ECLIPSE AVN-HS01F 10.1-inch Car Navigation System

1. Product Overview

The ECLIPSE AVN-HS01F is a state-of-the-art car navigation system featuring a floating 10.1-inch HD display. Designed for compatibility with approximately 400 car models, this unit provides high-definition map displays and video content. Its low-reflection screen ensures clear visibility, making route guidance and multimedia viewing a superior experience. The system integrates seamlessly with smartphones via Apple CarPlay and HDMI, allowing access to a wide range of content for an enhanced driving experience.

Image: The ECLIPSE AVN-HS01F unit displaying a detailed navigation map.

2. Key Features

• 10.1-inch HD Display: Features a low-reflection screen with 1280x720 resolution for crisp, clear visuals of maps and video content.
• Floating Structure: Enables installation in approximately 400 different car models, offering flexible positioning within the vehicle's dashboard.
• Apple CarPlay Support: Connect your iPhone to access navigation, music, messages, and more directly from the unit, with voice control via Siri.
• HDMI Input/Output: Allows connection of external devices like smartphones for high-definition video and game playback on the large screen.
• Multimedia Playback: Supports various media formats including SD cards, CDs, and DVDs, in addition to Bluetooth audio streaming.
• VICS WIDE: Provides advanced traffic information for optimized route guidance.

Image: The 10.1-inch large screen of the AVN-HS01F integrated into a car's dashboard.

Image: Visual comparison demonstrating the superior HD quality (1280x720) of the AVN-HS01F compared to standard WVGA (800x480).

3. Setup and Installation

The AVN-HS01F utilizes a floating display structure, which allows for installation in a wide variety of vehicles. For detailed installation instructions, including wiring diagrams and mounting procedures, please refer to the dedicated Installation Manual provided with your unit. Professional installation is recommended to ensure proper functionality and safety.

Image: An overview of different ECLIPSE navigation series, highlighting the floating display and various features across models.

4. Operating Instructions

4.1 Navigation Functions

• Map Display: View detailed maps in HD quality. Use pinch-to-zoom and swipe gestures for easy navigation.
• Route Guidance: Enter your destination to receive clear, turn-by-turn directions. The HD display ensures route information is highly visible.
• VICS WIDE: Access real-time traffic information to avoid congestion and optimize your travel time.

4.2 Media Playback

• CD/DVD: Insert discs into the designated slot for audio and video playback.
• SD Card: Insert an SD card containing audio or video files into the slot.
• Bluetooth Audio: Pair your smartphone or other Bluetooth-enabled device to stream audio wirelessly.

4.3 Apple CarPlay

Connect your iPhone via USB to enable Apple CarPlay. This allows you to use compatible iPhone apps, make calls, send messages, and control music directly from the navigation screen. Use Siri for hands-free voice commands.

Image: The AVN-HS01F display showing the Apple CarPlay interface, with a connected iPhone.

4.4 HDMI Connectivity

Connect HDMI-compatible devices, such as smartphones or portable media players, to the unit to display their content on the large screen. Enjoy high-definition videos and games.

Image: The AVN-HS01F display showing content mirrored from a smartphone via HDMI connection.

4.5 Display Adjustment

The floating display allows for flexible positioning to optimize viewing angles and minimize glare. Adjust the screen's tilt (front/back), swivel (left/right), and height (up/down) manually to suit your preference.

Image: Diagrams demonstrating the various adjustable angles and positions of the AVN-HS01F display for optimal viewing.

5. Maintenance

To ensure the longevity and optimal performance of your ECLIPSE AVN-HS01F, follow these maintenance guidelines:

• Screen Cleaning: Gently wipe the display with a soft, lint-free cloth. For stubborn smudges, slightly dampen the cloth with water or a screen-safe cleaner. Avoid abrasive materials or harsh chemicals.
• Unit Cleaning: Use a dry, soft cloth to wipe the main unit and surrounding areas. Ensure no dust or debris accumulates in ports or vents.
• Disc Care: Handle CDs and DVDs by their edges. Keep them clean and free of scratches to prevent playback issues.
• Software Updates: Periodically check the official ECLIPSE website for any available software or map updates to ensure your system is running the latest version.

6. Troubleshooting

If you encounter issues with your AVN-HS01F, try the following basic troubleshooting steps:

• No Power: Check all power connections. Ensure the vehicle's ignition is on.
• No Sound: Verify volume settings. Check audio source selection. Ensure speakers are properly connected.
• No GPS Signal: Ensure the GPS antenna is correctly installed and has a clear view of the sky. Move the vehicle to an open area if in a covered location.
• Display Issues: If the screen is blank or distorted, try restarting the vehicle's ignition. Check display cable connections if accessible.
• Touchscreen Unresponsive: Perform a system reset if available (refer to the main instruction manual for specific reset procedures).
• Disc Playback Errors: Ensure the disc is clean and free of scratches. Try a different disc to confirm the issue is not with the media.

For persistent issues or problems not covered here, please contact ECLIPSE customer support or consult a qualified service technician.

7. Specifications

8. Warranty and Support

The ECLIPSE AVN-HS01F comes with a 1-year manufacturer warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use.

For warranty claims, technical support, or further inquiries, please contact ECLIPSE customer service or visit the official ECLIPSE brand store:

ECLIPSE Official Brand Store

Please retain your proof of purchase for warranty validation.
