Lorelli Mini Max 3-in-1 Convertible Crib Instruction Manual

1. Introduction

This instruction manual provides comprehensive guidance for the safe assembly, operation, and maintenance of your Lorelli Mini Max 3-in-1 Convertible Crib. This versatile furniture piece is designed to adapt to your child's growth, transforming from a baby crib with a changing table into a toddler bed, a desk, and a separate chest of drawers. Please read all instructions carefully before assembly and retain this manual for future reference.

Figure 1.1: Lorelli Mini Max 3-in-1 Convertible Crib (Crib Configuration)

2. Safety Information

WARNING: Failure to follow these warnings and the instructions could result in serious injury or death.

• Always ensure all assembly fittings are tightened correctly. Regularly check all bolts and screws to ensure they are secure.
• Do not use the crib if any parts are broken, torn, or missing. Contact Lorelli for replacement parts.
• The mattress used with this crib must be 120 x 60 x 12 cm. An incorrect mattress size can create gaps where a child's head could become entrapped.
• Do not place the crib near windows where cords from blinds or drapes could strangle a child.
• Do not place items with a string or strap around a child's neck, such as pacifier clips or necklaces, as they can pose a strangulation hazard.
• Do not use this crib for a child who can climb out unassisted or who is taller than 89 cm.
• The maximum recommended weight for the crib is 120 kg.
• Ensure the oscillation function is fixed when the crib is in use, unless actively rocking the child under supervision.

3. Package Contents

Before beginning assembly, verify that all components are present and undamaged. If any parts are missing or damaged, do not proceed with assembly. Contact your retailer or Lorelli customer service.

• Crib frame components (side rails, end panels)
• Mattress support base
• Multifunction chest of drawers components (panels, drawers, changing table top)
• Under-bed storage drawers (2 units)
• Assembly hardware (screws, bolts, dowels, cam locks, etc.)
• Assembly tools (typically Allen key, screwdriver - not always included)

4. Assembly Instructions

Assembly requires two adults. Follow the detailed graphical instructions provided in the separate assembly guide included with your product. The general steps are outlined below:

1. Prepare the Area: Clear a spacious, clean area for assembly. Lay out all components and hardware.
2. Assemble the Crib Base: Attach the side rails to the end panels, ensuring all connections are secure.
3. Install Mattress Support: Insert the mattress support base into the crib frame. Select the desired height level (see Section 5.1).
4. Assemble Chest of Drawers: Construct the chest of drawers according to the separate instructions. Install the drawers and attach the changing table top.
5. Attach Chest to Crib: Securely attach the assembled chest of drawers to the crib frame. The chest can be mounted on either the left or right side of the crib.
6. Assemble Under-Bed Drawers: Construct the two large storage drawers and slide them into position under the crib.
7. Final Checks: Ensure all screws and bolts are tightly fastened. Check for stability and proper alignment of all parts.

Note: Specific hardware and step-by-step diagrams are provided in the dedicated assembly manual.

5. Configuration Options and Operation

The Lorelli Mini Max is designed for versatility, offering multiple configurations to suit your child's needs as they grow.

5.1. Crib with Changing Table

This is the primary configuration for infants. The crib features a mattress support that can be adjusted to two different height levels. The higher level is suitable for newborns, making it easier to access the baby. The lower level is for older infants who can sit up or pull themselves to a standing position, preventing them from climbing out.

• Mattress Height Adjustment: To adjust the mattress height, remove the mattress and carefully detach the mattress support from the side rails. Re-attach it at the desired height, ensuring all four corners are securely fastened.
• Changing Table: The integrated chest of drawers includes a changing table surface. Always use a changing pad and keep one hand on your child during diaper changes.
• Oscillation Function: The crib may feature an oscillation (rocking) function. To engage, unlock the mechanism (refer to assembly guide for specific details). To fix the crib in a stationary position, engage the locking mechanism.

Figure 5.1: Crib Configuration with Changing Table on Left

Figure 5.2: Crib Configuration with Changing Table on Right

5.2. Toddler Bed Conversion

Once your child outgrows the crib, it can be converted into a toddler bed. This involves removing one of the side rails and potentially adjusting the mattress height to the lowest position. The chest of drawers can remain attached or be separated.

1. Remove the front side rail of the crib.
2. Ensure the mattress support is at the lowest setting.
3. If desired, detach the chest of drawers from the bed frame (see Section 5.4).

Figure 5.3: Toddler Bed Configuration

5.3. Desk Conversion

The crib can also be transformed into a functional desk, providing a study or activity space for an older child. This typically involves reconfiguring the crib's end panels and mattress support.

1. Disassemble the crib frame.
2. Reassemble the end panels and mattress support to form a desk structure. The mattress support acts as the desk surface.
3. The chest of drawers will be separated for this configuration.

Figure 5.4: Desk Configuration

5.4. Separate Chest of Drawers

The multifunction chest of drawers can be used independently from the bed configurations. It provides storage and can continue to serve as a changing station or general storage unit.

1. Carefully detach the chest of drawers from the crib/bed frame by unscrewing the connecting hardware.
2. Ensure the chest is stable and level when used as a standalone unit.

6. Maintenance and Care

• Cleaning: Wipe surfaces with a soft, damp cloth and mild soap. Avoid abrasive cleaners or strong chemicals that could damage the melamine finish. Dry thoroughly after cleaning.
• Hardware: Periodically check all screws, bolts, and fasteners to ensure they are tight. Loose hardware can compromise the safety and stability of the furniture.
• Storage: If disassembling for storage, keep all hardware in a sealed bag and store it with the furniture components in a dry, cool place.
• Material: The product is made from high-quality 18mm melamine particle board. Avoid prolonged exposure to direct sunlight or extreme temperature changes to prevent warping or discoloration.

7. Troubleshooting

8. Specifications

• Model: Lorelli Mini Max 3-in-1 Convertible Crib
• Model Number: 10150500041A
• Dimensions (L x W x H): 197 x 83 x 108 cm (77.6 x 32.7 x 42.5 inches)
• Product Weight: 130 kg (286.6 lbs)
• Maximum Weight Recommendation: 120 kg (264.5 lbs)
• Recommended Mattress Size: 120 x 60 x 12 cm (47.2 x 23.6 x 4.7 inches)
• Material: 18mm Melamine Particle Board
• Color: White / Dark Grey
• Safety Standards: Conforms to all European safety standards.
• Assembly Required: Yes

9. Warranty and Support

For warranty information, please refer to the documentation provided at the time of purchase or contact your retailer. Lorelli is committed to product quality and customer satisfaction. For technical support, replacement parts, or any inquiries not covered in this manual, please contact Lorelli customer service through their official website or the contact information provided by your retailer.

Please retain your proof of purchase for warranty claims.
