WLIVE ASNG095FG 5-Drawer Fabric Dresser Instruction Manual

1. Introduction

This manual provides detailed instructions for the assembly, operation, and maintenance of your WLIVE ASNG095FG 5-Drawer Fabric Dresser. Please read all instructions carefully before assembly and use to ensure proper function and safety. Keep this manual for future reference.

Image 1.1: The WLIVE ASNG095FG 5-Drawer Fabric Dresser, featuring a floral painted design on its fabric drawers and a sturdy wood top.

2. Safety Information

Please observe the following safety precautions:

• Keep all small parts and packaging materials away from children and pets to prevent choking hazards.
• Ensure all connections are securely tightened before use. Periodically check and re-tighten as necessary.
• Do not overload the drawers or the top surface. Refer to the 'Specifications' section for weight limits.
• Always use the included anti-tilt device to secure the dresser to a wall, preventing accidental tipping.
• Assemble the unit on a soft, clean surface to prevent scratches or damage.

Image 2.1: Illustration of the dresser's sturdy steel frame, anti-tilt device, and adjustable feet, emphasizing stability and safety features.

3. Package Contents

Verify that all components are present before beginning assembly. If any parts are missing or damaged, contact customer support.

Hardware and Tools:

• Screws (various sizes)
• Allen Wrench
• Anti-tilt device components

Main Components:

• Steel Frame (various sections)
• Wood Top Panel
• Fabric Drawers (5 units, 3 small, 2 large)
• Adjustable Feet (4 units)
• Drawer Handles

4. Assembly Instructions

Follow these steps carefully for proper assembly. It is recommended to have two people for certain steps.

Step 4.1: Assemble the Steel Frame

1. Connect the vertical and horizontal steel frame sections using the provided screws and Allen wrench. Ensure all connections are finger-tight initially.
2. Attach the adjustable feet to the bottom of the frame.
3. Once the frame is fully assembled, tighten all screws securely.

Step 4.2: Attach the Wood Top Panel

1. Carefully place the wood top panel onto the assembled steel frame.
2. Secure the wood top panel to the frame using the designated screws.

Image 4.1: Detail of the high-quality wood board top, featuring a protective coating for durability and a textured, water-resistant surface.

Step 4.3: Assemble the Fabric Drawers

1. Unfold each fabric drawer.
2. Insert the bottom MDF board into the base of the drawer to create a rigid structure.
3. Attach the drawer handle to the front of each fabric drawer.

Image 4.2: Visual guide for assembling the fabric drawers, illustrating the three-tier material construction (retro colored fabric, MDF board, quality fabric) and the simple three-step folding process.

Step 4.4: Install Anti-Tilt Device

1. Position the dresser in its desired location.
2. Using the provided hardware, secure the anti-tilt device to the back of the dresser and to a wall stud. This is a critical safety step to prevent tipping.

5. Operating Instructions

The WLIVE ASNG095FG dresser is designed for organized storage in various rooms.

5.1 Drawer Usage

• Gently pull the handles to open the fabric drawers.
• Push the drawers back into the frame until they are fully closed.
• The fabric drawers are removable and foldable for convenience.

5.2 Storage Capacity

Each fabric drawer has a maximum weight capacity of 6.6 lbs. The wood top panel can support up to 50 lbs. Distribute weight evenly to maintain stability.

Image 5.1: The dresser with drawers open, illustrating its storage potential for clothing items like socks (45-50 pairs) and shirts (10-12 items), along with the 6.6 lbs drawer capacity and 50 lbs tabletop capacity.

5.3 Placement

This dresser is suitable for bedrooms, closets, living rooms, hallways, dorms, and offices. It can also serve as a TV stand for small-sized televisions, provided the weight limit of the top panel is not exceeded.

Image 5.2: The dresser positioned in a living room, demonstrating its use as a TV stand, complementing the room's decor.

6. Maintenance and Care

Proper care will extend the life of your dresser.

• Cleaning: Wipe the wood top and steel frame with a dry, soft cloth. For the fabric drawers, spot clean with a damp cloth and mild detergent if necessary, then air dry completely. Do not use harsh chemicals or abrasive cleaners.
• Inspection: Periodically check all screws and connections to ensure they remain tight. Re-tighten as needed.
• Environment: Avoid placing the dresser in direct sunlight or near heat sources to prevent material degradation.

7. Troubleshooting

If you encounter issues, refer to the following common solutions:

8. Specifications

• Brand: WLIVE
• Model Name: ASNG095FG
• Overall Dimensions: 39.4" L x 11.7" W x 25" H (11.7"D x 39.4"W x 25"H)
• Small Drawer Dimensions: 10.9"D x 11.9"W x 8.5"H
• Large Drawer Dimensions: 10.9"D x 18.2"W x 8.5"H
• Number of Drawers: 5 (3 small, 2 large)
• Material: Steel frame, Wood top, Non-woven fabric drawers with MDF board inserts
• Color: Floral Painted
• Item Weight: 27.6 pounds
• Table Top Capacity: 50 lbs
• Drawer Capacity: 6.6 lbs per drawer
• Assembly Required: Yes

Image 8.1: Detailed product size diagram, illustrating the overall dimensions of the dresser (39.4"W x 11.7"D x 25"H) and the dimensions of both small (11.9"W x 10.9"D x 8.5"H) and large (18.2"W x 10.9"D x 8.5"H) fabric drawers.

9. Warranty and Support

For warranty information or customer support, please refer to the documentation included with your purchase or contact WLIVE directly through their official website or customer service channels. Please have your model number (ASNG095FG) and purchase details ready when contacting support.
