1. Introduction
This manual provides essential information for the safe installation, operation, and maintenance of your Ledvion IP65 GU10 LED Garden Spike Light. Please read these instructions carefully before use and retain them for future reference.
The Ledvion Garden Spike Light is designed for outdoor use, ideal for illuminating trees, bushes, facades, garden paths, and terraces. Its robust aluminum construction and IP65 rating ensure durability and protection against dust and water splashes.
2. Safety Information
- Ensure the power supply is disconnected before installation, maintenance, or bulb replacement.
- This product is designed for outdoor use with an IP65 rating, meaning it is protected against dust ingress and low-pressure water jets from any direction.
- Only use GU10 LED bulbs with a maximum wattage of 5W.
- Do not immerse the product in water.
- If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
- Ensure the ground spike is securely inserted into stable ground to prevent tipping.
- Keep out of reach of children.
3. What's in the Box
Verify that all components are present in the package:
- 1x Ledvion Garden Spike Light fixture with GU10 socket and 2m cable with EU plug
- 1x Allen key
- Instruction Manual
Image: Package contents including the garden spike light, manual, and Allen key.
4. Specifications
| Feature | Specification |
|---|---|
| Brand | Ledvion |
| Model Number | LVO10054 |
| Material | Aluminum |
| Color (Fixture) | Black |
| Dimensions (L x W x H) | 21 x 12 x 7 cm |
| Weight | 530 g |
| IP Rating | IP65 (Dust and splash-proof) |
| Socket Type | GU10 |
| Max Bulb Wattage | 5 Watts (GU10 LED) |
| Voltage | 230 Volts |
| Cable Length | 2 meters with EU plug |
| Installation Type | Ground mounting |
| Special Features | Adjustable head, Weather-resistant |
Image: Product dimensions and components.
Image: Illustration of IP65 water and dust resistance.
5. Setup and Installation
The Ledvion Garden Spike Light is designed for easy 'plug and play' installation.
- Choose Location: Select a suitable outdoor location in your garden or pathway where you wish to illuminate. Ensure the ground is soft enough to insert the spike securely.
- Insert GU10 Bulb: Twist open the front cover of the light fixture. Carefully insert a GU10 LED bulb (not included) into the socket. Ensure the bulb is seated correctly. Close the front cover securely to maintain the IP65 rating.
- Ground Mounting: Firmly push the ground spike into the soil until the light fixture is stable. Ensure the cable is not pinched or damaged during this process.
- Positioning: Use the adjustable head to direct the light beam towards your desired object (e.g., tree, plant, facade). The head can pivot 360 degrees.
- Connect Power: Plug the 2-meter connection cable into a suitable outdoor power outlet. Ensure the outlet is also weather-protected.
Image: GU10 socket for bulb installation.
Image: Plug and play installation example.
6. Operating Instructions
Once installed and connected to power, the Ledvion Garden Spike Light operates directly from the power supply. If your GU10 bulb supports remote control functionality, you may use a compatible remote to control the light. Otherwise, the light will turn on/off with the power supply.
- Adjusting Beam Angle: The light head can be adjusted to change the direction of the light beam. Loosen the screw on the side of the fixture using the provided Allen key, adjust the angle, and then tighten the screw to secure it.
Image: Adjustable beam angle feature.
7. Maintenance
- Cleaning: Disconnect power before cleaning. Wipe the fixture with a soft, damp cloth. Do not use abrasive cleaners or solvents.
- Bulb Replacement: Disconnect power. Twist open the front cover. Carefully remove the old GU10 bulb and insert a new one (max 5W LED). Securely close the front cover.
- Inspection: Periodically check the cable and plug for any signs of damage. Ensure the ground spike remains firmly in place.
8. Troubleshooting
- Light does not turn on:
- Check if the power plug is securely connected to a working outlet.
- Ensure the GU10 bulb is correctly installed and not faulty.
- Verify the power supply to the outlet is active.
- Light flickers:
- Ensure the GU10 bulb is fully seated in the socket.
- Try a different GU10 bulb to rule out a faulty bulb.
- Water inside the fixture:
- Immediately disconnect power.
- Ensure the front cover is tightly closed after bulb installation.
- If the issue persists, contact customer support.
9. Warranty and Support
The Ledvion Garden Spike Light comes with a 2-year warranty from the date of purchase, covering manufacturing defects. Please retain your proof of purchase for warranty claims.
Image: 2-year warranty information.
For technical support, warranty claims, or further inquiries, please visit the official Ledvion website or contact your retailer.
Official Website: www.ledvion.com
