Introduction
The ELP 16MP Day Night USB Camera, model ELP-USB16MP01-KAF68W, is a high-resolution autofocus webcam designed for a wide range of applications. Featuring a 16-megapixel IMX298 sensor, it delivers sharp images with a maximum resolution of 4656x3496 pixels. Its day/night vision capability, supported by built-in white LEDs, ensures clear imaging in various lighting conditions. The camera is UVC-compliant, offering plug-and-play functionality across multiple operating systems without the need for additional drivers.
Setup Instructions
Package Contents
- 1 x ELP 16MP USB Camera
- 1 x 3-meter USB Cable
- 1 x User Manual (this document)
Connecting the Camera
- Locate an available USB port on your computer, laptop, Android device, or Raspberry Pi.
- Connect the provided 3-meter USB cable to the camera's port.
- Plug the other end of the USB cable into the USB port on your device.
The camera is UVC-compliant, meaning it is plug-and-play and typically does not require additional driver installation on compatible operating systems.
Compatible Operating Systems
- Windows XP/Vista/Win7/Win8/Win9/Win10/Win11
- Linux (kernel 2.6.26 or above) with UVC support
- MAC-OS X 10.4.8 or later
- Android 4.0 or above with UVC support
- Raspberry Pi
Operating Instructions
Autofocus Functionality
The ELP 16MP USB Camera features an autofocus lens, allowing it to automatically adjust focus for objects at various distances, from millimeter-level close-ups to distant subjects. This eliminates the need for manual lens adjustments.
This video demonstrates the ELP 16MP USB camera's ability to focus clearly on objects as close as 4cm.
This video shows the autofocus performance of the ELP 16MP USB camera when capturing objects at a 5cm distance.
Day/Night Vision
Equipped with white LEDs, the camera provides clear, colorful images in both daytime and low-light night conditions. The white LEDs can be manually turned on or off to suit your environment.
This video demonstrates the day and night vision capabilities and autofocus function of the ELP 16MP USB camera.
Adjustable Parameters
Through compatible software, you can adjust various image parameters to optimize performance for your specific application. These include:
- Brightness
- Contrast
- Saturation
- Hue
- Sharpness
- Gamma
- White Balance
- Exposure
Applications
The compact design and versatile features make this camera suitable for various uses, including:
- Home surveillance systems
- 3D printer monitoring
- Industrial CCTV
- Laser engraver camera
- Robotic machine vision
- Live streaming
- Video conferencing
- Barcode and QR code scanning
This video illustrates the ELP USB camera's use as a mini LightBurn camera for laser applications.
Maintenance
Cleaning
- To clean the camera lens, use a soft, lint-free cloth specifically designed for optical surfaces. Avoid abrasive materials or harsh chemicals.
- For the camera body, wipe with a dry or slightly damp soft cloth. Ensure no moisture enters the camera's internal components.
Storage
Store the camera in a cool, dry place away from direct sunlight and extreme temperatures. Protect the lens from scratches when not in use.
Troubleshooting
Camera Not Detected
- Ensure the USB cable is securely connected to both the camera and your device.
- Try connecting the camera to a different USB port on your device.
- Test the camera on another compatible computer or device to rule out a device-specific issue.
- Verify that your operating system is listed as compatible in the Setup section.
Image is Blurry or Out of Focus
- Allow the camera a few moments to autofocus. The autofocus mechanism works automatically.
- Ensure the lens is clean and free from smudges or dust.
- Check your camera software settings for any manual focus overrides or specific focus modes that might be enabled.
- Ensure adequate lighting for the camera to properly acquire focus.
Night Vision Not Working
- Confirm that the white LEDs are manually turned on. Refer to your software interface for controls.
- Ensure there are no obstructions blocking the LEDs.
Specifications
| Feature | Detail |
|---|---|
| Brand | ELP |
| Model Number | ELP-USB16MP01-KAF68W |
| Photo Sensor Technology | CMOS |
| Video Capture Resolution | 16MP, 5.6K |
| Maximum Resolution | 4656x3496 Pixels |
| Lens Type | Autofocus 68-degree no distortion lens |
| Focus Type | Auto Focus |
| Connectivity Technology | USB |
| Operating System Compatibility | Windows, Linux, macOS, Android, Raspberry Pi |
| Features | 16MP Ultra HD, Built-In White LEDs (Day/Night Vision), UVC Compliant, Lightweight, Mini size |
| Item Dimensions (D x W x H) | 1.42"D x 1.65"W x 1.65"H |
| Item Weight | 0.18 Kilograms |
| Color | Black |
Warranty Information
This ELP camera comes with a 1-year manufacturer's warranty. Additionally, a 30-day free return and replacement policy is offered from the date of purchase. Please retain your proof of purchase for warranty claims.
Support
For technical assistance or further inquiries regarding your ELP 16MP Day Night USB Camera, please contact the manufacturer, ShenZhen Ailipu Technology Co., Ltd. Refer to the product packaging or the official ELP website for the most current contact information.
