1. Introduction
Thank you for choosing the WEYMIC SE-60 Professional Audio Mixer. This manual provides detailed instructions for the proper setup, operation, and maintenance of your mixer. To ensure optimal performance and longevity of your device, please read this manual thoroughly before use and retain it for future reference.
2. Safety Information
- Power Supply: Use only the provided 110V external power adapter. Ensure the voltage matches your local power supply.
- Water and Moisture: Do not expose this device to rain, moisture, or any liquids. Avoid placing objects filled with liquids on the unit.
- Ventilation: Ensure adequate ventilation around the unit. Do not block ventilation openings.
- Heat Sources: Keep the unit away from heat sources such as radiators, heat registers, stoves, or other heat-producing appliances.
- Cleaning: Disconnect power before cleaning. Use a dry, soft cloth. Do not use liquid cleaners or aerosols.
- Servicing: Do not attempt to service this unit yourself. Refer all servicing to qualified service personnel.
- Cable Protection: Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
3. Product Overview
The WEYMIC SE-60 is a compact 6-channel professional audio mixer designed for various applications including DJ performances, stage events, karaoke, and live recording. It features a durable full-metal body, sealed rotary controls for dust and dirt resistance, and offers dynamic control for clear audio reproduction.
Figure 3.1: Front view of the WEYMIC SE-60 Professional Audio Mixer, showing all inputs, outputs, and control knobs.
Key Features:
- 6-Channel Mixer: Provides multiple input options for microphones and instruments.
- Full Metal Body: Ensures durability and protection for internal components.
- Sealed Rotary Controls: Designed to resist dust and dirt, enhancing longevity.
- Integrated Bluetooth: For wireless audio streaming from compatible devices.
- USB Playback & Recording: Supports USB flash drives for MP3/WMA/APE/FLAC playback and direct computer recording.
- 48V Phantom Power: Essential for condenser microphones.
- HI-Z Input: Optimized input for high-impedance instruments like guitars.
- Built-in DSP Effect Chip: Offers various audio effects for enhanced sound.
- Independent Monitoring: Allows for separate headphone monitoring.
Figure 3.2: Top panel view of the WEYMIC SE-60 mixer, highlighting the various input channels and control knobs.
4. Setup
4.1 Power Connection
- Connect the provided 110V power adapter to the DC IN port on the mixer.
- Plug the power adapter into a suitable electrical outlet.
- Press the POWER button to turn on the mixer. The power indicator light will illuminate.
4.2 Connecting Microphones and Instruments
The SE-60 features four MIC/INST inputs (XLR/TRS combo jacks) and one stereo line input (CH 5-6 ST IN).
Figure 4.1: Detail of microphone inputs, 48V phantom power, and HI-Z buttons.
- Microphones: Connect dynamic microphones using XLR cables to MIC/INST 1-4. For condenser microphones, connect via XLR and activate the +48V PHANTOM POWER button for the respective channel.
- Instruments: Connect instruments like guitars or basses directly to MIC/INST 1-4 using a 1/4" TRS cable. Press the INST-HI-Z button for the corresponding channel to optimize the input impedance for instruments.
- Stereo Line Input: Use the CH 5-6 ST IN (1/4" TRS L/Mono and R jacks) for connecting stereo line-level devices such as keyboards or media players.
4.3 Connecting Output Devices
- Main Output: Connect your main speakers or amplifier to the MAIN OUT L and R (XLR or 1/4" TRS) jacks.
- Headphones: Plug your headphones into the PHONES (1/4" TRS) jack for monitoring.
4.4 Computer Connection (USB)
Connect the mixer to your computer using a USB cable. The mixer functions as an audio interface, allowing for recording and playback through your computer's audio software.
5. Operating Instructions
5.1 Basic Operation and Gain Staging
- Ensure all volume knobs (VOL) are set to minimum before powering on.
- Power on the mixer, then your amplifier/speakers.
- For each input channel, gradually increase the GAIN knob until the signal peak indicator (PK!) flashes only occasionally during the loudest parts of the performance. This sets the input level correctly.
- Adjust the channel VOL knob to balance the levels of different inputs.
- Use the MAIN OUT L/R level control to set the overall output volume.
5.2 Channel Controls
- HIGH: Adjusts the high-frequency (treble) content of the channel.
- LOW: Adjusts the low-frequency (bass) content of the channel.
- FX: Controls the amount of signal sent to the internal DSP effects processor.
- PAN: Positions the channel's sound within the stereo field (left to right).
- VOL: Adjusts the output volume of the individual channel.
5.3 Bluetooth Connectivity
The SE-60 features built-in Bluetooth for wireless audio streaming.
Figure 5.1: The mixer's Bluetooth feature being used with a smartphone.
- Press the MODE button on the MP3 player section until 'BT' is displayed on the screen.
- On your Bluetooth-enabled device (e.g., smartphone, tablet), search for available devices.
- Select 'WEYMIC SE-60' (or similar name) from the list to pair.
- Once paired, you can stream audio wirelessly to the mixer. Use the integrated controls (play/pause, skip tracks) on the mixer or your device.
5.4 USB Playback and Recording
The USB port allows for playback of audio files from a USB flash drive and connection to a computer for recording.
Figure 5.2: Detail of the USB port for media playback and computer connection.
- USB Playback: Insert a USB flash drive containing MP3, WMA, APE, or FLAC audio files into the USB port. The mixer will automatically detect and begin playback. Use the controls (play/pause, skip) on the mixer to manage playback.
- Computer Recording: Connect the mixer to your computer via USB. The mixer will be recognized as an audio input device. Open your preferred digital audio workstation (DAW) or recording software and select the WEYMIC SE-60 as the input device to record your mix.
5.5 DSP Effects
The mixer includes a built-in DSP effect chip. Use the FX knob on each channel to send a portion of that channel's signal to the effects processor. The overall effect level can be adjusted with the dedicated EFFECT LEVEL knob.
6. Maintenance
- Cleaning: Regularly wipe the mixer's surface with a soft, dry cloth. Avoid abrasive cleaners or solvents.
- Storage: When not in use, store the mixer in a cool, dry place, away from direct sunlight and extreme temperatures.
- Cable Care: Avoid bending or twisting cables excessively. Store them neatly to prevent damage.
7. Troubleshooting
- No Sound Output:
- Check if the mixer is powered on.
- Verify all cables are securely connected (inputs, main outputs, headphones).
- Ensure channel VOL and MAIN OUT level knobs are turned up.
- Check if the connected amplifier/speakers are powered on and functioning.
- Distorted Sound:
- Reduce the GAIN knob for the input channel to prevent clipping (PK! indicator flashing constantly).
- Lower the channel VOL or MAIN OUT level.
- Check if the connected audio source is sending a clean signal.
- Bluetooth Not Connecting:
- Ensure the mixer is in Bluetooth mode ('BT' displayed).
- Make sure Bluetooth is enabled on your device and it's within range.
- Try unpairing and re-pairing the device.
- USB Playback Not Working:
- Ensure the USB flash drive is properly inserted.
- Check that the audio files are in a supported format (MP3, WMA, APE, FLAC).
- Try a different USB flash drive.
- 48V Phantom Power Not Working:
- Ensure the +48V button is pressed for the specific channel.
- Verify that your condenser microphone requires phantom power.
8. Specifications
| Feature | Specification |
|---|---|
| Brand | WEYMIC |
| Model Number | SE-60 |
| Dimensions (L x W x H) | 34.01 x 19.99 x 8 cm (13.39 x 7.87 x 3.15 inches) |
| Item Weight | 1.47 Kilograms (3.24 lbs) |
| Number of Channels | 6 |
| Connectivity Technology | USB, Bluetooth |
| Power Source | Corded Electric |
| Voltage | 110 Volts |
| Audio Input | XLR, 1/4" TRS |
| Output Connector Type | TRS 6.35 mm (1/4" TRS), XLR |
| Phantom Power | +48V |
9. Warranty Information
The WEYMIC SE-60 Professional Audio Mixer comes with a standard manufacturer's warranty. Please refer to the warranty card included with your product or contact WEYMIC customer support for specific details regarding warranty coverage, terms, and conditions.
10. Support
For technical assistance, troubleshooting not covered in this manual, or any other inquiries, please contact WEYMIC customer support through their official website or the contact information provided with your purchase. Our support team is available to help you with any questions or issues you may encounter.
