1. Introduction
The Tami Tami T600 Adjustable Bed Frame is designed to provide unmatched comfort and convenience, enhancing your sleep experience with advanced features such as head and foot incline, massage functions, USB charging ports, and under-bed lighting. This manual provides detailed instructions for assembly, operation, maintenance, and troubleshooting to ensure safe and effective use of your adjustable bed frame.
Figure 1.1: Tami Tami T600 Split King Adjustable Bed Frame, illustrating its dual base design and integrated massage zones.
2. Safety Information
Important Safety Warnings:
- After the power base is raised, jumping and playing on the raised part is prohibited.
- After the power base is raised, it is forbidden to push or pull the back or foot of the power base vigorously.
- Ensure all power cords are properly routed to avoid tripping hazards or damage.
- Keep children and pets away from moving parts during operation.
3. Assembly Instructions
The Tami Tami T600 Adjustable Bed Frame is designed for quick and easy assembly, often taking as little as 5 minutes with no tools required for the main setup. It arrives largely pre-assembled.
3.1. Unpacking and Preparation
- Carefully remove all components from the packaging. For Split King models, two separate bases will be shipped, potentially arriving in separate boxes.
- Place the folded bed frame on a clean, flat surface where you intend to set it up.
3.2. Basic Assembly Steps
- Unfold the Bed: Carefully unfold the bed frame. It is recommended to have two people for this step due to the weight of the unit.
- Screw in Legs: Attach the adjustable legs by screwing them into the designated receivers on the frame. Ensure they are securely tightened.
- Adjust Leg Height: The bed comes with three height-adjustable leg options (4", 8", 12") to customize the bed's height to your preference. Select and install the desired leg height.
- Connect Power: Plug the power cord into a grounded electrical outlet.
- Install Retainer Bar: Attach the mattress retainer bar at the foot of the bed to prevent the mattress from sliding.
Figure 3.1: Visual guide for the quick assembly process, showing unfolding the base and screwing in the legs.
4. Operating Instructions
Your Tami Tami T600 Adjustable Bed Frame is operated using a wireless remote control, offering a variety of comfort and convenience features.
4.1. Remote Control Functions
Figure 4.1: Overview of the wireless remote control and its various functions.
- Head Incline (0-65°): Use the dedicated buttons to raise or lower the head section of the bed.
- Foot Incline (0-45°): Use the dedicated buttons to raise or lower the foot section of the bed.
- Zero Gravity Position: Press the "Zero Gravity" button to automatically adjust the bed to a position that elevates your head and feet, promoting circulation and relieving pressure on your back.
- Anti-Snore Position: Press the "Anti-Snore" button to slightly raise the head, which can help open airways and reduce snoring.
- TV/Reading Position: Press the "TV/Reading" button for an optimal position for watching television or reading.
- Memory Positions (M1, M2): The remote includes two preset memory positions. You can also program two custom memory positions by adjusting the bed to your desired setting, then pressing and holding the memory button until the bed beeps.
- One-Touch Flat: Press this button to return the bed to a completely flat position.
- Child Lock: Activate the child lock feature to prevent unintended operation of the bed. Refer to the remote's specific instructions for activation/deactivation.
- Flashlight: The remote control includes a built-in flashlight for convenience in low-light conditions.
Figure 4.2: Illustrates various comfortable positions, including Zero Gravity, TV/Reading, and custom Memory positions.
4.2. Massage Functions
The T600 features a dual-zone interactive massage system to help relieve fatigue and pain.
- Massage Modes: Choose from Wave Massage (for fatigue removal), Pulse Massage (for pain and swelling reduction), or Steady Massage (for increased circulation).
- Intensity Levels: Adjust the massage intensity to one of three levels.
- Timers: Set the massage timer for 10, 15, or 30 minutes.
Figure 4.3: Demonstrates the dual-zone interactive massage feature and its benefits.
4.3. Convenience Features
- Dual-Side USB Ports: Charge your electronic devices conveniently with USB ports located on both sides of the bed frame.
- Under-Bed Nightlight: An integrated nightlight allows for safe movement around the bed during the night.
- Double-Sided Pockets: Store your remote control, phone, or other essentials within easy reach in the side pockets.
Figure 4.4: Showcases the smart features like USB charging, nightlight, and storage pockets.
4.4. Sync and Dual Control (Split King)
For Split King models, you have the flexibility to control both bases together or independently.
- Sync Control: Control both bases simultaneously with one remote, functioning like a single King size bed.
- Dual Control: Control each base separately with two remotes, allowing individual adjustments for each side of the Split King bed.
Figure 4.5: Explains the sync and dual control options for Split King adjustable bed frames.
5. Maintenance
- Cleaning: Wipe the bed frame with a dry cloth to remove dust and debris. Avoid using liquid cleaners directly on electronic components.
- Inspection: Periodically check all connections and fasteners to ensure they are secure.
- Motor Care: The quiet motors are designed for durability. Avoid obstructing their movement or placing excessive weight on the bed.
6. Troubleshooting
If you encounter any issues with your Tami Tami T600 Adjustable Bed Frame, please refer to the following common solutions:
- Bed Stops Responding: If the bed stops responding to remote commands, try unplugging the power cord from the wall outlet for 30 seconds, then plug it back in. This often resets the system.
- Remote Not Working: Check the batteries in the remote control and replace them if necessary. Ensure there are no obstructions between the remote and the bed's receiver.
- Unusual Noises: While the motors are designed to be quiet (<45 dB), slight operational sounds are normal. If you hear loud or unusual noises, inspect for any loose components or obstructions.
For persistent issues not resolved by these steps, please contact Tami Tami customer service.
7. Specifications
| Feature | Description |
|---|---|
| Model Number | T600HK040108 |
| Size | Split King |
| Product Dimensions | 79"L x 74"W x 15"H |
| Item Weight | 178 pounds |
| Weight Capacity | Up to 750 pounds |
| Motor Type | Dual motors (8000N thrust) |
| Motor Noise Level | Less than 45 dB |
| Frame Material | Sturdy steel frame, New Zealand 12mm E0 bedplate |
| Lift Cycles Tested | 20,000+ |
| Leg Height Options | 4", 8", 12" adjustable heights |
| Compatible Mattresses | Memory foam, gel foam, latex foam, hybrid mattresses (under 14 inches) |
| Special Features | Head/Foot Incline, Zero Gravity, Massage (Wave, Pulse, Steady), Dual USB Ports, Under-bed Nightlight, Storage Pockets, Wireless Remote with Child Lock |
Figure 7.1: Key quality and safety features of the Tami Tami T600 bed frame.
8. Warranty and Support
Tami Tami stands behind the quality of its products.
- Warranty: Your Tami Tami T600 Adjustable Bed Frame comes with a 5-YEAR warranty. This warranty covers manufacturing defects and ensures peace of mind regarding your purchase.
- Customer Support: For any logistics or product-related inquiries, Tami Tami provides professional customer service available 24/7 online. They are committed to providing quick assistance within 24 hours.
For support, please visit the official Tami Tami store on Amazon or contact their customer service directly via the contact information provided with your product packaging.
