Important Safety Information
Please read all instructions carefully before installation and use. Failure to follow these instructions may result in electric shock, fire, or other injuries. Keep this manual for future reference.
- Ensure the power outlet is a Ground Fault Circuit Interrupter (GFCI) outlet, 120 Volts.
- Do not immerse the product in water or other liquids.
- Unplug the unit before cleaning or servicing.
- Keep the remote control dry and away from water.
- This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Package Contents
Verify that all components are present and undamaged before beginning installation.
- Brondell CL950-RW Swash Luxury Bidet Toilet Seat
- Wireless Remote Control
- Installation Parts (T-Valve connector, mounting hardware, water supply hose)
- Batteries for Remote Control (Alkaline)
Image: The Brondell CL950-RW bidet toilet seat in white, shown with its wireless remote control. The seat features a sleek design with control buttons on the back panel and the remote displays various wash and dry functions.
Installation
1. Pre-Installation Check
- Ensure your toilet is a Round Fit. The distance from the toilet's bolt holes to the front of the bowl should be between 16.5 and 17.75 inches.
- Verify a dedicated 120 Volt GFCI (Ground Fault Circuit Interrupter) electrical outlet is available near the toilet.
Image: A diagram illustrating the required dimensions for a round toilet seat fit, indicating a distance of 16.5 to 17.75 inches from the bolt holes to the front of the bowl.
Image: An illustration showing a standard 120 Volt GFCI electrical outlet and a T-valve connector for simple water line connection, indicating installation requirements.
2. Basic Installation Steps
- Turn off the water supply to your toilet at the shut-off valve.
- Flush the toilet to drain the tank.
- Remove your existing toilet seat and lid.
- Install the provided T-valve connector between the toilet fill valve and the water supply line.
- Mount the bidet seat to the toilet bowl using the provided mounting hardware. Ensure it is securely fastened.
- Connect the bidet's water supply hose to the T-valve.
- Connect the power cord to the GFCI outlet.
- Slowly turn on the water supply and check all connections for leaks.
Operation
Remote Control Functions
The Brondell CL950-RW is operated via a wireless remote control. Ensure batteries are installed correctly in the remote.
Image: A detailed view of the Brondell CL950-RW wireless remote control, showing buttons for Rear wash, Front wash, Dry, Stop, Nozzle Position adjustment, Water Pressure/Dry Temperature adjustment, Water Temperature, Seat Temperature, Massage, Move, Auto Mode, and Deodorize functions, along with a battery indicator.
- Rear Wash: Initiates a posterior wash cycle.
- Front Wash: Initiates a feminine wash cycle.
- Dry: Activates the warm air dryer.
- Stop: Halts any active function.
- Nozzle Position: Adjusts the nozzle's forward or backward position.
- Water Pressure / Dry Temp: Increases or decreases water spray pressure or air dryer temperature.
- Water Temp: Adjusts the water temperature (multiple levels).
- Seat Temp: Adjusts the heated seat temperature (multiple levels).
- Massage: Provides a pulsating spray for enhanced cleaning.
- Move: Activates an oscillating nozzle movement for a wider cleaning area.
- Auto Mode: Initiates a preset wash and dry cycle.
- Deodorize: Activates the carbon deodorizer to neutralize odors.
- Battery: Indicates remote control battery status.
Image: An illustration demonstrating the adjustable settings on the remote control for seat temperature (Low), wash pressure (Strong), water temperature (High), and air dry (Medium).
Features Overview
The Brondell CL950-RW Swash Luxury Bidet Toilet Seat offers a range of features designed for comfort and hygiene:
- Adjustable Wash Settings: Customize spray and pressure patterns to your preference.
- Heated Water: Provides instant and continuous warm water for a comfortable wash.
- Warm Air Dryer: A gentle warm air stream reduces the need for toilet paper.
- LED Nightlight: An illuminating blue LED nightlight guides you in the dark.
- Automated Carbon Deodorizer: An integrated fan and carbon filter help neutralize bathroom odors.
- Gentle-Close Lid: The seat and lid close softly and quietly, preventing slamming.
- Stainless Steel Nozzle: A durable, rust-resistant nozzle that performs self-cleaning cycles.
- Eco Mode: An optional energy-saving mode to reduce power consumption.
Image: A collage highlighting key features: an oscillating stainless steel nozzle, a warm water wash spray, the convenient remote control, and a gentle closing lid mechanism.
Image: A collage showcasing additional features: an illuminating night light, a warm air dryer vent, the gentle closing lid, and the retractable nozzle.
Image: A close-up view of the bidet's stainless steel nozzle extending and spraying water, demonstrating its wash function.
Image: A close-up of the bidet seat's integrated carbon deodorizer filter, designed to reduce odors.
Image: The Brondell CL950-RW bidet seat with its blue LED nightlight illuminated, providing soft light in a dark bathroom setting.
Maintenance
Cleaning the Nozzle
The stainless steel nozzle performs a self-cleaning cycle before and after each use. For additional manual cleaning:
- Ensure the unit is unplugged from the electrical outlet.
- Gently pull the nozzle forward to extend it for cleaning.
- Wipe the nozzle with a soft cloth and a mild, non-abrasive cleaner.
- Push the nozzle back into its retracted position.
General Cleaning
- Always unplug the bidet seat before cleaning.
- Wipe the exterior surfaces with a soft, damp cloth and a mild, non-abrasive household cleaner.
- Do not use harsh chemicals, abrasive cleaners, or scrub brushes, as these can damage the finish.
- Ensure no water enters the electrical components or openings.
Water Filter (Optional)
Consider installing a Brondell water filter (sold separately) to prevent mineral buildup and maintain optimal performance, especially in areas with hard water. Refer to the filter's instructions for recommended replacement frequency.
Troubleshooting
If you encounter issues with your Brondell CL950-RW, please consult the table below before contacting customer support.
| Problem | Possible Cause | Solution |
|---|---|---|
| No power / Unit not turning on | Power cord unplugged, GFCI outlet tripped, remote batteries dead. | Check power connection, reset GFCI outlet, replace remote batteries. |
| No water spray / Weak spray | Water supply turned off, nozzle clogged, water pressure too low. | Ensure water supply is on, clean nozzle as per maintenance section, check household water pressure. |
| Water temperature not warm | Water heater setting too low, Eco Mode active. | Adjust water temperature setting on remote, disable Eco Mode if desired. |
| Seat not heating | Heated seat setting too low, Eco Mode active. | Adjust seat temperature setting on remote, disable Eco Mode if desired. |
| Leaks from connections | Loose connections, damaged washers. | Tighten all connections gently, ensure washers are properly seated. Do not overtighten. |
| Dryer not effective | Dryer temperature setting too low. | Increase dryer temperature setting on remote. |
| Remote control unresponsive | Dead batteries, obstruction between remote and seat sensor. | Replace remote batteries, ensure clear line of sight between remote and bidet seat. |
Specifications
| Feature | Detail |
|---|---|
| Model Number | CL950-RW |
| Shape | Round |
| Color | White |
| Material | Plastic |
| Power Supply | 120 Volts AC (GFCI outlet required) |
| Dimensions (L x W x H) | 49.53 x 38.74 x 15.49 cm (19.5 x 15.25 x 6.1 inches) |
| Item Weight | 6.35 kg (14 lbs) |
| Nozzle Material | Stainless Steel |
| Included Components | Bidet Seat, Remote Control, Installation Parts |
| Remote Batteries | Alkaline (Included) |
Warranty and Support
For detailed warranty information, product registration, and technical support, please refer to the official Brondell website or contact Brondell customer service directly. Keep your purchase receipt as proof of purchase for any warranty claims.
Brondell Inc. is the manufacturer of this product.
For further assistance, visit: www.brondell.com
Note: Warranty coverage and support procedures may vary by region and retailer.
