Introduction
Thank you for choosing the EP Level 2 Portable EV Charger. This manual provides essential information for the safe and efficient operation of your new EV charger. Designed for convenience and performance, this charger offers fast and reliable charging for all electric and plug-in hybrid vehicles equipped with a SAE J1772 (Type 1) standard interface. Please read this manual thoroughly before use and retain it for future reference.
Important Safety Information
Always follow basic safety precautions when using electrical products to reduce the risk of fire, electric shock, and personal injury.
- Read all instructions: Before operating the charger, read and understand all instructions provided in this manual.
- Electrical Safety: Ensure the NEMA 14-50 outlet is properly installed and grounded by a qualified electrician. Do not use if the outlet is damaged or improperly wired.
- Avoid Water Exposure: Although the charger has an IP65 waterproof rating, avoid submerging it in water. Do not operate with wet hands or in extremely wet conditions.
- Cable Care: Do not drive over, kink, or pull the charging cable forcefully. Inspect the cable and plug for any damage before each use.
- Ventilation: Ensure adequate ventilation around the charger during operation to prevent overheating.
- Children and Pets: Keep the charger and cables out of reach of children and pets.
- Emergency Disconnect: In case of an emergency, immediately unplug the charger from the power source and disconnect it from the vehicle.
- Temperature Limits: Do not operate the charger outside its specified temperature range (-13°F to 122°F).
What's in the Box
- EP Level 2 Portable EV Charger (with NEMA 14-50P Plug and SAE J1772 Connector)
- Hook
- Holster Dock
- User Manual
Product Overview and Features
The EP Level 2 Portable EV Charger is designed for efficient and safe charging of your electric vehicle. It features a robust design and user-friendly controls.
Figure 1: Main components of the EP Level 2 Portable EV Charger, including the control box, J1772 charging connector, and NEMA 14-50P plug.
Key Features:
- Ultra-Fast Level 2 Charging: Delivers up to 40 Amp/240V and 9.6 KW power output, providing 29-36 miles of range per hour. Adjustable current settings (16A/32A/40A) allow customization based on electrical setup.
- Versatile & Weatherproof Design: IP65 waterproof rating, suitable for extreme temperatures (-13°F to 122°F), making it ideal for indoor and outdoor use.
- Portable & Wall-Mountable: Compact design with controller bracket and cable organizer for easy installation in a garage or portability for on-the-go charging. The 25-foot cable offers extended reach.
- Advanced Safety Features: Equipped with lightning protection, leakage protection, overvoltage protection, overcurrent protection, and overheating protection for a secure charging experience.
- Smart & User-Friendly Design: LCD display shows real-time charging details (voltage, current, charging time, energy consumption). Allows setting a custom charging schedule (1-10 hours) to optimize for off-peak electricity rates.
- Universal Compatibility: Adopts SAE J1772 (Type 1) standard interface, compatible with all electric and plug-in hybrid vehicles (Tesla requires a SAE J1772 adapter, not included).
Figure 2: The 25-foot premium cable provides ample length for flexible charging scenarios, allowing the charger to reach vehicles comfortably.
Figure 3: The charger's IP65 rating ensures durability and safety in various environmental conditions, including dust and water exposure.
Figure 4: Simple one-button settings allow users to adjust the current limit to match their home's circuit and set reserved charging times to avoid peak electricity rates.
Figure 5: The SAE J1772 (Type 1) standard interface ensures broad compatibility with most electric vehicles. A Tesla adapter is required for Tesla vehicles.
Figure 6: The charger offers flexibility for both permanent home installation and portable use, adapting to various charging needs.
Figure 7: The compact design and included carrying bag make the charger easy to store and transport, allowing for convenient charging anywhere.
Setup Instructions
The EP Level 2 Portable EV Charger is designed for simple plug-and-play installation, requiring no hardwiring.
- Prepare the Outlet: Ensure you have a dedicated NEMA 14-50 socket installed by a qualified electrician. Verify the outlet is in good condition and properly grounded.
- Mount the Charger (Optional): Use the provided hook and holster dock to mount the charger control box on a wall near your NEMA 14-50 outlet. This helps keep the charging area organized and secure.
- Plug in the Charger: Insert the NEMA 14-50P plug firmly into the NEMA 14-50 wall socket. The charger's LCD display should illuminate, indicating it is powered on.
- Initial Check: Observe the LCD display for any error messages. If a "ground fault" or other error is displayed, refer to the Troubleshooting section.
Operating Instructions
Using your EP Level 2 Portable EV Charger is straightforward. Follow these steps for optimal charging.
1. Connecting to Your Vehicle:
- Ensure the charger is plugged into the NEMA 14-50 outlet.
- Open your vehicle's charging port.
- Firmly insert the SAE J1772 connector into your vehicle's charging port. You should hear a click indicating it's securely latched.
- The charger's LCD display will show charging status, including current, voltage, and charging time. The green "CHARGING" indicator lights will illuminate.
2. Adjusting Current Settings:
The charger allows you to adjust the charging current (16A/32A/40A) to match your electrical circuit's capacity or your vehicle's charging needs.
- While the charger is connected to power but not actively charging a vehicle, press and hold the 'A' button (Ampere adjustment button) on the control box for a few seconds.
- The current setting on the LCD display will cycle through 16A, 32A, and 40A. Release the button when your desired current is displayed.
- The charger will remember this setting for future charging sessions until changed again.
3. Setting a Charging Schedule (Delay Charging):
You can set a delayed charging time (1-10 hours) to take advantage of off-peak electricity rates.
- While the charger is connected to power but not actively charging a vehicle, press the 'Clock' button (Time setting button) on the control box.
- Each press will increase the delay time by one hour, up to a maximum of 10 hours.
- The LCD display will show the set delay time. The charging process will begin automatically after the set delay.
- To cancel the delay, press the 'Clock' button until the delay time disappears or unplug and re-plug the charger.
4. Disconnecting After Charging:
- Once charging is complete, or you wish to stop, first disconnect the SAE J1772 connector from your vehicle's charging port.
- Then, unplug the NEMA 14-50P plug from the wall socket.
- Store the cable and connector neatly using the provided cable organizer and holster dock to prevent damage.
Maintenance
Proper maintenance ensures the longevity and safe operation of your EV charger.
- Cleaning: Disconnect the charger from power before cleaning. Use a soft, dry cloth to wipe the control box and cables. Do not use abrasive cleaners or solvents.
- Inspection: Regularly inspect the charging cable, plug, and connector for any signs of wear, cuts, or damage. If any damage is found, discontinue use immediately and contact customer support.
- Storage: When not in use, store the charger in a cool, dry place, away from direct sunlight and extreme temperatures. Use the cable organizer to prevent tangling and damage.
Troubleshooting
If you encounter issues with your EP Level 2 Portable EV Charger, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Charger not powering on / LCD display is blank. | No power from the NEMA 14-50 outlet, or charger is not fully plugged in. | Ensure the NEMA 14-50 plug is fully inserted into the wall socket. Check the circuit breaker for the outlet. Test the outlet with another device if possible. |
| "Ground Fault" error displayed. | Issue with the electrical grounding of the NEMA 14-50 outlet. | Immediately unplug the charger. Have a qualified electrician inspect the NEMA 14-50 outlet wiring to ensure proper grounding. Do not use the charger until the issue is resolved. |
| Charging not starting after connecting to vehicle. | Vehicle not ready to charge, charging port not fully engaged, or delayed charging set. | Ensure your vehicle is ready to accept a charge. Re-insert the J1772 connector firmly into the vehicle's port. Check the charger's display for a set delay time and wait for it to expire, or cancel the delay. |
| Charger stops charging unexpectedly. | Overheating, overcurrent, or other safety protection activated. | Check the charger's display for error codes. Ensure adequate ventilation around the charger. Reduce the charging current setting if the issue persists. If the problem continues, contact customer support. |
| LCD display shows incorrect readings (e.g., temperature). | Minor sensor discrepancy or environmental factors. | While minor variations can occur, if readings are consistently and significantly off, or if the charger is not performing as expected, contact customer support. |
If the problem persists after attempting these solutions, please contact EP customer support for further assistance.
Specifications
| Specification | Detail |
|---|---|
| Model Number | PEVC-40 |
| Input Voltage | 240 Volts AC |
| Output Voltage | 240 Volts AC |
| Adjustable Current | 16A / 32A / 40A |
| Maximum Power Output | 9.6 KW (at 40A) |
| Connector Type | SAE J1772 (Type 1) |
| Plug Type | NEMA 14-50P |
| Cable Length | 25 feet |
| Waterproof Rating | IP65 |
| Operating Temperature | -13°F to 122°F (-25°C to 50°C) |
| Item Weight | 14.07 pounds |
| Package Dimensions | 17.25 x 14 x 5.75 inches |
Warranty and Support
The EP Level 2 Portable EV Charger comes with a 2-year limited warranty. For warranty claims, technical support, or any questions regarding your product, please contact EP customer service through the retailer where you purchased the product or visit the official EP website for contact information.
Please have your model number (PEVC-40) and purchase date available when contacting support.
