1. Introduction
This manual provides essential information for the installation, operation, and maintenance of your kielle Oudee 30102000 wall-mounted WC with SoftClose Rimless seat. Please read these instructions carefully before installation and retain them for future reference. Proper installation and maintenance will ensure optimal performance and longevity of the product.
2. Safety Information
Always observe the following safety precautions:
- Installation should be performed by a qualified professional to ensure compliance with local plumbing and building codes.
- Ensure the water supply is turned off before beginning any installation or maintenance work.
- Wear appropriate personal protective equipment (PPE) such as gloves and eye protection during installation.
- Do not use abrasive cleaners or harsh chemicals on the ceramic or plastic surfaces, as this may damage the finish.
- Avoid placing heavy objects on the toilet or seat, as this may cause damage or injury.
3. Package Contents
Verify that all components are present and undamaged before installation:
- kielle Oudee 30102000 Wall-Mounted WC (Ceramic bowl)
- SoftClose Rimless WC Seat (Plastic)
- Installation hardware (e.g., mounting bolts, washers, seals) - Specific components may vary; refer to the included hardware pack.
Figure 1: The kielle Oudee 30102000 wall-mounted WC with its SoftClose Rimless seat in a closed position. This image shows the complete unit as it would appear before installation.
4. Specifications
| Model | Oudee 30102000 |
| Brand | kielle |
| Type | Wall-Mounted WC |
| Seat Type | SoftClose, Rimless |
| Color | White |
| WC Material | Ceramic |
| Seat Material | Plastic |
| Installation Type | Wall-mounted |
Figure 2: Technical drawing illustrating the top and front view dimensions of the kielle Oudee 30102000 wall-mounted WC. Measurements are provided in millimeters.
Figure 3: Technical drawing illustrating the side view dimensions and mounting points of the kielle Oudee 30102000 wall-mounted WC. This view details the projection from the wall and connection points.
5. Setup and Installation
This section outlines the general steps for installing the kielle Oudee 30102000 wall-mounted WC. It is crucial to consult the detailed installation guide provided with your specific mounting frame and cistern, as these components are typically sold separately and have their own installation requirements.
5.1. Pre-Installation Checks
- Ensure the wall-mounting frame (concealed cistern) is securely installed according to its manufacturer's instructions and is compatible with the kielle Oudee 30102000.
- Verify that water supply and waste connections are correctly positioned and accessible.
- Inspect the WC bowl and seat for any damage before proceeding.
5.2. Installation Steps (General)
- Prepare Connections: Ensure the waste pipe and water inlet pipe from the concealed cistern are correctly aligned with the corresponding openings on the WC bowl.
- Apply Sealant: Apply a suitable sealant (e.g., silicone) around the waste pipe connection to ensure a watertight seal.
- Mount the WC Bowl: Carefully lift the WC bowl and slide it onto the mounting bolts protruding from the wall frame. Guide the waste and water inlet pipes into their respective connections on the bowl.
- Secure the Bowl: Attach the washers and nuts to the mounting bolts. Tighten them evenly and firmly, but do not overtighten, as this can crack the ceramic.
- Connect Water Supply: Connect the flexible water supply hose from the cistern to the WC bowl's inlet. Ensure all connections are hand-tightened, then use a wrench for a final snug turn.
- Install WC Seat: Follow the specific instructions provided with the SoftClose seat for attachment to the WC bowl. Typically, this involves inserting hinges into designated holes and securing them.
- Test for Leaks: Turn on the main water supply. Flush the toilet several times and carefully inspect all connections for any signs of leaks.
- Apply Finishing Sealant: Once satisfied with the installation and leak-free operation, apply a bead of silicone sealant around the perimeter where the WC bowl meets the wall tiles for a neat finish and to prevent water ingress.
Figure 4: The kielle Oudee 30102000 wall-mounted WC shown installed in a contemporary bathroom setting, with the seat closed. This illustrates the product's aesthetic integration.
Figure 5: The kielle Oudee 30102000 wall-mounted WC with its SoftClose seat in the open position, revealing the rimless design of the bowl. This highlights the functional aspect of the seat and bowl.
6. Operating Instructions
6.1. Flushing
The kielle Oudee 30102000 WC operates with a concealed cistern and flush plate (not included). To flush, press the appropriate button on your flush plate. Most flush plates offer a dual-flush option for water conservation: a smaller button for a partial flush and a larger button for a full flush.
6.2. SoftClose Seat Function
The SoftClose feature of the WC seat ensures a gentle and silent closing motion. To close the seat, simply push it down slightly, and it will lower itself slowly and quietly. Avoid forcing the seat down, as this can damage the SoftClose mechanism.
6.3. Rimless Design
The rimless design of the WC bowl facilitates easier cleaning and improved hygiene. Water is distributed evenly around the bowl during flushing, ensuring thorough rinsing without a traditional rim where dirt can accumulate.
7. Maintenance and Cleaning
Regular cleaning and proper maintenance will preserve the appearance and functionality of your kielle Oudee 30102000 WC.
7.1. General Cleaning
- Use a soft cloth or sponge with mild, non-abrasive cleaning agents.
- Wipe down all ceramic surfaces regularly.
- For the WC seat, use a damp cloth and mild soap. Avoid harsh chemicals, as they can discolor or damage the plastic.
- Rinse thoroughly with clean water after cleaning and dry with a soft cloth to prevent water spots.
7.2. Rimless Bowl Cleaning
The rimless design allows for easy access to the entire inner surface of the bowl. Use a toilet brush and a suitable toilet cleaner to clean the bowl thoroughly. The absence of a rim reduces hidden areas for bacteria and grime buildup.
7.3. Seat Removal for Cleaning (if applicable)
Some SoftClose seats are designed for quick release, allowing for easy removal for thorough cleaning of both the seat and the ceramic bowl. Refer to your seat's specific instructions for removal and reattachment. If your seat is not quick-release, clean it in place.
Figure 6: A close-up view of the kielle Oudee 30102000 WC with the seat open, clearly showing the rimless interior of the bowl. This design feature aids in easier cleaning and improved hygiene.
Figure 7: The kielle Oudee 30102000 WC with both the seat and lid fully lifted, exposing the hinge mechanism. This position is useful for thorough cleaning around the hinges and the top of the ceramic bowl.
8. Troubleshooting
This section addresses common issues you might encounter with your WC. For more complex problems, consult a qualified plumber.
| Problem | Possible Cause | Solution |
|---|---|---|
| Weak Flush | Low water level in cistern, partially closed stopcock, blockage in waste pipe. | Check cistern water level and adjust if necessary. Ensure stopcock is fully open. Inspect for blockages in the waste pipe. |
| Continuous Water Flow | Faulty fill valve or flush valve in the cistern. | Inspect the cistern mechanism. Adjust or replace the fill/flush valve as needed. Consult the cistern manufacturer's manual. |
| Leaking from Connections | Loose connections, damaged seals, incorrect sealant application. | Turn off water supply. Tighten connections. Replace damaged seals. Reapply sealant if necessary. |
| SoftClose Seat Not Functioning | Hinge mechanism obstruction or damage. | Check hinges for obstructions. Clean thoroughly. If damaged, contact kielle support for replacement parts. |
9. Warranty and Support
kielle products are manufactured to high-quality standards. For specific warranty terms and conditions, please refer to the warranty documentation included with your purchase or visit the official kielle website. In case of issues not covered by this troubleshooting guide, please contact kielle customer support for assistance.
Contact Information: (Please refer to your purchase documentation or the official kielle website for the most current contact details.)
