Introduction
This manual provides essential information for the safe and effective use of your SOLTECH 12V 1A 12W Power Supply Adapter. This AC to DC converter is designed to provide stable 12V power for a variety of compatible electronic devices. Please read this manual thoroughly before use and retain it for future reference.
Image: The SOLTECH 12V 1A 12W Power Supply Adapter, a compact black unit with a standard US plug and a DC barrel connector cable.
Safety Information
To ensure safe operation and prevent damage, observe the following safety guidelines:
- Do not expose the adapter to water, moisture, or extreme temperatures.
- Do not disassemble or attempt to repair the adapter. Refer servicing to qualified personnel.
- Ensure the adapter is used within its specified input and output voltage/current limits.
- Avoid placing the adapter in poorly ventilated areas during operation.
- Disconnect the adapter from the power outlet when not in use for extended periods.
Built-in Safety Features
The SOLTECH power adapter incorporates multiple safety mechanisms to protect your devices:
- Over-Voltage Protection: Safeguards against excessive voltage output.
- Over-Current Protection: Prevents damage from drawing too much current.
- Over-Temperature Protection: Shuts down if internal temperature exceeds safe limits.
- Over-Load Protection: Protects against excessive power draw.
- Short-Circuit Protection: Prevents damage in case of a short circuit.
Image: Visual representation of the adapter's safety features including over-temp, over-current, over-voltage, overload, and short circuit protection.
Certifications
This adapter is certified by UL, FCC, CE, RoHS, SAA, PSE, KC, and CCC, ensuring compliance with high safety and quality standards.
Image: The SOLTECH power adapter displaying its UL Listed mark and other certifications.
Product Overview
Components
- 1 x SOLTECH 12V 1A Power Adapter (Model: 12V1ADUMMY1)
Key Features
- Input: AC 100-240V, 50/60Hz
- Output: DC 12V, 1A (1000mA), 12W (Max)
- DC Connector Size: 5.5mm x 2.1mm (compatible with 5.5mm x 2.5mm)
- DC Cable Length: Approximately 47.25 inches (120 cm)
- Adapter Body Size: Approximately 1.5 x 1.0 x 2.3 inches
- DC Polarity: Inner Positive (+), Outer Negative (-)
Image: Detailed view of the adapter showing its dimensions, DC connector size (5.5mm outer, 2.1mm inner, compatible with 2.5mm), and DC polarity diagram (inner positive, outer negative).
Compatibility
This power adapter is suitable for a wide range of 12V DC devices requiring up to 1000mA (1A) or 12 watts of power. Always verify your device's power requirements and connector size before use.
- CCTV Security Cameras (e.g., Samsung Wisenet, Night Owl, Lorex, Defender, Swann, Q-See)
- DVRs / NVRs
- LED Strip Lights
- Wireless Routers
- Switch Hubs
- LED/LCD Monitors
- Audio Amplifiers
- 3D Printers
- Radio Transceivers
- ADSL Cats
- Bluetooth Speakers
Image: An illustration showing the power adapter surrounded by various compatible devices such as CCTV cameras, DVRs, routers, and LED strip lights.
Setup
- Verify Device Compatibility: Before connecting, confirm that your device requires a 12V DC input and draws no more than 1A (1000mA) of current. Also, ensure your device's power input port matches the adapter's 5.5mm x 2.1mm (or 5.5mm x 2.5mm compatible) barrel connector with inner positive (+) polarity.
- Connect to Device: Insert the DC barrel connector of the power adapter firmly into the power input port of your electronic device.
- Connect to Power Outlet: Plug the AC prongs of the power adapter into a standard 100-240V AC wall outlet.
- Power On Device: Once connected, power on your device. The adapter will automatically supply the necessary power.
Image: The SOLTECH power adapter plugged into a wall outlet and connected to a DVR/NVR unit, demonstrating a typical setup.
Operating Instructions
The SOLTECH 12V 1A 12W Power Supply Adapter is designed for simple plug-and-play operation. Once correctly connected to a compatible device and a power outlet, it will continuously supply stable DC power. No additional configuration is required.
Maintenance
To ensure the longevity and optimal performance of your power adapter:
- Keep the adapter clean and free from dust. Use a soft, dry cloth for cleaning.
- Store the adapter in a cool, dry place when not in use.
- Avoid bending or crimping the power cable excessively.
- Do not expose the adapter to direct sunlight or heat sources.
Troubleshooting
If you encounter issues with your power adapter, refer to the following table:
| Problem | Possible Cause | Solution |
|---|---|---|
| Device not powering on. | 1. Adapter not plugged in.
2. Wall outlet not active. 3. Device incompatible (wrong voltage/current). 4. DC connector loose or incorrect size/polarity. |
1. Ensure adapter is fully plugged into outlet.
2. Test outlet with another device. 3. Verify device's power requirements match adapter (12V, max 1A). 4. Check connector fit and polarity (Inner Positive). |
| Adapter feels hot. | 1. Normal operation (slight warmth).
2. Overload or poor ventilation. |
1. This is normal for power adapters.
2. Ensure device current draw is within 1A. Provide adequate ventilation around the adapter. If excessively hot, disconnect immediately. |
| Intermittent power to device. | 1. Loose connection.
2. Damaged cable/connector. |
1. Ensure all connections are secure.
2. Inspect cable and connector for damage. Replace if damaged. |
Specifications
| Feature | Detail |
|---|---|
| Model Number | 12V1ADUMMY1 |
| Input Voltage | AC 100-240V, 50/60Hz |
| Output Voltage | DC 12V |
| Output Current | 1A (1000mA) |
| Output Wattage | 12W (Max) |
| DC Connector Size | 5.5mm x 2.1mm (compatible with 5.5mm x 2.5mm) |
| DC Polarity | Inner Positive (+), Outer Negative (-) |
| Cable Length | 47.25 inches (approx. 120 cm) |
| Adapter Body Dimensions | 1.5 x 1.0 x 2.3 inches (approx.) |
| Item Weight | 2.6 ounces |
| Certifications | UL, FCC, CE, RoHS, SAA, PSE, KC, CCC |
Warranty Information
SOLTECH is committed to delivering quality products. For specific warranty terms and conditions, please refer to the product packaging or contact SOLTECH customer support. Typically, products are covered against defects in materials and workmanship for a specified period from the date of purchase.
Customer Support
For technical assistance, troubleshooting, or any inquiries regarding your SOLTECH 12V 1A 12W Power Supply Adapter, please visit the official SOLTECH website or contact their customer service department. Contact information can usually be found on the product packaging or the brand's official online presence.
