1. Introduction
Thank you for choosing the Midea MAC46TFBW 2-in-1 Ice Cool Tower Air Cooler and Fan. This appliance is designed to provide both cooling and air circulation, enhancing comfort in your living space. It features a 2-in-1 design, combining a tower fan with an air cooler, and incorporates AirCooler Technology with a built-in water tank for enhanced cooling. The double filtration system helps ensure cleaner air. Please read this manual thoroughly before operation to ensure proper use, maintenance, and safety.
2. Important Safety Instructions
To reduce the risk of fire, electric shock, or injury, please observe the following safety precautions:
- Always unplug the appliance before cleaning, servicing, or moving.
- Do not operate any fan with a damaged cord or plug. Discard fan or return to an authorized service facility for examination and/or repair.
- Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over.
- Do not insert or allow fingers or foreign objects to enter any ventilation or exhaust opening as it may cause an electric shock or fire, or damage the fan.
- Do not block air openings or operate with any openings blocked. Keep openings free of lint, hair, and the like.
- Use this appliance only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.
- Do not use outdoors.
- This appliance is intended for household use only.
- Ensure the water tank is properly secured before operating the cooling function.
- Do not overfill the water tank.
3. Product Overview
Familiarize yourself with the components of your Midea MAC46TFBW air cooler.
Figure 3.1: Front view of the Midea MAC46TFBW 2-in-1 Ice Cool Tower Air Cooler. This image shows the sleek white and black design, with the air outlet grille and the visible water level indicator at the bottom front.
Figure 3.2: Side view of the Midea MAC46TFBW Air Cooler, highlighting its slim tower design suitable for various room layouts.
Figure 3.3: Close-up of the top control panel, showing the digital display and touch-sensitive buttons for various functions. A remote control is also visible on top of the unit.
Figure 3.4: Another view of the top control panel, providing a clear look at the button layout for power, mode, oscillation, and timer settings.
Components:
- Main Unit: The primary body of the air cooler.
- Control Panel: Located on top of the unit for manual operation.
- Digital Display: Shows current settings and status.
- Air Outlet Grille: Where the cooled air is expelled.
- Water Tank: Integrated at the bottom front, with a capacity of 7 liters.
- Remote Control: For convenient operation from a distance.
- Anti-dust Filter: Located at the rear for air purification.
- Anti-humidity Curtain: Part of the double filtration system.
- Ice Cool Accessory: Two ice cubes designed to be frozen and placed in the water tank for enhanced cooling.
4. Setup
The Midea MAC46TFBW air cooler requires no assembly and is ready for use out of the box.
- Unpacking: Carefully remove the air cooler from its packaging. Retain packaging for future storage or transport.
- Placement: Place the unit on a firm, level surface. Ensure there is adequate space around the unit for proper airflow (at least 20 cm from walls or furniture).
- Power Connection: Plug the power cord into a standard electrical outlet.
- Filling the Water Tank (for cooling function):
- Locate the water tank at the bottom front of the unit.
- Carefully pull out the water tank.
- Fill the tank with clean water, ensuring not to exceed the "MAX" fill line. The tank has a large capacity, storing up to 7 liters.
- For enhanced cooling, you can place the included Ice Cool Accessory (frozen ice cubes) into the water tank.
- Slide the water tank back into the unit until it clicks securely into place.
5. Operating Instructions
Your Midea MAC46TFBW can be operated using the control panel on the unit or the included remote control.
Control Panel and Remote Control Functions:
Figure 5.1: The remote control and a close-up of the unit's top panel, illustrating the ease of control.
Figure 5.2: This image emphasizes the convenience of controlling the unit with the remote, featuring a timer function for up to 7 hours.
- Power Button (⏻): Turns the unit ON or OFF.
- Mode Button: Cycles through different operating modes (e.g., Fan, Cool).
- Speed Button: Adjusts fan speed (Low, Medium, High).
- Oscillation Button (↻): Activates or deactivates the 60-degree horizontal oscillation feature, distributing air more widely.
Figure 5.3: The unit's 60-degree oscillation feature ensures wide air distribution for enhanced comfort.
- Timer Button: Sets the auto-off timer for up to 7 hours. Press repeatedly to select desired duration.
- Cooling Button (Snowflake icon): Activates or deactivates the air cooling function. Ensure the water tank is filled when using this mode.
Using the Ice Cool Accessory:
For an extra cooling boost, utilize the Ice Cool Accessory.
Figure 5.4: The Ice Cool Accessory, consisting of two cubes, can be frozen and added to the water tank for a cooler airflow.
- Place the two Ice Cool cubes in a freezer until completely frozen.
- Once frozen, open the water tank of the air cooler.
- Place the frozen Ice Cool cubes directly into the water tank.
- Close the water tank securely.
- Activate the cooling function on the unit. The frozen cubes will help lower the water temperature, resulting in cooler air output.
6. Maintenance
Regular maintenance ensures optimal performance and longevity of your air cooler.
Cleaning the Unit:
- Always unplug the unit before cleaning.
- Wipe the exterior surfaces with a soft, damp cloth. Do not use abrasive cleaners or solvents.
- For the water tank, remove it from the unit and rinse thoroughly with clean water. If necessary, use a mild detergent and a soft brush to clean the interior, then rinse well. Allow to air dry completely before reinserting.
Cleaning the Filters:
The unit features a double filtration system with an anti-dust filter and an anti-humidity curtain for cleaner air.
Figure 6.1: The air cooler features a double filtration system, including an anti-dust filter, to provide cleaner air.
- Locate the anti-dust filter at the rear of the unit.
- Carefully remove the filter.
- Rinse the filter under running water to remove accumulated dust. For stubborn dirt, a soft brush can be used.
- Allow the filter to air dry completely before placing it back into the unit.
- The anti-humidity curtain should also be checked periodically and cleaned if necessary, following similar steps.
Storage: If storing the unit for an extended period, ensure the water tank is empty and clean, and the filters are clean and dry. Store in a cool, dry place.
7. Troubleshooting
Before contacting customer support, please refer to the following table for common issues and their solutions.
| Problem | Possible Cause | Solution |
|---|---|---|
| Unit does not turn on. | No power supply. | Check if the power cord is securely plugged into a working outlet. |
| No cool air. | Water tank is empty or cooling function is not activated. | Fill the water tank. Ensure the cooling button (snowflake icon) is pressed. |
| Weak airflow. | Air filter is dirty or air inlet/outlet is blocked. | Clean the anti-dust filter. Ensure no obstructions are blocking the air inlets or outlets. |
| Unit is noisy. | Unit is not on a level surface or internal components are loose. | Place the unit on a flat, stable surface. If noise persists, contact customer support. |
| Remote control not working. | Batteries are dead or remote is too far/blocked. | Replace batteries. Ensure there are no obstructions between the remote and the unit. |
8. Specifications
Technical details for the Midea MAC46TFBW 2-in-1 Ice Cool Tower Air Cooler and Fan.
Figure 8.1: Diagram illustrating the dimensions of the Midea MAC46TFBW air cooler.
- Model: MAC46TFBW
- Type: 2-in-1 Tower Fan + Air Cooler
- Dimensions (L x W x H): 27 x 34.5 x 105 cm (10.6 x 13.6 x 41.3 inches)
- Item Weight: 10.5 kg (23.1 lbs)
- Water Tank Capacity: 7 Liters
- Material: Plastic, Metal
- Color: White and Black
- Special Features: Ice Cool Accessory, Remote Control, Oscillation, Timer
- Assembly Required: No
- Included Components: Remote control
9. Warranty and Support
Midea stands behind the quality of its products.
Warranty Information:
This Midea MAC46TFBW air cooler comes with a 1-year warranty on parts and labor from the date of purchase. This warranty covers manufacturing defects and malfunctions under normal use. Please retain your proof of purchase for warranty claims.
Figure 9.1: Midea offers guaranteed quality. (Note: The image shows "2 Años Garantía Total" which translates to "2 Years Total Warranty", but the product data states "1 year warranty on parts and labor". The text reflects the data from specifications for accuracy.)
Customer Support:
If you encounter any issues not covered in the troubleshooting section or require further assistance, please contact Midea customer support. Refer to the contact information provided with your product packaging or visit the official Midea website for support details.
If you are not satisfied with the performance of your Midea product, registered in time for the program, you may call the contact center within a maximum of 60 days after the product is delivered to your home, to request a change.
