Alphacool 17628

Introduction

This manual provides essential information for the proper installation, operation, and maintenance of your Alphacool 17628 45 Degree Double Rotary Angled Adapter. Please read these instructions carefully before use to ensure optimal performance and longevity of your water cooling system components.

Product Overview

The Alphacool 17628 is a high-quality brass fitting designed for water cooling systems. It features a 45-degree double rotary design, allowing for flexible tubing routing in compact spaces. The adapter has G1/4" AG (male) to G1/4" IG (female) threads, suitable for 8/5 mm thick tubing. It is optimized for use in server and workstation systems where precise and reliable connections are crucial.

Alphacool 45 Degree Double Rotary Angled Adapter, front view

Image: Front view of the Alphacool 45 Degree Double Rotary Angled Adapter, showing the G1/4 AG thread and the white finish.

Safety Information

Ensure all components are compatible before installation.
Always turn off and unplug your computer system before installing or removing any water cooling components.
Handle fittings with care to avoid damaging threads or O-rings.
Perform a leak test on your water cooling loop before powering on your system.

Setup and Installation

Preparation: Ensure your water cooling loop is drained and all components are clean.
Thread Inspection: Carefully inspect the G1/4" threads on both the adapter and the component you intend to connect (e.g., radiator, pump, water block) for any damage or debris.
O-Ring Check: Verify that the O-rings on the adapter are properly seated and free from damage. These are crucial for a watertight seal.
Connection: Screw the G1/4" AG (male) end of the adapter into the corresponding G1/4" IG (female) port on your water cooling component. Hand-tighten until snug. Do not overtighten, as this can damage the threads or O-rings.
Tubing Connection: If connecting tubing directly to the G1/4" IG (female) end of the adapter, ensure you use a compatible G1/4" male fitting for your tubing size (e.g., compression fitting for 8/5 mm tubing).
Positioning: Utilize the double rotary feature to adjust the angle of the adapter to achieve the desired tubing path.
Leak Test: After assembling your entire water cooling loop, perform a thorough leak test for at least 24 hours using a leak tester or by filling the loop with distilled water and running the pump without powering on other system components.

Alphacool 45 Degree Double Rotary Angled Adapter, side view showing rotary mechanism

Image: Side view of the Alphacool 45 Degree Double Rotary Angled Adapter, highlighting the rotary joints for flexible positioning.

Operating Guidelines

Once installed and leak-tested, the adapter operates passively as part of your water cooling loop. No specific operational steps are required for the adapter itself beyond ensuring it remains securely connected and free from leaks.

Coolant Compatibility: Use only clear and transparent water cooling liquids.
Avoid Pastel Coolants: Particles and additives found in pastel or opaque coolants can clog and permanently damage water cooling components, including this adapter, radiators, pumps, and tubing. This can lead to system failure and may void the manufacturer's warranty.

Maintenance

Regular maintenance of your water cooling system helps ensure optimal performance and longevity of all components, including the Alphacool 45 Degree Double Rotary Angled Adapter.

Coolant Replacement: Replace your water cooling liquid every 6-12 months, or as recommended by your coolant manufacturer.
System Flush: When replacing coolant, it is recommended to flush the entire system with distilled water to remove any accumulated debris or old coolant residue.
Inspection: Periodically inspect the adapter for any signs of wear, corrosion, or leaks, especially around the O-rings and rotary joints.
Cleaning: If necessary, carefully clean the exterior of the adapter with a soft, damp cloth. Do not use harsh chemicals or abrasive materials.

Troubleshooting

Problem	Possible Cause	Solution
Leakage at connection point	Fitting not tightened sufficiently. Damaged or improperly seated O-ring. Damaged threads on adapter or component.	Gently tighten the fitting further (do not overtighten). Inspect and replace O-ring if damaged. Inspect threads; if damaged, replace the component.
Restricted flow / Clogging	Use of opaque/pastel coolants. Accumulation of debris in the loop.	Drain and flush the system thoroughly. Use only clear, transparent coolants. Disassemble and clean the adapter if necessary.
Difficulty rotating adapter	Debris or coolant residue in rotary mechanism. Over-tightening of connected fittings.	Disassemble and clean the rotary joints. Ensure connected fittings are hand-tightened only.

Specifications

Model Number	17628
Manufacturer Part Number	1022526
Brand	Alphacool
Material	Brass
Color	White
Thread Size	G1/4" AG (Male) to G1/4" IG (Female)
Tubing Compatibility	Designed for 8/5 mm tubing thickness (when used with appropriate G1/4" male fitting)
Dimensions (L x W x H)	17 x 17 x 21 mm
Weight	16 g
Compatible Devices	Server, Workstation (water cooling systems)
Quantity in Package	1

Alphacool 45 Degree Double Rotary Angled Adapter, showing both ends

Image: View of the Alphacool 45 Degree Double Rotary Angled Adapter, showing the G1/4 AG (male) and G1/4 IG (female) ends.

Warranty and Support

This Alphacool product is covered by the manufacturer's warranty. Please refer to the official Alphacool website or your point of purchase for detailed warranty terms and conditions. Using non-transparent or pastel coolants may void your warranty due to potential damage to the product.

For technical support or further inquiries, please visit the official Alphacool support page or contact their customer service. Keep your proof of purchase for warranty claims.

Official Alphacool Website: www.alphacool.com
