1. Introduction
Thank you for purchasing the INVITOP LED Ceiling Light, Model HS618. This modern and energy-efficient lighting fixture offers stepless dimming and color temperature adjustment, controllable via a remote or smartphone app. Its versatile design is suitable for various indoor spaces, providing comfortable and customizable illumination.
2. Safety Information
- Always turn off the main power supply before installation, removal, or maintenance to prevent electric shock.
- Ensure the installation surface is stable and can support the weight of the light fixture.
- Do not attempt to modify the product. Any unauthorized modifications may void the warranty and pose safety risks.
- Keep the product away from water and high humidity environments.
- If you are unsure about the installation process, consult a qualified electrician.
3. Product Specifications
| Feature | Description |
|---|---|
| Brand | iNVItop |
| Model Number | HS618 |
| Product Dimensions | 60 x 60 x 8 cm (approx. 23.6 x 23.6 x 3.1 inches) |
| Weight | 2.9 kg (approx. 6.4 lbs) |
| Color | Black Frame |
| Material | Plastic, Metal |
| Style | Stylish, Nordic |
| Light Source Type | LED |
| Control Method | Remote Control, Smartphone App (iOS/Android) |
| Features | Stepless Dimming, Color Temperature Adjustment, Night Light Mode, Timer Function, High Color Rendering (Ra80+) |
| Applicable Area (40CM model) | 6-10 Tatami (approx. 9.7-16.2 sq meters or 104-174 sq ft) |
The INVITOP LED Ceiling Light is available in various sizes to suit different room dimensions. The 40CM model is suitable for areas of 6-10 tatami. Other sizes (M: 50*14cm, 36W for 8-10 tatami; L: 60*14cm, 45W for 10-14 tatami) may also be available.
Image: Size variations for the INVITOP LED Ceiling Light, showing dimensions, weight, wattage, and recommended room size in tatami for each model (S, M, L).
4. Setup and Installation
The INVITOP LED Ceiling Light is designed for easy, no-construction installation using standard hook-on compatible wiring fixtures. Please follow these steps carefully:
4.1 Compatible Wiring Fixtures
Ensure your ceiling has one of the following compatible wiring fixtures:
Image: Illustration of different types of ceiling wiring fixtures compatible with the INVITOP LED Ceiling Light.
4.2 Installation Steps
- Turn off Power: Before starting, ensure the main power supply to the ceiling fixture is turned off at the circuit breaker.
- Connect Wiring: Connect the light fixture's wiring to your ceiling's compatible wiring fixture. Ensure a secure connection.
- Mount the Base: Secure the light's base to the ceiling fixture.
- Attach the Lampshade: Carefully attach the lampshade to the base, ensuring it is properly aligned and secured.
- Restore Power: Once installation is complete, turn the main power supply back on.
For a visual guide, please refer to the installation video below:
Video: Step-by-step guide on how to install the INVITOP LED Ceiling Light onto a compatible ceiling fixture.
5. Operating Instructions
The INVITOP LED Ceiling Light offers flexible control options via the included remote control or a dedicated smartphone application.
5.1 Remote Control Operation
Use the remote control to adjust various settings:
- Power On/Off: Press the power button to turn the light on or off.
- Brightness Adjustment: Use the brightness buttons to increase or decrease the light intensity steplessly.
- Color Temperature Adjustment: Adjust the color temperature from warm white (incandescent color) to cool white (daylight white) to natural light.
- Night Light Mode: Activate the low-power night light mode for soft illumination.
- Timer Function: Set a timer for automatic shutdown.
Image: Remote control functions for brightness and color temperature adjustment, illustrating the range from warm to cool light.
Video: Demonstration of the remote control adjusting the light's brightness and color temperature in a bedroom setting.
5.2 Smartphone App Control
The light can also be controlled via a smartphone app (iOS/Android). Download the dedicated app and follow the in-app instructions for pairing and control. The app provides similar functionalities to the remote control, including stepless dimming and color temperature adjustment.
Image: Smartphone app control in action, showing the light being adjusted remotely from a mobile device.
5.3 Energy Saving and Eye Protection
The light uses high-quality LED lamp beads for energy efficiency and a high Color Rendering Index (Ra80+), making colors appear natural. The acrylic lampshade provides soft, flicker-free illumination, protecting your eyes.
Image: Visual representation of the energy-saving benefits and superior color rendering (Ra85+) of the LED ceiling light compared to lower Ra values.
6. Maintenance
To ensure the longevity and optimal performance of your INVITOP LED Ceiling Light, follow these simple maintenance guidelines:
- Cleaning: Gently wipe the lampshade and frame with a soft, dry cloth. For stubborn dirt, a slightly damp cloth can be used, followed by a dry cloth. Avoid abrasive cleaners or solvents.
- Dust Removal: Regularly dust the light fixture to prevent accumulation, which can affect light output and aesthetics.
- Inspection: Periodically check for any loose connections or damage. If any issues are found, turn off the power and contact customer support.
7. Troubleshooting
If you encounter any issues with your INVITOP LED Ceiling Light, please refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not turn on | No power supply, loose connection, remote control battery low | Check power switch/circuit breaker. Ensure connections are secure. Replace remote control batteries. |
| Remote control not working | Batteries depleted, remote not paired, obstruction | Replace batteries. Re-pair remote if necessary (refer to app instructions). Remove any obstructions between remote and light. |
| Light flickers or dims unexpectedly | Unstable power supply, faulty wiring, internal component issue | Check household wiring. If problem persists, turn off power and contact customer support. |
| Cannot connect to smartphone app | Bluetooth/Wi-Fi off, incorrect pairing process, app issue | Ensure Bluetooth/Wi-Fi is enabled on your phone. Follow app pairing instructions carefully. Reinstall app if needed. |
If the problem persists after trying these solutions, please contact customer support for further assistance.
8. Warranty and Support
This INVITOP LED Ceiling Light comes with a 1-year warranty from the date of purchase. We are committed to providing reliable product support.
For any warranty claims or technical assistance, please contact us through your Amazon account. Navigate to 'Account Service' > 'Order History' > 'Ask a Question' for your specific order. Please include your order number and a detailed description of the issue. We aim to provide a resolution within 24 hours.
If your product arrived without a physical instruction manual, please contact us, and we will provide a digital English version.
9. Product Application Examples
The versatile design and adjustable lighting features of the INVITOP LED Ceiling Light make it suitable for various rooms and settings:
- Bedroom: Create a relaxing ambiance with warm, dim light or bright, cool light for reading.
- Living Room: Adjust lighting to suit different activities, from bright family gatherings to cozy movie nights.
- Children's Room: Utilize the night light mode for comfort and adjustable brightness for play or study.
- Hallways & Entrances: Provide clear and welcoming illumination in transitional spaces.
