Introduction
The Symcode USA-6709DA-Blue Handheld 2D Wireless Barcode Scanner is designed for accurate and efficient data capture. It offers versatile connectivity options and robust decoding capabilities, making it suitable for various business environments.
Figure 1: Symcode 2D Wireless Barcode Scanner with included accessories.
Setup
Package Contents
Verify that all items are present in the package:
- Barcode Scanner (Model: USA-6709DA-Blue)
- Charging Cord
- User Manual
Connection Modes
The scanner supports three primary connection methods:
- 2.4G Wireless Communication: Provides an effective communication range of up to 200 meters in open air.
- Bluetooth 6.0 Communication: Offers an effective communication range of up to 30 meters. Ideal for connecting to smartphones and tablets without requiring a driver.
- USB Wired Connection: The included cable can be used for both charging and data transmission simultaneously.
Figure 2: Illustration of wired and wireless connection modes.
Initial Charging
Before first use, ensure the scanner is fully charged.
- Charging Time: Approximately 2.5 hours.
- Battery Life: Up to 30 hours of continuous operation on a full charge.
Operating Instructions
Scanning Modes
The scanner offers three operational modes:
- Manual Trigger Mode: Press the trigger button to initiate a scan.
- Auto-sense Mode: The scanner automatically detects and scans barcodes when presented within its field of view.
- Continuous Mode: The scanner continuously scans, ideal for high-volume environments.
Data Upload Modes
Data can be uploaded to a computer using two methods:
- Instant Upload Mode: Data is transmitted immediately after each scan.
- Offline Storage Mode: The scanner can store up to 10,000 codes internally. Data can be uploaded later by scanning a specific setup code.
Figure 3: Instant Upload and Offline Storage Modes.
Barcode Compatibility
The scanner supports a wide range of 1D and 2D barcode types, including the ability to read screen codes, incomplete codes, and fuzzy codes:
- 1D Barcodes: UPC/EAN, UPC/EAN with Supplemental, UCC/EAN 128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 128 Full ASCII, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, RSS variants, Chinese 2 of 5, and extended ASCII support for Code 128 barcodes.
- 2D Barcodes: QR Code, PDF417, Data Matrix.
Figure 4: Examples of supported 1D and 2D barcode types.
Configuration Options
The barcode reader offers over 180 configuration options, allowing for customization such as:
- Adding prefix and suffix codes to scanned data.
- Deleting starting or ending characters from scanned data.
- Adding keyboard keys or combinations to the scanning operation.
Transmission Range
The effective transmission range varies based on the environment:
- Open Air: Up to 200 meters.
- Indoor: Up to 60 meters.
Figure 5: Wireless transmission range.
System Compatibility
The scanner is compatible with various operating systems and software applications:
- Operating Systems: Windows, Mac, Linux, iOS, Android.
- Software: Quickbook, Word, Excel, Novell, and other common software.
Figure 6: Operating system compatibility.
Usage Scenarios
The scanner is suitable for a variety of applications:
Figure 7: Typical usage environments for the scanner.
Maintenance
Cleaning
To maintain optimal performance, keep the scanner clean:
- Use a soft, dry cloth to wipe the exterior of the scanner.
- For the scanning window, use a lens cleaning cloth or a soft, lint-free cloth lightly dampened with a mild, non-abrasive cleaner. Avoid harsh chemicals.
Storage
Store the scanner in a cool, dry place away from direct sunlight and extreme temperatures. Ensure the device is powered off when not in use for extended periods.
Troubleshooting
Common Issues and Solutions
| Issue | Possible Cause | Solution |
|---|---|---|
| Scanner not connecting. | Out of range, low battery, incorrect pairing mode. | Ensure scanner is within range, charge battery, re-pair device according to connection mode instructions. |
| Unable to scan barcodes. | Barcode damaged, incorrect symbology setting, dirty scanning window. | Try scanning a different barcode, check scanner configuration for supported symbologies, clean scanning window. |
| Data not transmitting to computer. | Incorrect upload mode, software not open/compatible, USB cable issue. | Verify upload mode (instant/offline), ensure target application is active, check USB cable connection. |
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | USA-6709DA-Blue |
| Input Voltage | DC5V±0.25V |
| Current (Work) | 25 mA |
| Current (Instantaneous) | 95 mA |
| Decoding Speed | 100 times / sec |
| Wireless Range (Open Air) | 200m |
| Wireless Range (Indoor) | 60m |
| Charging Time | 2.5 Hours |
| Battery Life | 30 Hours |
| Battery Type | 1 Lithium Polymer battery (included) |
| Package Dimensions | 6.81 x 4.61 x 3.27 inches |
| Item Weight | 10.5 ounces |
| Durability | Shockproof, withstands 8 ft (2.4m) drops to concrete, IP67 anti-drop grade, dustproof. |
| Compatible Devices | Desktop, Laptop, Smartphone, Tablet |
| Connectivity Technology | Bluetooth 6.1, Wireless 2.4G, USB Cable |
Figure 8: Product dimensions.
Figure 9: Durability features of the scanner.
Warranty and Support
Warranty Information
This product includes a standard manufacturer's warranty. Please refer to the documentation included in your package or contact Symcode customer support for specific warranty terms and conditions.
Customer Support
For technical assistance, troubleshooting, or any inquiries regarding your Symcode 2D Wireless Barcode Scanner, please visit the official Symcode website or contact their customer service department. Contact details are typically available on the product packaging or the manufacturer's website.
