Introduction
Welcome to the world of high-speed slot car racing with your new AGM MASTECH Dual Track Set. This manual provides essential information for setting up, operating, and maintaining your racing set to ensure a safe and enjoyable experience. Please read all instructions carefully before assembly and use.
Safety Information
WARNING: Not suitable for children under 3 years due to small parts which may present a choking hazard. This product contains functional sharp edges. This is an electric toy and must only be used with the supplied transformer. The transformer is not a toy. Adult supervision is required at all times during use. Please read all instructions inside and retain this information for future reference. Colors and contents may vary from those shown on the box.
Always ensure the power adapter is disconnected from the main power supply before performing any assembly, disassembly, or maintenance.
Image: Safety warnings and product details on the packaging.
Package Contents
Before beginning assembly, please verify that all components listed below are present in your package:
- Bugatti & Audi Licensed Cars: 4
- Controllers: 2
- Control Box / Lap Counter: 1
- Straight Track Pieces: 14
- Curve Track Pieces: 20
- Cross Track Pieces: 2
- Narrow Track Piece: 1
- 1/4 Straight Track Pieces: 2
- Loop Track Pieces: 20
- Loop Supports: 8
- Jumping Adventure Piece: 1
- Power Adapter: 1
- Guardrails: 4
- Clips: 18
- Track Supports: 10
- Track Support Bases: 10
- Columns: 40
- Jumping Pieces: 2
Image: Visual representation of all components included in the set.
Setup Instructions
Track Assembly
The track features an easy-build and disassemble design. Carefully connect each track piece by aligning the connectors and pressing firmly until they snap together completely. Ensure all track pieces are securely joined to maintain electrical continuity and track stability. The set allows for multiple track configurations. Refer to the diagram below for three suggested layouts, including the 8.4m long track layout (Method 1) which requires a space of 175x95x32cm.
Image: Three possible track configurations, including the primary 8.4m layout.
Power Connection
Connect the power adapter to the control box. The control box then connects to the track. Ensure all connections are firm. Use only the original power adapter provided with the set. Do not use battery boxes or other adapters, as this may affect performance and stability.
Image: Illustration of the power adapter and control box connection to the track.
Operating Instructions
Placing Cars on Track
Carefully place each slot car onto its designated track slot. Ensure the guide pin on the bottom of the car is correctly inserted into the track's groove and the conductive brushes are making proper contact with the track's metal strips.
Speed Control
The hand controllers allow for precise speed management. Different levels of trigger press correspond to different speeds:
- Press Half: Deceleration for turns.
- Full Throttle: Straight acceleration for maximum speed.
- High Speed Key: Activates 360-degree circular high-speed flight (loops).
- Speed Limit Uniform Speed: You can properly tighten the speed limit pin on the controller to maintain a uniform speed, preventing the car from flying off the track due to excessive speed.
Image: Visual guide to controller speed settings and their effects on car movement.
Image: Flexible top speed options for different skill levels.
Car Features
The licensed cars are equipped with LED headlights and a strong magnetic base. The magnetic base enhances track adhesion, reducing the likelihood of derailing. However, it is still crucial to control speed, especially on turns, to prevent the car from flying off the track.
Image: Detail of the car's magnetic base and conductive sheet.
Track Features
The track set includes interchangeable loop and curve designs, allowing for dynamic racing. Springboard pieces can be added or removed freely to introduce additional challenges and excitement to your race.
Image: Examples of interchangeable loop and curve track sections.
Image: Instructions for adding springboard elements to the track.
Maintenance
Proper maintenance ensures the longevity and optimal performance of your slot car set. Follow these guidelines:
- Conductive Brushes: Ensure the conductive brush on the underside of each vehicle is at an angle of approximately 30 degrees to the rear of the vehicle for optimal contact.
- Guide Rod: Verify that the guide rod is aligned and properly inserted into the middle groove of the track.
- Track Connections: Regularly check that all interfaces of the track are tight and flat. Loose connections can lead to power interruptions and poor performance.
- Brush Blade Contact: Confirm that the brush blade makes consistent contact with the track metal strip and that the wheel is flat with the track surface.
- Cleaning: Keep the track and car components clean and free of dust and debris. Use a soft, dry cloth to wipe surfaces.
Image: Detailed maintenance tips for cars and track.
Troubleshooting
If you encounter issues with your slot car set, refer to the following common problems and solutions:
- Car Flies Off Track: This usually occurs when the car speed is too fast, especially on turns or loops. Reduce speed before entering curves and adjust the speed limit pin on the controller if necessary to maintain a uniform speed.
- Car Not Moving or Intermittent Power:
- Check all track connections to ensure they are fully snapped together and flat.
- Verify the power adapter is securely connected to the control box and the control box to the track.
- Ensure the car's conductive brushes are clean, properly angled (approx. 30 degrees), and making good contact with the track's metal strips.
- Check that the guide pin on the car is correctly seated in the track groove.
- Lap Counter Not Registering: Ensure the cars are passing directly over the lap counter sensor and that the control box is properly connected.
Specifications
| Feature | Detail |
|---|---|
| Product Dimensions | 17.32 x 13.19 x 4.72 inches |
| Item Weight | 5.79 pounds |
| Model Number | MR-09L |
| Manufacturer Recommended Age | 8 years and up |
| Track Length | 8.4 meters |
| Layout Size (8.4m track) | 175 x 95 x 32 cm |
| Scale | HO scale 1:64 |
| Power Source | Electric (via supplied adapter) |
Warranty and Support
While specific warranty details are not provided in this manual, AGM MASTECH is committed to customer satisfaction. If you have any questions about the product, require assistance with setup, operation, or encounter any issues, please feel free to contact us. We aim to reply to all inquiries within 24 hours.
For further support, please refer to the contact information provided on the product packaging or the official AGM MASTECH website.
