Rollei Quick-Parabol 45 cm Softbox Instruction Manual

Introduction

The Rollei Quick-Parabol 45 cm Softbox is designed to provide versatile lighting solutions for photography. Its parabolic shape, combined with an internal silver coating, delivers both soft, natural light and contrast-rich illumination for impressive shots. Featuring a quick-assembly design and a Bowens S-type mount, this softbox is an essential tool for professional and amateur photographers alike.

This manual provides detailed instructions for the proper setup, operation, and maintenance of your Rollei Quick-Parabol 45 cm Softbox.

Safety Instructions

• Always ensure the softbox is securely attached to your light source and stand before use.
• Do not expose the softbox to excessive heat or open flames.
• Avoid using the softbox in wet or damp conditions as it is not water-resistant.
• Keep out of reach of children.
• Handle with care to prevent damage to the fabric and internal components.

Package Contents

Please check that all items are present in your package:

• 1x Rollei Quick-Parabol 45 cm Softbox
• 1x Honeycomb Grid
• 2x Diffusers (Inner and Outer)
• 1x Carry Bag

Image: The Rollei Quick-Parabol 45 cm Softbox in use, demonstrating its compact size and light output.

Setup

1. Unfold the Softbox: Remove the softbox from its carry bag. The Quick-Parabol design allows for rapid unfolding. Gently push the central hub until the rods click into place, forming the parabolic shape.
2. Attach to Light Source: Align the Bowens S-type mount on the softbox with your compatible studio flash or LED light. Insert the mount and rotate clockwise until it locks securely.


Image: Demonstrating the attachment of the softbox to a light source using the Bowens S-type mount.

3. Install Diffusers (Optional): For softer, more diffused light, attach the inner diffuser first using the internal Velcro tabs. Then, attach the outer diffuser to the front edge of the softbox using its Velcro strips.


Image: The softbox with the outer diffuser installed, ready for use to create soft, even lighting.

4. Attach Honeycomb Grid (Optional): For more controlled and directional light, attach the honeycomb grid to the outer Velcro rim of the softbox. This helps to prevent light spill and create a more focused beam.


Image: The softbox with the honeycomb grid attached, providing precise light control for a portrait.

Operating

The Rollei Quick-Parabol 45 cm Softbox is designed for ease of use once assembled. Its primary function is to modify the light output from your studio flash or LED light.

• Soft Light: For a broad, soft, and even light spread, use both the inner and outer diffusers. This is ideal for portraits, product photography, and general fill light.
• Contrast Light: For more contrast and punch, remove the diffusers. The silver interior lining will reflect light directly, creating more defined shadows and highlights.
• Controlled Light: When precise light direction is needed, attach the honeycomb grid. This narrows the beam of light, reducing spill and allowing for more dramatic lighting effects.

Image: A detailed view of the softbox interior, showing the reflective silver lining and the Bowens mount.

Maintenance

• Cleaning: Gently wipe the exterior fabric with a soft, dry cloth. For stubborn marks, a slightly damp cloth can be used, but ensure the softbox is completely dry before storage. Do not use harsh chemicals or abrasive cleaners.
• Storage: After use, carefully collapse the softbox by releasing the rods. Store it in the provided carry bag to protect it from dust and damage.
• Inspection: Periodically check the rods, fabric, and mounting mechanism for any signs of wear or damage.

Image: The softbox shown in its collapsed state, illustrating its portability and ease of storage.

Troubleshooting

Specifications

Warranty and Support

Rollei stands by the quality of its products. Your Rollei Quick-Parabol 45 cm Softbox comes with the following:

• 24-Month Exchange Guarantee: Enjoy peace of mind with a full 24-month exchange guarantee.
• 2-Year Spare Parts Availability: Spare parts are available for a period of 2 years within the EU.

Customer Support:

Should you require assistance or have any questions, our expert team is available to help.

• Phone Support: +49 40 270 750 277 (Monday - Friday, 10:00 AM - 4:00 PM CET)
• Online Support: Visit the official Rollei website for further support options and contact forms.
