1. Introduction
Thank you for purchasing the DBPOWER W32 Projector. This manual provides essential information for the safe and efficient operation of your device. Please read it thoroughly before use and keep it for future reference.
Package Contents
Verify that all items are included in your package:
- DBPOWER W32 Projector
- Remote Control
- Power Cord
- HDMI Cable
- AV Cable
- User Manual (this document)
- Height Adjustment Screw
2. Setup
2.1 Placement
Place the projector on a stable, flat surface. Ensure adequate ventilation around the device. For optimal viewing, project onto a smooth, light-colored wall or a projector screen.
2.2 Power Connection
- Connect the power cord to the projector's power input.
- Plug the other end of the power cord into a power outlet.
- Press the power button on the projector or remote control to turn it on.
2.3 Focus and Keystone Correction
Adjust the focus ring on the projector lens until the image is clear. Use the keystone correction dial to correct any trapezoidal distortion, ensuring a rectangular image.
3. Operating Instructions
3.1 Connecting Devices
The DBPOWER W32 Projector supports various input sources:
- HDMI: Connect to laptops, game consoles (PS3/PS4, X-Box, Switch), TV sticks (Fire TV, Roku Stick), and other HDMI-enabled devices.
- USB: Connect USB drives for media playback.
- AV: Connect to DVD players or older devices using the included AV cable.
- TF Card: Insert a TF card for direct media playback.
3.2 Wireless Connectivity (WiFi & Bluetooth)
The projector features built-in WiFi and Bluetooth for seamless wireless connections.
WiFi Screen Mirroring (iOS/Android)
- Select "Screen" from the input source menu to enter the mirroring interface.
- Ensure your iOS/Android device and the projector are connected to the same WiFi network.
- On your iOS device, enable Screen Mirroring and select "DBPOWER-XXXXXX" from the detected devices.
- On your Android device, enable Cast/Wireless Display and select "DBPOWER-XXXX" from the detected devices.
Bluetooth Audio Connection
Connect external Bluetooth speakers or headphones for an enhanced audio experience.
- Go to the projector's Bluetooth settings.
- Enable Bluetooth on the projector.
- Put your Bluetooth audio device into pairing mode.
- Select your device from the list on the projector to connect.
3.3 Audio Output
The projector has two built-in speakers for basic audio. For a more immersive experience, connect external audio devices via Bluetooth or the 3.5mm audio jack.
4. Maintenance
4.1 Cleaning the Lens
Use a soft, lint-free cloth specifically designed for optical lenses to clean the projector lens. Do not use abrasive cleaners or solvents.
4.2 Air Filter Cleaning
Regularly check and clean the air filter to ensure proper ventilation and prevent overheating. Refer to the diagram below for the location of the air vents.
4.3 Storage
When not in use for extended periods, store the projector in a cool, dry place, away from direct sunlight and excessive dust. Use the original packaging or a protective case.
5. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| No image displayed | Power cable not connected; Incorrect input source selected; Device not connected properly. | Check power connection; Select correct input source (HDMI, USB, AV); Ensure cables are securely connected. |
| Blurred image | Focus not adjusted; Keystone not adjusted. | Adjust the focus ring; Adjust the keystone correction dial. |
| No sound | Volume too low; External audio device not connected or selected; Muted. | Increase volume; Check external audio connections/Bluetooth pairing; Unmute the projector. |
| Remote control not working | Batteries dead; Obstruction between remote and projector; Remote sensor blocked. | Replace batteries; Remove obstructions; Ensure remote is pointed at the projector's IR sensor. |
| Overheating | Blocked ventilation; Prolonged use in hot environment. | Ensure vents are clear; Operate in a well-ventilated area; Allow projector to cool down. |
6. Specifications
| Feature | Detail |
|---|---|
| Brand | DBPOWER |
| Model Number | W32 |
| Product Dimensions | 14.9 x 11 x 10.4 cm |
| Item Weight | 970 g |
| Brightness | 10000 Lumens (equivalent to 300 ANSI Lumens) |
| Native Resolution | 1920 x 1080 pixels (1080P) |
| Supported Resolution | Up to 4K |
| Contrast Ratio | 10,000:1 |
| Lamp Life | ≥100,000 hours |
| Connectivity Technology | Bluetooth, WiFi, HDMI, USB, AV, TF Card |
| Recommended Use | Home Theater |
| Special Features | 4K compatible, Bluetooth, Built-in Speaker, Keystone Correction, WiFi |
7. Warranty and Support
DBPOWER provides a 12-month warranty from the date of purchase. This warranty covers initial defects and natural failures under normal use. For any issues, including exchanges or returns, please contact our customer support.
Customer Support
- 24-hour quick response service
- 12-month quality guarantee
- 30-day return validity period
- Dedicated customer support always available
For direct support, you can scan the QR code below to add us on LINE or visit our official store page.
Please note: Customer support is closed on Saturdays, Sundays, and public holidays, as well as during year-end/New Year, Golden Week, and Obon holidays.
