Lyridz A5262 Bedside Lamp User Manual

1. Introduction

Thank you for purchasing the Lyridz A5262 Bedside Lamp. This manual provides detailed instructions for the safe and efficient use of your new lamp. Please read this manual thoroughly before use and retain it for future reference.

The Lyridz A5262 is a versatile and eye-friendly bedside lamp designed for various uses, including nursing, reading, and general ambient lighting. It features touch control, adjustable color temperature and brightness, and a portable design with a long-lasting rechargeable battery.

2. Safety Instructions

• Do not disassemble, repair, or modify the product. This may cause electric shock, fire, or damage.
• Keep the lamp away from water or other liquids to prevent electric shock.
• Do not expose the lamp to extreme temperatures, direct sunlight, or high humidity.
• Use only the provided charging cable or a certified Type-C cable for charging.
• Keep out of reach of small children unless under adult supervision. The product is designed with child safety in mind (BPA-free, rounded edges), but caution is always advised.
• If the product is damaged, discontinue use immediately and contact customer support.

3. Product Overview

Components:

• Lyridz A5262 Bedside Lamp
• Type-C USB Charging Cable
• User Manual

Key Features:

• One-Touch Control: Simple tap on the top sensor for power ON/OFF.
• Adjustable Color Temperature: Three practical light colors (Warm White, Cool White, Daylight) with stepless adjustment from 2700K to 6500K.
• Stepless Dimming & Memory Function: Adjust brightness from 1lm to 100lm with a long press, or choose from 5 preset levels with a short press. The lamp remembers your last setting.
• Eye-Friendly RG0 Light: LED light source with uniform illumination, glare-free, and certified RG0 level for no harmful blue light, protecting eyes and sleep rhythm.
• Long-Lasting Battery: Built-in 3000mAh battery provides approximately 6 to 200 hours of continuous use on a single charge.
• Portable Design: Lightweight and includes a strap for easy carrying.
• Durable & Safe Materials: Made from high-quality ABS and polycarbonate, completely BPA-free.

Image 3.1: Overview of Lyridz A5262 Bedside Lamp highlighting its features like one-touch control, 3 color options, RG0 certification, 3000mAh battery, and Type-C charging.

4. Setup

4.1 Initial Charging

1. Before first use, fully charge the lamp.
2. Connect the provided Type-C USB cable to the charging port on the lamp.
3. Connect the other end of the USB cable to a compatible USB power adapter (not included) or a computer USB port.
4. The charging indicator light will show the charging status (e.g., red for charging, green for fully charged).
5. A full charge takes approximately 3 hours.

Image 4.1: The Lyridz A5262 lamp on a table, demonstrating its use and highlighting the internal 3000mAh battery.

5. Operating Instructions

5.1 Power ON/OFF

• To turn the lamp ON or OFF, simply tap the top touch sensor of the lamp.

Image 5.1: A hand interacting with the top touch sensor of the lamp for easy power control.

5.2 Adjusting Color Temperature

• Locate the 'Color' button on the side of the lamp.
• Short press the 'Color' button to cycle through the three preset color temperatures: Warm White, Cool White, and Daylight.
• Long press the 'Color' button for stepless adjustment of the color temperature between 2700K and 6500K. Release when the desired color is reached.

Image 5.2: The lamp displaying its three primary color modes, adjustable via the side 'Color' button.

5.3 Adjusting Brightness (Dimming)

• Locate the 'Dimming' button on the side of the lamp.
• Short press the 'Dimming' button to cycle through 5 preset brightness levels (1lm to 100lm).
• Long press the 'Dimming' button for stepless brightness adjustment. Release when the desired brightness is reached.
• The lamp will remember your last brightness setting when turned off and on again.

Image 5.3: Demonstrating the brightness adjustment feature, offering both preset levels and stepless dimming.

5.4 Power Button

• The 'Power' button on the side acts as a master power switch. Use it to completely turn off the lamp and save battery when not in use for extended periods.

6. Maintenance

6.1 Cleaning

• Ensure the lamp is turned off and unplugged before cleaning.
• Wipe the lamp with a soft, dry cloth. Do not use abrasive cleaners, solvents, or harsh chemicals.
• Avoid getting moisture into any openings.

6.2 Storage

• Store the lamp in a cool, dry place when not in use for extended periods.
• Charge the battery at least once every three months to maintain battery health.

7. Troubleshooting

• Lamp does not turn on:
    - Ensure the battery is charged. Connect the lamp to a power source using the Type-C cable.
    - Check if the master 'Power' button on the side is in the ON position.
• Brightness or color cannot be adjusted:
    - Ensure the lamp is turned on. Try tapping the top sensor or pressing the side 'Power' button.
    - If using the touch sensor for dimming, ensure you are long-pressing for stepless adjustment.
• Short battery life:
    - Ensure the lamp is fully charged before use.
    - Battery life varies significantly with brightness settings. Higher brightness consumes more power.
• Lamp flickers or behaves erratically:
    - Try fully charging the lamp.
    - If the issue persists, contact customer support.

8. Specifications

9. Warranty and Support

Lyridz products are designed for quality and reliability. For warranty information, technical support, or any questions regarding your Lyridz A5262 Bedside Lamp, please refer to the contact information provided on the product packaging or visit the official Lyridz website.

Please retain your proof of purchase for warranty claims.

10. Usage Scenarios

The Lyridz A5262 Bedside Lamp is ideal for various situations:

• Nighttime Nursing & Diaper Changes: The soft, warm light (RG0) is gentle on baby's eyes and helps parents navigate in the dark without disturbing sleep.
• Bedtime Reading: Adjust to a brighter, cooler light for comfortable reading before sleep.
• Ambient Lighting: Create a cozy atmosphere in any room with adjustable brightness and color.
• Portable Light Source: Easily carry the lamp using its strap for trips to the bathroom or around the house at night.

Image 10.1: Examples of the lamp's versatility in various daily and nighttime scenarios.

Image 10.2: The lamp providing gentle, blue-light-free illumination for a sleeping baby.

Image 10.3: The lamp's portable design, easily carried by its integrated strap.
