Comfytemp TENS Unit Muscle Stimulator Instruction Manual

Introduction

The Comfytemp TENS Unit Muscle Stimulator is designed to provide targeted, drug-free pain relief through electrotherapy. This device offers 24 pre-set modes and 40 intensity levels, making it suitable for various body parts and pain conditions. Its dual-channel functionality allows for independent intensity control, catering to different needs simultaneously. The compact, rechargeable design ensures portability and convenience for use at home or on the go.

What's in the Box

• 1 x Comfytemp TENS Machine
• 2 x Electric Wires
• 8 x TENS Unit Replacement Pads (2 large 2.4 x 4 inches for back/legs; 6 small 1.8 x 1.8 inches for joints)
• 1 x Storage Bag
• 1 x Type-C Cable
• 1 x Backclip
• 1 x Pads Storage Board
• 1 x Pressure Sensitive Tape
• 1 x User Manual

Image: The Comfytemp TENS Unit with all included accessories, neatly arranged.

Product Features

• Pain Relief: Pre-set modes include acupuncture, tapping, scraping, kneading, pressing, and massage to help relieve pain. With 24 modes and 40 intensity levels, this electrotherapy muscle stimulator offers targeted, drug-free pain relief for various conditions.
• Large Screen & Easy to Use: Features a 1.7"*2.2" large screen and intuitive buttons for easy readability and operation, especially beneficial for middle-aged and elderly individuals.
• Independent Intensity Control: Allows separate intensity settings for Channel A and Channel B, enabling customized treatment for different body parts simultaneously.
• Safety Designed: Includes an electrode dislodgement alert that immediately stops current output if pads detach, and a one-tap pause function for quick operation cessation.
• Rechargeable & Compact: Powered by a built-in 300mAh battery for up to 20 hours of use on a single charge, with USB-C fast charging. Its compact size makes it easy to store and transport.

Safety Information

Caution:

• Do not use this product if you have an implanted defibrillator, cardiac pacemaker, or any other implanted metallic or electronic device.
• This unit is not a medical device and is not intended to diagnose or treat any medical condition or disease.
• If you have any of the following conditions (such as acute illness, tumor, pregnancy, heart disease, high fever, abnormal blood pressure, abnormal skin condition, etc. that require the active supervision of a doctor), please read the Comfytemp TENS device user manual or consult your physician for use.

Setup

1. Ensure the TENS unit is fully charged using the provided USB-C cable.
2. Connect the electric wires to the electrode pads. Each wire typically has two connectors for two pads.
3. Clean and dry the skin area where you intend to place the electrode pads.
4. Remove the protective film from the electrode pads.
5. Firmly apply the electrode pads to the desired treatment area on your skin. Ensure both pads connected to a single channel are placed on the body to form a closed circuit.
6. Plug the electric wires into the corresponding ports (Channel A or Channel B) on the top of the TENS unit.

Image: A close-up view of the TENS unit with electrode pads connected via electric wires, ready for application.

Operating Instructions

1. Turn on the device using the ON/OFF switch located on the side. The large screen will illuminate.
2. Press the 'MODE' button to cycle through the 24 available massage modes (e.g., acupuncture, tapping, kneading).
3. Use the 'A+' or 'A-' buttons to adjust the intensity for Channel A. Use 'B+' or 'B-' for Channel B. Start with the lowest intensity and gradually increase until a comfortable sensation is felt.
4. Press the 'SET' button to adjust the treatment timer. The timer can be set from 10 to 60 minutes.
5. To pause the treatment at any time, press the 'STOP' button. Press it again to resume.
6. The device features independent intensity control for dual channels. This allows you to apply different intensity levels to different body parts simultaneously.

Image: The TENS unit's display screen, illustrating the selection of different pre-set massage modes.

Electrode Pad Placement

Proper placement of electrode pads is crucial for effective and safe treatment. Refer to the included user manual for detailed diagrams and recommended placements for specific pain areas. Generally, place pads on clean, dry skin, ensuring they are not directly over joints, open wounds, or sensitive areas. For dual-channel use, ensure pads for each channel are placed on the same side of the body or on areas that require similar intensity.

Image: A diagram illustrating recommended electrode pad placements on the human back for various pain relief applications.

Maintenance and Care

• Cleaning the Device: Wipe the TENS unit with a soft, damp cloth. Do not use abrasive cleaners or immerse the device in water.
• Cleaning Electrode Pads: If the adhesive on the pads becomes less sticky, gently wipe the adhesive surface with a damp cloth or a drop of water. Allow them to air dry completely before re-applying the protective film.
• Storage: Store the device and pads in the provided storage bag in a cool, dry place away from direct sunlight and extreme temperatures. Ensure the protective film is reapplied to the pads after each use to prolong their lifespan.
• Battery Care: Recharge the device regularly, even if not in frequent use, to maintain battery health. Avoid fully discharging the battery for extended periods.

Troubleshooting

• No Sensation: Ensure the device is turned on, the intensity is set above zero, and both electrode pads for the active channel are firmly attached to the skin. Check that the electric wires are securely plugged into both the pads and the device.
• Weak Sensation: Increase the intensity level gradually. Ensure the pads are making full contact with clean, dry skin. The pads may need cleaning or replacement if they are old or dirty.
• Irritation at Pad Site: Discontinue use if skin irritation occurs. Ensure pads are not placed over broken or irritated skin. Clean the skin thoroughly before application.
• Device Not Turning On: Check the battery level. If low, charge the device using the USB-C cable.
• Uneven Sensation Between Channels: Verify that the intensity levels for Channel A and Channel B are set appropriately and independently.

Specifications

• Package Dimensions: 5.94 x 3.78 x 3.03 inches; 10.86 ounces
• Batteries: 1 Lithium Polymer battery required (included)
• Date First Available: January 18, 2023
• Manufacturer: Comfytemp
• ASIN: B0BSL9GTHQ

Warranty and Support

The Comfytemp TENS Unit Muscle Stimulator comes with a 365-day warranty. For any product-related inquiries or support, please contact Comfytemp customer service. They offer 24-hour quick customer support to assist you with any issues or questions you may have.

Please retain your proof of purchase for warranty claims.
