1. Introduction
Thank you for purchasing the Parrot Uncle 23-Inch Bladeless Chandelier Ceiling Fan. This manual provides essential information for the safe installation, operation, and maintenance of your new ceiling fan. Please read these instructions thoroughly before beginning installation and retain them for future reference.
2. Important Safety Instructions
- Always disconnect power at the main circuit breaker before installation or servicing.
- All wiring must be in accordance with national and local electrical codes. If you are unfamiliar with wiring, consult a qualified electrician.
- Ensure the installation site can support the fan's weight (approximately 15 pounds).
- Do not bend the fan blades during installation or cleaning.
- Keep children away from the fan during operation.
- Use only E12 base bulbs, maximum 20 watts each. Bulbs are not included.
3. Package Contents
Verify that all components are present before beginning installation:
- Ceiling Fan Unit
- Light Kit
- Remote Control
- Mounting Hardware
- Installation Instruction Manual
4. Product Features
- Modern Design: Combines a ceiling fan and chandelier light in one unit.
- Quiet, Reversible DC Motor: Provides powerful airflow with minimal noise. Reversible function allows for downwind cooling in summer and upwind air circulation in winter.
- Remote Control: Independent control for fan (6 speeds) and light functions. Includes sleep timer settings (1/3/6/8 hours).
- Easy Installation: Designed for quick and straightforward setup with included hardware.
5. Specifications
| Feature | Detail |
|---|---|
| Brand | Parrot Uncle |
| Model Name | F8238 |
| Color | Silver |
| Material | Acrylonitrile Butadiene Styrene, Glass, Iron, Crystal |
| Product Dimensions | 23.3"L x 23.3"W x 12.4"H |
| Item Weight | 15 Pounds |
| Power Source | DC |
| Voltage | 120 Volts |
| Number of Blades | 3 |
| Air Flow Capacity | 1530.32 Cubic Feet Per Minute |
| Light Source Type | Incandescent (E12 base) |
| Number of Light Sources | 5 |
| Wattage (Bulb) | Max 20 watts per bulb |
| Bulb Features | Not Dimmable (with standard bulbs) |
| Control Method | Remote Control |
| Installation Type | Semi Flush Mount |
| Indoor/Outdoor Usage | Indoor |
6. Setup & Installation
Installation of the Parrot Uncle ceiling fan is designed to be straightforward. It is recommended to have two people for installation. Please follow the detailed instructions provided in the separate installation guide included in your package.
6.1 Pre-Installation Checklist
- Ensure power is OFF at the circuit breaker.
- Confirm all parts listed in Section 3 are present.
- Prepare necessary tools (screwdriver, wire strippers, ladder, etc.).
6.2 Mounting the Fan
The fan supports semi-flush mount installation. Ensure the electrical box is securely mounted and capable of supporting the fan's weight.
Figure 1: Product Dimensions and Mounting Diagram. The fan has a diameter of 23.3 inches and a height of 12.4 inches.
6.3 Wiring
Connect the fan's wiring to your household wiring according to the provided wiring diagram in the installation guide. Ensure all connections are secure.
6.4 Installing Light Bulbs
This fan requires 5 E12 base bulbs, with a maximum wattage of 20 watts per bulb. Bulbs are not included. Install the bulbs into the sockets before attaching the light kit cover.
Figure 2: The Parrot Uncle Bladeless Chandelier Ceiling Fan with Lights.
7. Operating Instructions
Your Parrot Uncle ceiling fan is operated using the included remote control. Ensure the remote control has a CR2032 battery installed (not included).
7.1 Remote Control Functions
- Fan ON/OFF: Press the fan button to turn the fan on or off.
- Fan Speed Control: Use the speed buttons (1-6) to adjust the fan's rotation speed.
- Light ON/OFF: Press the light bulb button to turn the lights on or off.
- Timer Settings: Select 1, 3, 6, or 8 hours to set a sleep timer for the fan.
- Reversible Motor: The remote includes a button to reverse the fan's direction. This allows for downdraft (cooling) in warmer months and updraft (air circulation) in cooler months.
Figure 3: Internal Bladeless Fan Design.
8. Maintenance
Regular maintenance ensures optimal performance and longevity of your ceiling fan.
8.1 Cleaning
- Always turn off the power before cleaning.
- Wipe the fan and light fixture with a soft, damp cloth. Do not use abrasive cleaners or solvents.
- Avoid getting water into the motor housing or electrical components.
8.2 Bulb Replacement
- Ensure the power is off and bulbs have cooled before replacing.
- Replace with E12 base bulbs, maximum 20 watts.
9. Troubleshooting
If you experience issues with your fan, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Fan does not start | No power to the fan; Loose wire connections; Remote control battery low or missing. | Check circuit breaker; Verify all wire connections; Replace remote control battery (CR2032). |
| Lights do not work | Loose wire connections; Faulty bulbs; Remote control issue. | Check light kit wiring; Replace bulbs; Check remote battery. |
| Fan makes noise | Loose screws; Motor housing rubbing. | Tighten all screws; Ensure no parts are rubbing. |
| Remote not responding | Low or dead battery; Remote not paired (if applicable). | Replace CR2032 battery; Refer to the installation guide for remote pairing instructions. |
10. Warranty & Support
The Parrot Uncle 23-Inch Bladeless Chandelier Ceiling Fan (Model F8238) comes with a Lifetime Warranty. For any questions, technical assistance, or warranty claims, please contact Parrot Uncle customer service.
Please visit the official Parrot Uncle website or refer to your purchase documentation for specific contact details.
