ANRAN 5MP Wireless Outdoor Security Camera System User Manual

1. Introduction

This ANRAN wireless security camera system offers advanced surveillance features including 5MP ultra-high-definition video, 360° pan/tilt functionality, PIR motion detection, two-way audio, and continuous recording with a built-in 1TB HDD. Designed for outdoor use, it provides reliable security monitoring for your home or business with easy setup and comprehensive features.

2. Package Contents

Please verify that all items listed below are included in your package:

• 4CH Monitor NVR x 1 unit
• 1TB Hard Disk Drive x 1 (built-in NVR)
• 5MP Cameras x 4 units
• Camera Power Adapters (12V1A) x 4
• NVR Power Adapter (12V2A) x 1
• USB Mouse x 1
• Japanese Instruction Manual x 1
• 1M LAN Cable x 1
• Camera Mounting Screws x 4 sets

Image: Complete package contents of the ANRAN security camera system.

3. Key Features

• 360° Wide-Angle & Auto-Tracking: The dome-type cameras feature 355° horizontal pan and 90° vertical tilt, allowing for comprehensive area coverage. After setup, the cameras can automatically track detected motion.
• 5MP High-Resolution & Color Night Vision: Equipped with 5-megapixel resolution for clear images, surpassing standard 3-megapixel cameras. Features advanced night vision with both infrared and white LED lamps, enabling color recording when motion is detected at night.
• Two-Way Talk & PIR Motion Detection: High-quality microphone and speaker allow for clear two-way communication. The PIR motion sensor, combined with human shape detection technology, accurately identifies human movement and filters out animal alarms, sending real-time notifications to your smartphone.
• Easy Setup & 24/7 Continuous Recording: The system is pre-paired at the factory, requiring no complex wiring or pairing. Simply power on the cameras and NVR for immediate surveillance. A built-in 1TB HDD supports 24/7 continuous recording with automatic overwriting of old data, ensuring year-round coverage. Utilizes H.265+ compression for efficient storage.
• Certified & 1-Year Warranty: The product's power devices are PSE certified for electrical product safety. Comes with a 1-year warranty from the purchase date and a 30-day no-reason return service.

4. Setup Guide

The ANRAN wireless security camera system is designed for easy installation, even for beginners, with no complex construction required.

Step-by-Step Installation:

1. Unpack and Identify Components: Carefully remove all items from the packaging and ensure all package contents are present as listed in Section 2.
2. Power On Cameras: Connect each camera to its respective power adapter and plug it into a power outlet.
3. Power On NVR Monitor: Connect the NVR monitor to its power adapter and plug it into a power outlet.
4. Automatic Connection: The cameras and NVR are pre-paired from the factory. Once powered on, they will automatically connect, and live video feeds will appear on the NVR monitor.
5. Position Cameras: Mount the cameras in desired outdoor locations using the provided screws. Ensure they are within range of a power source and have a clear line of sight to the area you wish to monitor.

Image: Simple power connection for the camera and NVR.

Note: An internet connection is not required for local recording and viewing on the NVR. For remote viewing via smartphone or PC, an internet connection for the NVR is necessary (connect the NVR to your router via the included LAN cable).

5. Operating Instructions

5.1. Pan/Tilt/Zoom (PTZ) Control

The cameras offer extensive pan and tilt capabilities, allowing you to adjust the viewing angle remotely. Use the smartphone application to control the camera's movement:

• Pan: Rotate the camera horizontally up to 355°.
• Tilt: Adjust the camera vertically up to 90°.
• Digital Zoom: Pinch to zoom in/out on the live feed within the app to see more detail.

Image: Camera's 360° wide-angle pan and tilt functionality.

Image: Superior clarity of 5-megapixel resolution compared to 3-megapixel.

5.2. Motion Detection & Alerts

The system uses a PIR (Passive Infrared) motion sensor and human shape detection to accurately identify movement and send alerts.

• PIR Sensor: Detects objects with heat signatures (approx. 37°C / 98.6°F), reducing false alarms from non-human sources.
• Human Shape Detection: Further refines detection to focus on human figures.
• Real-time Notifications: When motion is detected, an alarm sound can be triggered, and a real-time notification is sent to your smartphone, allowing you to immediately check the live feed.
• Night Color Shooting: Upon detection, the camera can switch to color night vision mode, capturing clear facial details of intruders.

Image: PIR motion detection and high-brightness LED light in action.

5.3. Two-Way Audio Communication

Each camera is equipped with a high-quality microphone and speaker, enabling clear two-way communication.

• Remote Interaction: Speak to family members, pets, or deter intruders directly through the camera using your smartphone app from anywhere in the world.
• Noise Reduction: The system intelligently reduces noise for clearer audio capture.

Image: Two-way talk and PIR motion detection features.

5.4. Recording and Storage

The NVR comes with a pre-installed 1TB HDD for reliable video storage.

• 24/7 Continuous Recording: The system records continuously throughout the day.
• Automatic Overwrite: When the HDD is full, the system automatically overwrites the oldest footage with new recordings, eliminating the need for manual deletion.
• H.265+ Video Compression: Advanced compression technology saves approximately twice the storage space compared to traditional H.264, allowing for longer recording periods with the same quality.

5.5. Remote Access and Management

Access your security system from anywhere using the dedicated smartphone app or PC software.

• Live Viewing: Monitor your property in real-time.
• Playback: Review recorded footage directly from your device.
• Multi-Device Support: Manage multiple cameras and share access with family members or colleagues.

Image: Easy access and unified management via smartphone/PC.

6. Maintenance

Regular maintenance ensures optimal performance and longevity of your security system.

• Clean Camera Lenses: Periodically wipe the camera lenses with a soft, damp cloth to remove dust, dirt, or water spots that may obscure the view.
• Check Power Connections: Ensure all power adapters are securely plugged into outlets and cameras/NVR to prevent intermittent power loss.
• Verify Recording Status: Regularly check the NVR monitor or app to confirm that recording is active and functioning correctly.
• Firmware Updates: Check the manufacturer's website periodically for any available firmware updates to improve system performance and security.

7. Troubleshooting

If you encounter issues with your ANRAN security camera system, refer to the following common troubleshooting steps:

For more complex issues or if troubleshooting steps do not resolve the problem, please contact ANRAN customer support.

8. Specifications

9. Warranty and Support

ANRAN is committed to providing high-quality products and excellent customer service.

• Warranty Period: Your product is covered by a 1-year warranty from the date of purchase.
• Return Policy: Enjoy a 30-day no-reason return service.
• Contacting Support: If you have any questions, concerns, or require assistance with your surveillance camera, please do not hesitate to contact us.

Support Channels:

1. Via Order History: Contact the seller directly through your order history on Amazon.
2. Official Email & Phone: Our official email address and phone number can be found on the last page of the included instruction manual.

Support Hours:

• Phone Support: Monday - Friday, 10:00 - 13:00 & 14:30 - 19:30 (Japan Standard Time)
• Email Support: 24-hour response
