KINGSMITH WR1 Water Rower Instruction Manual

1. Introduction

Welcome to your KINGSMITH WR1 Water Rower. This manual provides essential information for the safe assembly, operation, and maintenance of your fitness equipment. Please read this manual thoroughly before using the rower and retain it for future reference.

The KINGSMITH WR1 Water Rower, showcasing its full operational length and its compact, folded state for storage.

2. Safety Information

To ensure safe operation, please observe the following precautions:

• Consult a physician before starting any new exercise program.
• Ensure all parts are securely assembled before each use.
• Do not exceed the maximum user weight of 120 kg (264 lbs).
• Keep children and pets away from the equipment during operation.
• Use the rower on a stable, level surface.
• Wear appropriate athletic footwear and clothing.
• Stop exercising immediately if you feel faint, dizzy, or experience pain.

3. Package Contents

Please verify that all components are present before assembly. Refer to the packaging for a detailed list of included items. Typically, the package contains:

• KINGSMITH WR1 Water Rower main unit
• User Manual
• Assembly tools (if required)
• Water pump and purification tablets

4. Setup and Assembly

4.1 Unfolding the Rower

The KINGSMITH WR1 is designed for easy folding and storage, requiring minimal assembly. To unfold the rower:

1. Place the folded rower on a flat surface.
2. Carefully extend the main rail until it locks into place.
3. Ensure all locking mechanisms are engaged before use.

This image illustrates the dimensions of the KINGSMITH WR1 Water Rower when fully extended (206cm length, 50cm width, 56cm height) and its compact folded form, highlighting its space-saving design.

4.2 Filling the Water Tank

The water tank provides natural resistance for your workout. Follow these steps to fill it:

1. Remove the rubber stopper from the top of the water tank.
2. Use the provided pump to fill the tank with clean tap water to the indicated maximum level.
3. Add one purification tablet to the water to prevent algae growth.
4. Replace the rubber stopper securely.

5. Operating Instructions

5.1 Basic Operation

To begin your rowing workout:

1. Sit on the seat with your feet securely strapped into the footrests.
2. Grip the handle with both hands, palms down.
3. Push off with your legs, then lean back slightly and pull the handle towards your abdomen.
4. Return to the starting position by extending your arms, leaning forward, and bending your knees.

A user performing a rowing exercise on the KINGSMITH WR1 Water Rower, demonstrating the correct posture and engagement for a full-body workout.

5.2 LED Display

The integrated LED display provides real-time workout data:

• Speed: Current rowing speed.
• Distance: Total distance rowed during the session.
• Calories: Estimated calories burned.
• Time: Duration of the current workout.

5.3 KS Fit App Connection

Enhance your training experience by connecting your rower to the KS Fit app:

1. Download the KS Fit app from Google Play Store or Apple App Store.
2. Enable Bluetooth on your smartphone or tablet.
3. Open the KS Fit app and follow the on-screen instructions to pair with your KINGSMITH WR1 rower.
4. The app allows you to track progress, access various training modes, and adjust settings.

The KINGSMITH WR1 Water Rower featuring a tablet mounted on its holder, displaying the KS Fit application interface, which allows users to track their workout progress and adjust settings.

6. Maintenance

6.1 Cleaning

Regular cleaning helps maintain the rower's appearance and functionality:

• Wipe down the frame and seat with a damp cloth after each use.
• Avoid using abrasive cleaners or solvents.

6.2 Water Treatment

To keep the water clean and clear:

• Add a purification tablet every 3-6 months, or if the water appears cloudy.
• If the water becomes discolored, drain the tank and refill with fresh water and a new tablet.

6.3 Storage

When not in use, the rower can be folded for compact storage:

1. Ensure the rower is clean and dry.
2. Follow the reverse steps of unfolding to fold the rower.
3. Store in a cool, dry place away from direct sunlight.

The KINGSMITH WR1 Water Rower in its fully folded position, ready for compact storage, emphasizing its space-saving design.

7. Troubleshooting

If you encounter any issues, refer to the following common problems and solutions:

8. Specifications

9. Warranty and Support

Your KINGSMITH WR1 Water Rower comes with a standard manufacturer's warranty. Please refer to the warranty card included in your package for specific terms and conditions.

For technical support, spare parts, or warranty claims, please contact KINGSMITH customer service through their official website or the contact information provided with your purchase.
