1. Introduction
Thank you for choosing the SQRMINI MY002 Mini Bluetooth Earbuds. This manual provides detailed instructions for setting up, operating, and maintaining your earbuds to ensure optimal performance and longevity. Please read this manual thoroughly before use.
The SQRMINI MY002 earbuds are designed for comfort and versatility, featuring a mini, lightweight design, Bluetooth 5.3 technology, intuitive touch controls, and an extended battery life, making them suitable for various activities including sleep, sports, and daily use.
2. Package Contents
Please verify that all items listed below are included in your package:
- SQRMINI MY002 Mini Bluetooth Earbuds (L/R)
- Charging Case
- USB-C Charging Cable
- User Manual
Image: Package contents including earbuds, charging case, USB-C cable, and user manual.
3. Product Overview
Familiarize yourself with the components of your SQRMINI MY002 earbuds and charging case.
Image: SQRMINI MY002 earbuds and charging case.
Image: Close-up of SQRMINI MY002 earbuds, highlighting design and charging points.
4. Setup
4.1 Charging the Earbuds and Case
For first-time use, fully charge the earbuds and charging case.
- Charging the Case: Connect the provided USB-C cable to the charging port on the case and to a power source. The indicator light on the case will show charging status.
- Charging the Earbuds: Place the earbuds into their respective slots in the charging case. Ensure the charging contacts align. The earbuds will automatically begin charging. A blue indicator light may appear on the earbuds or case to confirm charging.
The earbuds provide up to 6 hours of listening time on a single charge. The charging case can provide approximately 2.5 additional charges, extending total playtime to up to 20 hours.
Image: Earbuds charging inside the case with indicator light.
4.2 Powering On/Off
- Power On: Open the charging case, and the earbuds will automatically power on.
- Power Off: Place the earbuds back into the charging case and close the lid. They will automatically power off and begin charging.
4.3 Pairing with a Device
The SQRMINI MY002 earbuds utilize advanced Bluetooth 5.3 technology for a stable connection.
- Ensure the earbuds are charged and inside the charging case.
- Open the lid of the charging case. The earbuds will enter pairing mode automatically.
- On your device (smartphone, tablet, laptop), enable Bluetooth.
- Search for available Bluetooth devices and select "MY002" from the list.
- Once connected, you will hear a confirmation tone, and the earbuds will be ready for use.
The earbuds will automatically connect to the last paired device when the charging case lid is opened, provided Bluetooth is enabled on the device.
Image: Earbuds and charging case next to a smartphone, ready for pairing.
5. Operating Instructions
5.1 Wearing the Earbuds
The MY002 earbuds feature a half in-ear ergonomic design, weighing only 2.7g (0.095oz) and measuring 1.3cm (0.51 inch), ensuring a lightweight and comfortable fit for extended periods. They are designed to be worn without pain, even when sleeping on your side.
Image: Woman sleeping with an earbud, demonstrating comfortable fit.
Image: Woman meditating with earbuds, showing discreet wear.
5.2 Touch Controls
The earbuds feature smart touch controls for easy management of audio playback and calls.
Image: Touch control diagram for SQRMINI MY002 earbuds.
| Action | Left Earbud | Right Earbud |
|---|---|---|
| Play/Pause | Tap Twice | Tap Twice |
| Volume Up | N/A | Tap Triple |
| Volume Down | Tap Triple | N/A |
| Answer/End Call | Press Once | Press Once |
| Reject Call | Press hold 2 seconds | Press hold 2 seconds |
| Activate Voice Assistant | Tap Quartic | Tap Quartic |
5.3 Single Earbud Mode
You can use either earbud independently for calls or music playback while maintaining awareness of your surroundings. Simply remove one earbud from the case, and it will connect to your device. The other earbud can remain in the case or be used by another person.
6. Maintenance
6.1 Cleaning
Regular cleaning helps maintain sound quality and hygiene.
- Gently wipe the earbuds and charging case with a soft, dry, lint-free cloth.
- Do not use harsh chemicals, cleaning solvents, or strong detergents.
- Avoid getting moisture in any openings.
6.2 Storage
Always store the earbuds in their charging case when not in use to protect them and keep them charged.
6.3 Water Resistance
The SQRMINI MY002 earbuds are IPX5-rated waterproof, offering protection against sweat, light rain, and splashes. They are not designed for submersion in water.
7. Troubleshooting
If you encounter any issues with your earbuds, please refer to the following common solutions:
- Earbuds Not Charging:
- Ensure the charging cable is securely connected to both the case and the power source.
- Check if the charging case itself has sufficient battery.
- Verify that the earbuds are correctly seated in the charging case and their charging contacts align.
- Earbuds Not Pairing/Connecting:
- Make sure Bluetooth is enabled on your device.
- Place the earbuds back into the charging case, close the lid, wait a few seconds, then open it again to re-enter pairing mode.
- Forget/delete "MY002" from your device's Bluetooth list and attempt to pair again.
- Ensure the earbuds are within the effective Bluetooth range of your device.
- No Sound or Low Volume:
- Increase the volume on both your connected device and using the earbud touch controls.
- Ensure the earbuds are properly seated in your ears for an optimal seal.
- Check if the earbuds are connected to the correct audio output on your device.
- Microphone Issues (e.g., during calls):
- Ensure the earbuds are properly connected and selected as the audio input device on your phone.
- Check for any obstructions around the microphone area on the earbuds.
- Test the microphone in a quiet environment to rule out background noise interference.
8. Specifications
Detailed technical specifications for the SQRMINI MY002 Mini Bluetooth Earbuds:
| Feature | Specification |
|---|---|
| Model Number | MY002 |
| Bluetooth Version | 5.3 |
| Earbud Weight | 2.7g (0.095oz) |
| Product Size (Earbud) | 0.51 inch (1.3cm) |
| Product Size (Case) | 45*45*25mm |
| Product Weight (with case) | 31.9g |
| Audio Sensitivity | 102dB SPL |
| Frequency Response | 20Hz-20kHz |
| THD+N | ≤1% |
| Impedance | 16 Ohm |
| Microphone | MEMS Omnidirectional Mic |
| Earbud Playtime | Up to 6 hours |
| Total Playtime (with case) | Up to 20 hours |
| Waterproof Rating | IPX5 |
| Battery Type | Lithium Polymer |
9. Warranty and Support
SQRMINI products are manufactured to high quality standards. This product is covered by a limited warranty from the date of purchase. For specific warranty terms and conditions, please refer to the documentation included with your purchase or contact your retailer.
For technical support, troubleshooting assistance, or any inquiries regarding your SQRMINI MY002 earbuds, please refer to the contact information provided with your product or visit the official SQRMINI support website.
