Introduction
This manual provides comprehensive instructions for the safe and efficient use of your Redodo 24V 100Ah LiFePO4 Deep Cycle Lithium Battery. Please read this manual thoroughly before installation and operation to ensure optimal performance and safety.
Image: Redodo 24V 100Ah LiFePO4 Battery, front view showing the Redodo logo and 25.6V 100Ah rating.
Key Features
- Double Energy & Stable Performance: The Redodo 24V 100Ah LiFePO4 battery offers twice the energy capacity compared to a 12V 100Ah LiFePO4 battery, potentially saving on additional wiring and voltage balancing. High-quality LiFePO4 cells ensure extended cycle life and stable 24V output.
- Powerful 100A BMS & Grade-A Cells: An integrated 100A Battery Management System (BMS) supports a continuous charge/discharge current of 100A, 2560W charging power, and 2560Wh energy. The BMS provides essential protections, and Grade-A lithium cells ensure reliable battery quality.
- Scalable for Home Solar Systems: This battery can be expanded up to 4P2S (8 batteries) to form a 51.2V 400Ah LiFePO4 battery system with a maximum energy of 20.48kWh. It is an ideal choice for high-power or long-duration off-grid solar applications.
- Long Lifespan & Lightweight Design: Offers 4000+ cycles at 100% Depth of Discharge (DOD) with an estimated 10-year lifespan, significantly outperforming lead-acid batteries. Weighing only 22.04kg, it is approximately 1/3 the weight of comparable lead-acid batteries, enhancing portability for various applications.
- Trolling Motor Compatibility: Recommended for trolling motors with 45.4~54.4kg (100-120 lbs) thrust. Please note, this battery is not suitable for starting batteries or golf cart batteries.
Image: Diagram illustrating the powerful 100A BMS and Grade-A cells within the Redodo LiFePO4 battery.
Setup and Installation
Before installation, ensure all components are present and undamaged. Always prioritize safety during setup.
Unpacking
Carefully remove the battery from its packaging. Inspect the battery for any physical damage that may have occurred during shipping. If damage is found, do not proceed with installation and contact customer support.
Physical Dimensions
Understanding the battery's physical dimensions is crucial for proper placement and installation in your intended application.
Image: Redodo LiFePO4 Battery with indicated dimensions: 53.34 cm (length), 20.82 cm (width), and 21.59 cm (height).
Dimensions (L x W x H): 53.3 cm x 20.8 cm x 21.6 cm. Weight: 22.04 kg.
Wiring and Connection
Connect the battery terminals securely using appropriate cables and connectors. Ensure correct polarity (positive to positive, negative to negative) to prevent damage. For series or parallel connections, refer to the maximum system configuration guidelines to avoid overloading the battery or BMS.
Image: Illustration of multiple Redodo LiFePO4 batteries configured as part of a home solar system, demonstrating scalability.
The battery supports expansion up to 4P2S (8 batteries) for a 51.2V 400Ah system, achieving up to 20.48kWh of energy storage.
Operating Instructions
Charging the Battery
The Redodo LiFePO4 battery can be recharged efficiently using several methods:
Image: Visual representation of three charging methods: solar panels, generator, and a dedicated LiFePO4 battery charger.
- Solar Panels: Use solar panels with a minimum output of 800W for approximately 5 hours of charging time.
- Generator: Connect via a 20A DC to DC charger.
- LiFePO4 Battery Charger: Use a dedicated 20A LiFePO4 battery charger.
Power Output and Applications
The 24V 100Ah battery provides stable and reliable power for a variety of applications, offering extended run times for common appliances.
Image: Scene showing the Redodo battery in an outdoor setting, with icons indicating run times for a coffee maker, microwave, heater, and air conditioner.
- Coffee Maker (500W): Approximately 5 hours of operation.
- Microwave (800W): Approximately 3.2 hours of operation.
- Heater (1000W): Approximately 2.5 hours of operation.
- Air Conditioner (2000W): Approximately 1.28 hours of operation.
Maintenance
To ensure the longevity and optimal performance of your Redodo LiFePO4 battery, follow these maintenance guidelines:
- Keep the battery terminals clean and free from corrosion. Use a dry cloth to wipe them regularly.
- Store the battery in a cool, dry place when not in use, away from direct sunlight and extreme temperatures.
- Avoid fully discharging the battery for extended periods. For long-term storage, maintain a charge level between 50% and 80%.
- Regularly check the battery's voltage to monitor its state of charge and overall health.
- Do not expose the battery to water or excessive humidity.
Troubleshooting
This section addresses common issues you might encounter with your Redodo LiFePO4 battery and provides potential solutions.
| Problem | Possible Cause | Solution |
|---|---|---|
| Battery not charging | Incorrect charger, loose connections, charger malfunction | Ensure a compatible LiFePO4 charger is used. Check all cable connections for tightness. Test the charger with another device if possible. |
| Low power output | Battery not fully charged, excessive load, internal BMS protection activated | Fully charge the battery. Reduce the load connected to the battery. Check for BMS fault codes if your system provides them. |
| Battery not holding charge | Battery degradation, improper storage, BMS issue | Ensure proper storage conditions (temperature, charge level). If the battery is old and has exceeded its cycle life, consider replacement. Contact support if issues persist. |
| Overheating | Overcharging, excessive discharge current, poor ventilation | Use the correct charger with appropriate voltage and current. Ensure the load is within the battery's specifications. Provide adequate ventilation around the battery during operation. |
If you encounter issues not listed here, or if the suggested solutions do not resolve the problem, please contact Redodo customer support for further assistance.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Redodo |
| Battery Composition | Lithium Iron Phosphate (LiFePO4) |
| Model Name | 24V100Ah |
| Nominal Voltage | 25.6 Volts |
| Capacity | 100 Ah |
| Energy | 2560 Wh |
| Continuous Charge/Discharge Current | 100 A |
| Max. Power | 2560 W |
| Cycle Life | 4000+ cycles @ 100% DOD |
| Dimensions (L x W x H) | 53.3 cm x 20.8 cm x 21.6 cm |
| Item Weight | 22.04 kg |
| Battery Weight | 19.95 kg |
Note: Specifications are subject to change without notice. The nominal voltage is listed as 25.6V, consistent with typical 24V LiFePO4 systems.
Warranty and Support
Redodo is committed to providing excellent customer service and support for your product.
- Warranty: Your Redodo LiFePO4 battery comes with a 5-year warranty, ensuring peace of mind regarding product quality and performance.
- Customer Service: Redodo offers 24-hour customer service to assist with any inquiries or issues you may have.
- Technical Support: Benefit from lifetime technical assistance, providing expert guidance throughout the lifespan of your battery.
- Delivery: Products are shipped from our European warehouse, with an estimated delivery time of 3-7 business days.
Image: Map showing European delivery area with 3-7 business days delivery, alongside icons for 24-hour customer service, technical support, returns, and European warehouses.
For any inquiries, technical assistance, or warranty claims, please contact Redodo customer support through the official channels provided with your purchase.
