1. Product Overview
The ESSAGER HE-006 TWS Bluetooth 5.3 Earphones are designed for wireless audio playback and hands-free communication. They feature a semi-in-ear design, touch controls, and come with a portable charging case.
Image: The ESSAGER HE-006 TWS Bluetooth 5.3 Earphones, showing both earbuds and the compact charging case.
Package Contents:
- ESSAGER HE-006 TWS Bluetooth Earphones (Left and Right)
- Charging Case
- USB Charging Cable (Type-C)
- User Manual
2. Setup and Initial Use
2.1 Charging the Earphones and Case
Before first use, fully charge the earphones and the charging case. The charging case has a built-in 400mAh battery, and each earphone has a 30mAh battery.
- Charging the Case: Connect the provided USB Type-C cable to the charging port on the case and to a USB power source. The indicator light on the case will show charging status.
- Charging the Earphones: Place the earphones into their respective slots in the charging case. They will automatically begin charging. The case will indicate the charging status of the earbuds.
Image: The ESSAGER HE-006 earbuds placed inside their charging case, illustrating how they are stored and charged.
Image: The ESSAGER HE-006 charging case connected via a USB-C cable, demonstrating the charging process.
2.2 Pairing with a Device
The earphones utilize Bluetooth V5.3 technology for fast and stable connections.
- Automatic Power On: Open the charging case and remove both earphones. They will automatically power on and enter pairing mode.
- Bluetooth Connection: On your mobile device (smartphone, tablet, laptop), go to the Bluetooth settings. Search for available devices and select "ES-006" from the list.
- Successful Pairing: Once connected, a voice prompt will confirm successful pairing. For subsequent uses, the earphones will automatically connect to the last paired device when removed from the case.
Image: A smartphone screen displaying the Bluetooth pairing interface, showing the "ES-006" device ready for connection.
3. Operating Instructions
3.1 Wearing the Earphones
The HE-006 earphones feature a semi-in-ear design for comfortable and secure fit during various activities.
- Identify the Left (L) and Right (R) earphones.
- Gently insert each earphone into your ear canal, adjusting for a snug and comfortable fit.
Image: A person wearing the ESSAGER HE-006 earbuds, demonstrating the semi-in-ear fit.
3.2 Touch Controls
The earphones are equipped with touch sensors for convenient control of music and calls.
| Action | Left Earbud (L) | Right Earbud (R) |
|---|---|---|
| Play/Pause Music | Single Tap | Single Tap |
| Next Track | Double Tap | Double Tap |
| Previous Track | Triple Tap | Triple Tap |
| Answer/End Call | Single Tap | Single Tap |
| Reject Call | Press and Hold (2s) | Press and Hold (2s) |
| Activate Voice Assistant | Press and Hold (2s) | Press and Hold (2s) |
Note: Volume control may need to be adjusted directly on your connected device.
4. Maintenance and Care
4.1 Cleaning
Regular cleaning helps maintain optimal performance and hygiene.
- Use a soft, dry, lint-free cloth to wipe the earphones and charging case.
- Do not use abrasive cleaners, solvents, or aerosol sprays.
- Gently clean the ear tips and speaker mesh with a dry cotton swab to remove any earwax or debris.
4.2 Water Resistance
The earphones are designed to be sweatproof and water-resistant, making them suitable for sports and outdoor activities. However, they are not intended for swimming or submersion in water. Avoid exposing the charging case to liquids.
4.3 Battery Care
To prolong battery life:
- Store the earphones and case in a cool, dry place when not in use.
- Avoid extreme temperatures.
- Charge the device regularly, even if not used frequently, to prevent deep discharge.
5. Troubleshooting
If you encounter issues with your ESSAGER HE-006 earphones, refer to the following common solutions:
| Problem | Possible Solution |
|---|---|
| Earphones not pairing |
|
| No sound from one earphone |
|
| Earphones not charging |
|
| Poor sound quality |
|
6. Specifications
Detailed technical specifications for the ESSAGER HE-006 TWS Bluetooth Earphones.
| Feature | Specification |
|---|---|
| Model Name | HE-006 |
| Bluetooth Version | 5.3 |
| Bluetooth Protocols | IFP V1.7, HSP V1.2, A2DP V1.3, AVRCP V1.6 |
| Wireless Communication Technology | Bluetooth |
| Bluetooth Range | Up to 10 meters (33 feet) |
| Charging Case Battery Capacity | 400mAh Lithium Battery |
| Earphone Battery Capacity | 2 x 30mAh |
| Control Method | Touch |
| Earpiece Shape | Semi-in-ear |
| Audio Driver Type | Dynamic Driver (F13 composite diaphragm speakers) |
| Water Resistance Level | Water Resistant (Sweatproof) |
| Material | Metal (Charging Case) |
| Product Dimensions | 2.81 x 1.16 x 1.16 inches (Charging Case) |
| Item Weight | 5.9 ounces (0.17 Kilograms) |
| Connectivity Technology | Wireless |
| Compatible Devices | Cellphones, Tablets, Laptops |
Image: Diagram showing the dimensions of the ESSAGER HE-006 charging case in centimeters and inches.
7. Warranty and Support
7.1 Warranty Information
ESSAGER products are manufactured to high-quality standards. This product is covered by a limited warranty against defects in materials and workmanship from the date of purchase. Please retain your proof of purchase for warranty claims. Specific warranty terms and duration may vary by region and retailer.
7.2 Customer Support
For technical assistance, warranty inquiries, or other support needs, please contact ESSAGER customer service through the retailer where the product was purchased or visit the official ESSAGER website for contact information.
- Online Support: Refer to the ESSAGER official website.
- Email Support: [Please refer to product packaging or official website for email address]
