1. Introduction
Thank you for choosing the POGOLAB 49 Key Roll Up Keyboard Piano. This portable digital piano is designed for beginners and enthusiasts, offering a compact and versatile musical experience. It features 49 standard keys, 47 unique tones, 14 educational demo songs, and recording capabilities. This manual provides essential information to help you set up, operate, and maintain your instrument.
2. What's in the Box
- 1 x POGOLAB 49 Key Roll Up Keyboard Piano
- 1 x USB Cable
- 1 x User Manual (this document)
3. Product Overview
Familiarize yourself with the components of your POGOLAB Roll Up Keyboard Piano.
Figure 3.1: The POGOLAB 49 Key Roll Up Keyboard Piano, shown both unrolled for play and rolled for storage, alongside its USB charging cable.
Figure 3.2: Detailed view of the control panel, highlighting the built-in speaker, tone and rhythm selection buttons, recording and demo functions, volume adjustment, power switch, headphone jack, microphone jack, and USB charging port.
Key Components:
- 49 Standard Keys: Black and white keys made from environmental-grade silicone.
- Control Panel: Houses the speaker, function buttons, and ports.
- Built-in Speaker: For audio output.
- Headphone Jack (3.5mm): For private practice.
- Microphone Jack: For connecting an external microphone.
- USB Charging Port (DC 5V): For power and charging.
- Power Switch (ON/OFF): To turn the device on or off.
4. Setup
4.1 Unpacking and Initial Inspection
- Carefully remove all components from the packaging.
- Inspect the keyboard and accessories for any signs of damage. If any damage is found, contact customer support immediately.
- Unroll the keyboard on a flat, stable surface.
4.2 Charging the Battery
The keyboard piano is equipped with a built-in rechargeable Lithium Polymer battery.
- Connect the provided USB cable to the DC 5V charging port on the control panel.
- Connect the other end of the USB cable to a standard USB power adapter (not included) or a computer's USB port.
- Allow the device to charge fully before first use. The charging indicator (if present) will typically change color or turn off when charging is complete.
Figure 4.1: Connecting the USB cable for charging the internal battery.
4.3 Powering On/Off
- To turn on: Slide the ON/OFF switch to the 'ON' position.
- To turn off: Slide the ON/OFF switch to the 'OFF' position.
4.4 Connecting Headphones or External Speakers
For private practice or louder output, use the 3.5mm headphone jack.
- Insert a standard 3.5mm audio jack from your headphones or external speakers into the Headphone Jack on the control panel.
- The internal speaker will automatically mute when headphones are connected.
Figure 4.2: Connecting headphones for private listening.
4.5 Connecting a Microphone
If desired, an external microphone can be connected.
- Insert a standard microphone jack into the Microphone Jack on the control panel.
5. Operating Instructions
5.1 Basic Playback
- Ensure the piano is powered on.
- Press the keys to produce sound.
5.2 Adjusting Volume
- Use the Volume Adjustment slider or buttons (indicated as '+' and '-' next to 'Tone' and 'RHY' in Figure 3.2) to increase or decrease the sound output.
5.3 Changing Tones
The piano offers 47 unique tones.
- Press the Tone button.
- Use the '+' and '-' buttons to cycle through the available tones.
- Play a key to hear the selected tone.
5.4 Selecting Rhythms
The piano includes 128 rhythms.
- Press the RHY button.
- Use the '+' and '-' buttons to cycle through the available rhythms.
- Press the Play button to start the rhythm. Press Play again to stop.
5.5 Playing Demo Songs
There are 14 educational demonstration songs pre-loaded.
- Press the Demo button to start playing the demonstration songs sequentially.
- Press the Demo button again to skip to the next demo song.
- To stop demo playback, press the Start/Stop button (indicated as 'Play' with a pause symbol in Figure 3.2).
5.6 Recording and Playback
Capture your performances with the recording function.
- Press the Record button to begin recording. A light indicator may show recording is active.
- Play your desired melody on the keyboard.
- Press the Record button again to stop recording.
- To listen to your recorded performance, press the Play Recording button (indicated as 'Play' with a play symbol in Figure 3.2).
6. Maintenance
6.1 Cleaning
The silicone keys are designed for easy cleaning.
- Wipe the keys and surface with a soft, damp cloth.
- Do not use harsh chemicals or abrasive cleaners.
- Ensure the device is powered off and disconnected from charging before cleaning.
Figure 6.1: The piano's keys are waterproof and easy to clean with a damp cloth.
6.2 Storage
The roll-up design allows for convenient storage.
- After use, gently roll up the keyboard.
- Store it in its original box or a protective bag/backpack to prevent damage.
- Avoid storing in extreme temperatures or direct sunlight.
Figure 6.2: The compact, rolled-up design allows for easy storage and portability.
6.3 Battery Care
- To prolong battery life, avoid completely draining the battery frequently.
- Charge the device regularly, even if not in frequent use.
7. Troubleshooting
If you encounter issues with your POGOLAB Roll Up Keyboard Piano, please refer to the following common solutions:
| Problem | Possible Solution |
|---|---|
| No sound from the speaker. |
|
| Keys are unresponsive or produce incorrect sounds. |
|
| Device does not charge. |
|
| Sound is distorted or unclear. |
|
If the problem persists after attempting these solutions, please contact POGOLAB customer support for further assistance.
8. Specifications
| Feature | Detail |
|---|---|
| Model Number | PF49 |
| Number of Keys | 49 |
| Tones | 47 |
| Demo Songs | 14 |
| Rhythms | 128 |
| Connectivity | USB, 3.5mm Jack |
| Power Source | Battery Powered (1 Lithium Polymer battery included) |
| Material | Silicone, Plastic |
| Product Dimensions (unrolled) | 31.1"W x 5.12"D x 0.59"H (79cm W x 13cm D x 1.5cm H) |
| Item Weight | 1.08 pounds (0.49 kg) |
| Special Features | Built-In Speaker, Headphone Jack, Portable, Rechargeable, Roll Up |
9. Warranty and Support
9.1 Warranty Information
POGOLAB products are manufactured to high-quality standards. For specific warranty details, please refer to the warranty card included with your purchase or visit the official POGOLAB website. Keep your proof of purchase for any warranty claims.
9.2 Customer Support
If you have any questions, require technical assistance, or need to report an issue, please contact POGOLAB customer support. Contact information can typically be found on the product packaging, the official POGOLAB website, or through your retailer's support channels.
