and improves overall image sharpness and contrast, especially in outdoor environments.

Image: A split image showing the effect of a CPL filter on water reflections (reducing glare) and a UV filter on a landscape (improving clarity and reducing haze).

Official Product Videos

Maintenance

To ensure the longevity and optimal performance of your NEEWER filters, follow these maintenance guidelines:

• Cleaning: Use the provided cleaning cloth to gently wipe the filter surfaces. For stubborn smudges, use a lens cleaning solution specifically designed for optical glass.
• Storage: Always store the filters in their dedicated filter case when not in use to protect them from dust, scratches, and impacts.
• Handling: Avoid touching the optical glass surfaces directly with your fingers to prevent oil and fingerprint smudges.
• Durability: The filters feature 30 layers of multi-functional coatings, making them water repellent, scratch resistant, and oil proof.

Image: A detailed diagram showcasing the multi-layered coating structure of the HD optical glass, highlighting its water and oil repellent, anti-reflective, and light reduction properties.

Troubleshooting

Please observe the following reminders to avoid potential issues:

• When using wide-angle/macro lenses or ND, CPL filters, do not apply any protective film to the camera lens.
• When attached to the Pocket 3, the wide-angle lens cannot be used together with ND, CPL, or other filters.

Specifications

Warranty and Support

This NEEWER product comes with a 1 Year Manufacturer Warranty. For support or warranty claims, please contact NEEWER customer service directly.
