Exped Ultra Series Sleeping Mat Instruction Manual

Introduction

The Exped Ultra Series Lightweight Backpacking Mat is designed for optimal comfort and packability during outdoor adventures. This manual provides essential information for the setup, operation, maintenance, and care of your sleeping mat to ensure its longevity and your comfort.

Figure 1: Top view of the Exped Ultra Series Sleeping Mat.

Safety Information

WARNING:

• Do not use in temperatures below 50°F (10°C) for the 1R model. Refer to your specific mat's R-value for appropriate temperature ratings.
• Always use the included Schnozzel Pumpbag for inflation and deflation to avoid suffocation risk and damage to the mat.
• Keep away from water and moisture to prevent mold growth.
• Always follow the manufacturer's instructions for safe use and storage.

Key Features

• Recycled 20d Ripstop Polyester: Oeko-tex® 100 Certified for sustainability.
• Ultralight Backpacking Mat: Designed for summer camping, fast, compact, and lightweight.
• Ultimate Comfort: Head-to-toe air chambers provide full body support and increased durability.
• AirMat Technology: Air-insulated for use in warmer temperatures.
• Pumpbag Included: EXPED's Schnozzel Pumpbag ensures rapid, moisture-free mat inflation without lung power.
• Sustainability: All EXPED sleeping mats are CO2-balanced through myclimate.

Figure 2: Key features and design elements of the Exped Ultra Series mat.

Setup Guide

Unpacking and Initial Inspection

1. Remove the sleeping mat and Schnozzel Pumpbag from the stuff sack.
2. Unroll the mat on a flat, clear surface, ensuring no sharp objects are underneath.
3. Inspect the mat for any visible damage or punctures. A repair kit is included for minor repairs.

Figure 3: Contents of the Exped Ultra Series package.

Inflating the Mat with the Schnozzel Pumpbag

1. Locate the inflation valve on the mat (usually marked "IN").
2. Attach the nozzle of the Schnozzel Pumpbag securely to the inflation valve.
3. Hold the pumpbag open to capture air, then roll the top closure of the bag down to trap the air.
4. Press down on the pumpbag to force the air into the mat. Repeat this process until the mat is firm. Typically, 2-3 full bags of air are sufficient.
5. Once inflated, close the inflation valve tightly.

Figure 4: Setting up the Exped Ultra Series mat in a tent.

Operating Instructions

Adjusting Firmness

For personalized comfort, you can adjust the mat's firmness. Briefly open the inflation valve and press gently on the mat to release small amounts of air until your desired firmness is achieved. Close the valve immediately after adjustment.

Sleeping on the Mat

The mat's head-to-toe air chambers are designed to fully support your body. The slightly larger outer tubes help to cradle you, preventing you from rolling off during sleep. This design enhances stability and comfort, especially for side sleepers.

Figure 5: Enjoying comfort on the Exped sleeping mat.

Maintenance and Care

Deflation and Packing

1. Locate the deflation valve on the mat (usually marked "OUT").
2. Open the deflation valve completely.
3. Roll the mat tightly from the end opposite the valve to expel all air.
4. Once deflated, close the valve and secure the mat with the included strap or place it directly into the stuff sack.

Cleaning and Storage

• Clean the mat with a damp cloth and mild soap. Avoid harsh chemicals.
• Ensure the mat is completely dry before storing to prevent mold and mildew.
• Store the mat unrolled with valves open in a cool, dry place if possible, to prolong its lifespan. If space is limited, store it loosely rolled in its stuff sack.
• Follow manufacturer instructions for special materials, such as the recycled ripstop polyester.

Troubleshooting

Mat Losing Air

• Check Valves: Ensure both inflation and deflation valves are securely closed.
• Inspect for Punctures: Inflate the mat and submerge it in water (if possible) or apply soapy water to the surface to locate bubbles indicating a leak. Use the included repair kit for small punctures.
• Temperature Changes: Air pressure inside the mat can decrease in colder temperatures. Re-inflate as needed.

Product Specifications

Figure 6: Detailed specifications for the Exped Ultra 1R Mummy mat.

Warranty and Support

For specific warranty information and customer support, please refer to the official Exped website or contact their customer service directly. Keep your proof of purchase for any warranty claims.
