1. Introduction
This manual provides detailed instructions for the safe and efficient use of your ROKU LED Ceiling Light. This product is designed for rooms of 10-12 tatami size, offering 40W (maximum 45W) power and up to 4950 lumens of brightness. It features stepless dimming and color adjustment, a remote control, night light function, timer, and memory function. Please read this manual thoroughly before installation and operation, and retain it for future reference.
Image 1.1: ROKU LED Ceiling Light installed in a bedroom, showcasing its sleek design and bright illumination.
2. Safety Precautions
- Always turn off the main power supply before installation, maintenance, or cleaning to prevent electric shock.
- Installation should be performed by a qualified electrician if you are unsure about the process.
- Do not disassemble or modify the product. This may void the warranty and pose a safety risk.
- Keep the product away from water and high humidity environments.
- Ensure the mounting surface is sturdy enough to support the weight of the light fixture.
- Use only the specified voltage (100V AC) for this product.
3. Package Contents
The ROKU LED Ceiling Light (Model B0BYJ6SX36) package includes the following items. Please verify all components are present upon delivery, as this product is shipped in two separate boxes.
- LED Ceiling Light Fixture (x2)
- Remote Control (x2)
- Mounting Hardware (screws, nuts, etc.) (x2 sets)
- Instruction Manual (Japanese) (x1)
Note: AAA batteries for the remote control are not included and must be purchased separately.
4. Setup and Installation
Installation of the ROKU LED Ceiling Light is designed to be straightforward. Please follow these 4 steps carefully. Remember to turn off the power supply before beginning installation.
Image 4.1: Visual guide for the 4-step installation process.
- Prepare the Ceiling: Ensure the power is off. Remove any existing light fixture. Connect the power connector from the ceiling to the fixture's power box.
- Attach the Chassis: Secure the mounting chassis to the ceiling using the provided bolts and nuts. Ensure it is firmly attached.
- Connect the Light Fixture: Connect the power plug from the light fixture to the power connector on the chassis.
- Secure the Lamp Shade: Align the lamp shade with the chassis and rotate it clockwise until it clicks into place, securing the fixture to the ceiling.
The fixture is compatible with various ceiling hooks, including round full-hook ceilings, full-hook ceilings, square full-hook ceilings, and embedded ceilings.
5. Operating Instructions
The ROKU LED Ceiling Light is operated using the included remote control. Ensure AAA batteries are installed in the remote control.
Image 5.1: Overview of the remote control functions.
5.1 Power On/Off
- Press the 'On' button to turn the light on.
- Press the 'Off' button to turn the light off.
5.2 Stepless Dimming and Color Adjustment
The light offers stepless adjustment of brightness (0-100%) and color temperature (daylight white to warm white).
- Use the 'Brighten' and 'Dim' buttons to adjust brightness.
- Use the 'Cool White' and 'Warm White' buttons for 3-step color adjustment.
- To enter stepless color adjustment mode, press and hold the 'Cool White' or 'Warm White' button for 4 seconds.
Image 5.2: Demonstrates the range of brightness and color temperature settings.
5.3 Night Light Function
Activate the night light mode for a low-brightness illumination, ideal for nighttime activities without disturbing sleep.
- Press the 'Night Light' button to activate this mode.
- This mode consumes minimal power and provides sufficient light for movement in the dark.
Image 5.3: The night light provides gentle illumination for safe movement at night.
5.4 Timer Function
Set the light to automatically turn off after a specified period.
- Press the '15 min' button for the light to turn off after 15 minutes.
- Press the '30 min' button for the light to turn off after 30 minutes.
- To cancel the timer, turn the light off and then on again, or press the 'Cancel' button on the remote.
Image 5.4: The timer function allows automatic shut-off after 15 or 30 minutes.
5.5 Memory Function
The light will remember the last brightness setting used when it was turned off via the remote control.
- When you turn the light back on, it will resume the previously set brightness level.
6. Product Features
The ROKU LED Ceiling Light incorporates several advanced features for optimal performance and user convenience.
- High Color Rendering (RA>=85): Provides illumination close to natural light, enhancing visual comfort and making colors appear more vibrant.
- Energy Efficient: Consumes approximately half the power of traditional fluorescent lamps, contributing to energy savings.
- Long Lifespan: Designed for a lifespan of 50,000 hours, significantly longer than conventional lighting.
- Compact and Lightweight Design: The thin and light fixture minimizes occupied space and simplifies installation and relocation.
- Dust and Insect Proof: Designed to prevent dust and insects from entering the fixture, maintaining cleanliness and light quality.
Image 6.1: The compact and lightweight design simplifies handling and installation.
Image 6.2: High color rendering (RA>=85) ensures colors appear true to life.
7. Maintenance
To ensure the longevity and optimal performance of your LED ceiling light, follow these simple maintenance guidelines:
- Cleaning: Gently wipe the surface of the light fixture with a soft, dry cloth. For stubborn dirt, use a slightly damp cloth with mild soap, then wipe dry immediately. Do not use abrasive cleaners, solvents, or harsh chemicals.
- Inspection: Periodically check the mounting hardware to ensure the fixture remains securely attached to the ceiling.
- No User-Serviceable Parts: The LED light source is integrated and not user-replaceable. Do not attempt to open the fixture.
8. Troubleshooting
If you encounter any issues with your ROKU LED Ceiling Light, please refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not turn on. | No power supply. Loose connection. Remote control batteries are dead. | Check the main power switch. Ensure all connections are secure (after turning off power). Replace remote control batteries (AAA). |
| Remote control not working. | Batteries are dead or incorrectly inserted. Obstruction between remote and light. Remote not paired (unlikely for this model). | Replace batteries and ensure correct polarity. Remove any obstructions. Ensure you are within range. If issues persist, contact customer support. |
| Light flickers or dims unexpectedly. | Unstable power supply. Loose wiring. Product malfunction. | Check household electrical system. Verify wiring connections (after turning off power). Contact customer support if the problem continues. |
If the problem persists after attempting these solutions, please contact our customer support for assistance.
9. Specifications
Detailed technical specifications for the ROKU LED Ceiling Light (Model B0BYJ6SX36):
| Feature | Specification |
|---|---|
| Model Number | B0BYJ6SX36 |
| Brand | ROKU |
| Color | 2-Pack |
| Material | Plastic |
| Style | Stepless Dimming & Color Adjustment |
| Fixture Shape | Close to Ceiling |
| Room Type | Kitchen, Living Room, Bedroom |
| Power Source | AC |
| Special Feature | Cordless (Remote Control) |
| Control Method | Remote |
| Light Source Type | LED |
| Number of Light Sources | 6 |
| Voltage | 100 Volts (AC) |
| Lighting Method | Adjustable |
| Wattage | 40 W (Max 45W) |
| Luminous Flux | 4950 lm |
| Mounting Type | Single Circuit |
| Fixture Type | Non-removable |
| Installation Type | Semi-flush Mount |
| Assembly Required | Yes |
| Case Shape | Round |
| Item Dimensions (L x W x H) | 30 cm x 30 cm x 5.8 cm |
| Item Weight | 0.49 Kilograms |
| Number of Items | 1 (per unit, 2 units in package) |
| Number of Units | 1.0 Unit (per unit, 2 units in package) |
| UPC | 735530750360 |
10. Warranty and Support
Your ROKU LED Ceiling Light comes with a 3-year warranty from the date of purchase.
All ceiling light units undergo inspection before shipment to ensure proper functionality. If your ceiling light fails to illuminate or if you encounter any other issues during the warranty period, please do not hesitate to contact us.
Customer Support
For any inquiries or support needs, please contact us via email. We aim to respond to all queries within 24 hours.
Contact Email: support@roku.com (Example email, please refer to your purchase documentation for the correct contact information).
