iZEEKER iG600

iZEEKER Dual-Lens Trail Camera

User Manual - Model iG600

1. Introduction

This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your iZEEKER Dual-Lens Trail Camera. Designed for wildlife monitoring, this camera features 4K 48MP resolution, WiFi and Bluetooth connectivity, and advanced Starlight Night Vision capabilities. Please read this manual thoroughly before using the camera to ensure optimal performance and longevity.

iZEEKER Dual-Lens Trail Camera with SD card and AA batteries

Image 1.1: iZEEKER Dual-Lens Trail Camera, including the camera unit, SD card, and AA batteries.

Key Features:

  • Innovative Dual-Lens Design: Features two advanced optical lenses for superior image capture in varying light conditions.
  • Superb Starlight Night Vision: Automatically adjusts for low light, providing full-color images in dim conditions and clear black-and-white images in total darkness.
  • High-Resolution Imaging: Captures crisp 48MP photos and smooth 4K Ultra HD videos.
  • Fast Trigger Time: Achieves a rapid 0.1-second trigger time with a 120° detection angle.
  • WiFi & Bluetooth Connectivity: Allows for easy settings adjustment, live view, and direct content download via a smartphone app.
  • Durable Construction: IP66 waterproof material ensures reliable operation in various weather conditions.

2. What's in the Box

Upon unboxing your iZEEKER Trail Camera, please verify that all the following components are included:

  • iG600 Trail Camera x 1
  • SD Card (32GB) x 1
  • AA Alkaline Batteries x 4
  • USB Cable x 1
  • Tripod Mount x 1
Contents of the iZEEKER Trail Camera package including camera, strap, user manual, tripod mount, USB cable, and screws.

Image 2.1: All components included in the iZEEKER Trail Camera package.

3. Setup

3.1 Battery Installation

The iG600 Trail Camera requires 4 or 8 AA alkaline batteries for operation. For extended battery life, 8 batteries are recommended.

  1. Open the camera's main latch and then the battery compartment cover.
  2. Insert the AA batteries according to the polarity indicators (+/-) inside the compartment.
  3. Close the battery compartment cover securely, followed by the main latch to ensure a waterproof seal.

3.2 SD Card Installation

A 32GB SD card is included. The camera supports up to 256GB memory storage.

  1. Locate the SD card slot, typically near the battery compartment.
  2. Insert the SD card with the metal contacts facing down until it clicks into place.
  3. To remove, gently push the card in until it springs out.

3.3 Mounting the Camera

The camera can be mounted using the included strap for trees or the tripod mount for other surfaces.

  • Tree Mount: Thread the provided strap through the camera's mounting slots and secure it around a tree or pole. Adjust the strap for a snug fit.
  • Tripod/Wall Mount: Attach the tripod mount to the camera's bottom screw hole. Use screws to secure the mount to a wall or other flat surface, or attach it to a standard tripod.
iZEEKER Trail Camera mounted on a tree, with a smartphone displaying the camera's live view via WiFi app control.

Image 3.1: Camera mounted on a tree, demonstrating its outdoor placement.

3.4 Initial Power On and Basic Settings

After installing batteries and the SD card, power on the camera and configure initial settings.

  1. Locate the mode switch inside the camera. Slide it to the "SETUP" position.
  2. The internal display will turn on, allowing you to navigate the menu using the control buttons.
  3. Set the date, time, and preferred language.
  4. Format the SD card through the camera's menu to ensure compatibility and optimal performance.
  5. Once basic settings are configured, slide the switch to the "ON" position to activate monitoring mode.

4. Operating the Camera

4.1 Dual-Lens Technology and Night Vision

The iG600 features two distinct lenses: one optimized for daylight and another for low-light and night conditions, ensuring superior image quality around the clock.

Close-up of the iZEEKER dual lenses, showing a lowlight camera with Native 1080p Resolution and f/1.4 aperture, and a daytime camera with Ultra 4K 30fps Resolution and f/2.0 aperture.

Image 4.1: The camera's dual-lens system, featuring dedicated lenses for daytime and low-light conditions.

The camera automatically switches between lenses based on ambient light. In low-light conditions, the dedicated low-light lens captures up to 2x more light, while in total darkness, the 850nm low glow LEDs provide clear black-and-white images.

Three images showing a bird in full light (color), low light (color with less detail), and no light (black and white).

Image 4.2: Examples of image capture in full light, low light, and no light conditions.

4.2 Photo and Video Modes

The iG600 captures high-quality still images and video footage.

  • Photos: Up to 48MP resolution, providing vivid details.
  • Videos: Records 4K 30fps Ultra HD videos with clear sound, utilizing H.264 encoding for efficient storage.
A vibrant, detailed image of a flamingo with 'See Every Detail 4K Resolution' text overlay.

Image 4.3: Example of 4K resolution detail captured by the camera.

Video 4.1: Demonstrates the camera's ability to capture stunning wildlife moments with high clarity.

4.3 PIR Sensor and Trigger Speed

The camera's Passive Infrared (PIR) sensors detect motion and trigger recording rapidly.

  • Detection Angle: A 120° detection angle is achieved with one 60° central PIR sensor and two 30° side PIR sensors. Side sensors can be enabled or disabled in the menu.
  • Trigger Time: An ultra-fast 0.1-second trigger time ensures minimal delay between detection and capture.
  • Trigger Distance: The longest trigger distance is 65ft (20m).
Two cheetahs running, with text overlay 'Never miss a movement 0.1S Trigger Speed'.

Image 4.4: Illustrates the camera's rapid 0.1-second trigger speed.

A monkey and its baby on a tree branch, with a diagram showing the camera's 120 degree max detection angle and adjustable shooting range.

Image 4.5: Depicts the 120° maximum detection angle of the camera.

Video 4.2: Shows the camera's effectiveness in capturing motion, ensuring no interesting shots are missed.

4.4 WiFi and App Control

Connect your camera to your smartphone via WiFi for convenient control and content management.

  1. Download the
