YUHAO 72 Inch Brushed Nickel Ceiling Fan Instruction Manual
Model: DC1188-8B/72
Product Overview
The YUHAO 72 Inch Brushed Nickel Ceiling Fan is designed for optimal air circulation and lighting in indoor or covered outdoor spaces. It features an energy-efficient DC motor, reversible blades for year-round use, and an adjustable LED light with multiple color temperatures and dimming capabilities. Control all functions conveniently with the included remote.
Image: The YUHAO 72 Inch Brushed Nickel Ceiling Fan, showcasing the fan unit, remote control, and various downrod lengths (6", 12", 24").
What's in the Box
- Mounting Hardware
- Remote Control
- Bulb (Integrated LED Light Source)
- 6", 12", and 24" Downrods
Setup and Installation
Detailed installation instructions are provided in the included manual. For visual guidance, please refer to the official installation video provided by the seller.
Video: Official Installation Guide for YUHAO Ceiling Fan Model 1188. This video demonstrates the step-by-step process of assembling and mounting the ceiling fan.
Mounting Options
The fan includes multiple downrod lengths (6", 12", and 24") to accommodate various ceiling heights. It is suitable for low ceilings, high ceilings, and slanted ceilings (up to 15°).
Image: Diagram illustrating the fan's dimensions and how it can be mounted on low, high, and slanted ceilings using different downrod lengths.
The fan can be used with wall switches that simply turn lights on and off. However, switches with dimming or speed control are not recommended.
Image: Information on recommended room sizes (14x14 ft to 19x19 ft) and a visual guide on compatible wall switches (simple on/off switches are suitable, dimming/speed control switches are not recommended).
Operating Instructions
Remote Control Functions
All fan functions are conveniently controlled via the included remote control. The remote features buttons for fan speed, light color temperature, light brightness, and timer settings.
Image: The remote control highlighting its multi-function capabilities including 6 wind speeds, 3 color temperature adjustments, 1/3/6 hour timing, forward/reverse function, and light brightness control.
Fan Speed and Airflow
Choose from six distinct wind speeds to meet your airflow needs. The fan delivers over 6700 CFM of airflow, ensuring effective cooling.
Image: Visual representation of the 6 adjustable fan speeds, categorized into Low (Gentle Breeze, Level 1-2), Medium (Natural Wind, Level 3-4), and High (Cooling Air, Level 5-6).
Reversible Motor for Year-Round Use
The DC motor features a reversible function, allowing for optimal air circulation in both summer and winter. In summer mode, the fan circulates air downward to create a cooling effect. In winter mode, it circulates air upward to evenly distribute warm air throughout the room.
Image: A cross-section diagram showing airflow direction for summer (downward) and winter (upward) modes, demonstrating the reversible DC motor function.
Adjustable LED Lighting
The integrated 24W LED light source offers energy efficiency and longevity. It provides up to 2000 lumens of soft, non-harsh light. You can select from three color temperatures (3000K warm white, 4000K natural white, 6500K cool white) and adjust brightness from 0% to 100%.
Image: Visual display of the three adjustable color temperatures (Warm light 3000K, Neutral light 4000K, Cool light 6500K) and a brightness adjustment bar for the 24W, 2000LM LED light.
Video: Features Demo for the 72-inch Nickel YUHAO Ceiling Fan. This video demonstrates the various operational features of the fan, including speed and light adjustments.
Maintenance
Regular cleaning of the fan blades and light cover is recommended to maintain optimal performance and appearance. Use a soft, damp cloth for cleaning. Ensure the fan is turned off and power is disconnected before cleaning.
The fan's DC motor is designed for durability and noiseless operation, requiring minimal maintenance. The LED light source is replaceable, ensuring long-term usability.
Troubleshooting
If you encounter any issues with your ceiling fan, please refer to the troubleshooting section in the comprehensive manual provided with your product. Common issues may include:
- Fan not turning on: Check power connections and remote control battery.
- Fan making unusual noises: Ensure all screws are tightened and blades are balanced.
- Light not working: Verify connections to the LED light source.
For persistent problems, please contact customer service.
Specifications
| Feature | Detail |
|---|---|
| Brand | YUHAO |
| Model Number | DC1188-8B/72 |
| Color | Nickel |
| Material | Copper wire Motor, Wooden blades, Metal housing, LED Light |
| Style | Modern |
| Product Dimensions | 72"L x 72"W x 14"H |
| Indoor/Outdoor Usage | Indoor (or Covered Outdoor) |
| Power Source | DC |
| Control Method | Remote |
| Light Source Type | LED |
| Wattage | 24 watts (LED) |
| Brightness | 2000 lumen (Max) |
| Number of Blades | 3 (double-sided) |
| Special Features | Timer, Adjustable brightness, 6 Wind Speeds, 3 Color Temperatures LED, Forward and Reverse |
| Item Weight | 26.8 pounds |
| Batteries Required | 2 AAA (included) |
Warranty and Support
For any product support or inquiries, please contact YUHAO customer service directly. You can typically find contact information through your order details on the platform where the product was purchased. The manufacturer is committed to responding to messages within 24 hours and will send replacement parts for any damaged components.
Hint: To contact the seller, navigate to your order, click on 'Get Product Support', and explicitly request to contact the seller, not the Amazon team.
