Drsaec J52 Bluetooth 5.3 Wireless Earbuds Instruction Manual

1. Introduction

Thank you for choosing the Drsaec J52 Bluetooth 5.3 Wireless Earbuds. This manual provides detailed instructions on how to set up, operate, and maintain your earbuds to ensure optimal performance and longevity. Please read this manual carefully before use and retain it for future reference.

Image 1.1: Drsaec J52 Wireless Earbuds in their charging case, displaying the digital power indicator.

2. Package Contents

Please check the package for the following items:

• Drsaec J52 Wireless Earbuds (Left and Right)
• Portable Charging Case
• USB-C Charging Cable
• User Manual

3. Setup

3.1. Initial Charging

Before first use, ensure both the earbuds and the charging case are fully charged.

1. Charge the Charging Case: Connect the provided USB-C cable to the charging port on the case and to a USB power adapter (not included). The LED display on the case will show the charging progress. A full charge takes approximately 1 hour.
2. Charge the Earbuds: Place the earbuds into the charging case. Ensure they are correctly seated; the earbuds will automatically begin charging. The LED display on the case will show individual battery levels for the left and right earbuds. A single charge provides up to 7 hours of playback. The charging case provides an additional 42 hours of battery life.

Important: When using for the first time, please remove the protective film from the charging contacts on the earbuds to allow proper charging.

Image 3.1: The charging case features an LED display showing the battery percentage of the case and individual charge levels for each earbud.

3.2. Pairing with Your Device

The Drsaec J52 earbuds utilize Bluetooth 5.3 for a stable and efficient connection.

Image 3.2: Diagram illustrating the benefits of Bluetooth 5.3, including more stable connection, lower power consumption, longer transmission range, and lower latency.

1. Power On: Open the charging case. The earbuds will automatically power on and enter pairing mode.
2. Activate Bluetooth: On your smartphone or other Bluetooth-enabled device, go to the Bluetooth settings and turn on Bluetooth.
3. Select Device: Look for 'J52' in the list of available devices and select it to connect.
4. Confirmation: Once connected, you will hear an audio prompt, and the earbuds will be ready for use.

The earbuds will automatically reconnect to the last paired device when taken out of the case, provided Bluetooth is enabled on the device.

Image 3.3: A smartphone screen showing the 'J52' earbuds listed under Bluetooth devices, demonstrating the one-step pairing process.

3.3. Wearing the Earbuds

For optimal sound quality and comfort, ensure the earbuds are properly seated in your ears.

• Identify the Left (L) and Right (R) earbuds.
• Gently insert each earbud into your ear canal and rotate slightly until it feels secure and comfortable.

4. Operating Instructions

4.1. Power On/Off

• Power On: Open the charging case, and the earbuds will automatically power on. Alternatively, long-press the touch area on both earbuds for 3 seconds.
• Power Off: Place the earbuds back into the charging case and close the lid. They will automatically power off and begin charging. Alternatively, long-press the touch area on both earbuds for 5 seconds.

4.2. Touch Controls

The Drsaec J52 earbuds feature smart touch controls for easy management of music and calls.

Image 4.1: Detailed diagram of touch control functions for the Drsaec J52 earbuds.

• Play/Pause: Double-tap the touch area on either the Left (L) or Right (R) earbud.
• Volume Up: Single-tap the touch area on the Right (R) earbud.
• Volume Down: Single-tap the touch area on the Left (L) earbud.
• Next Song: Long-tap the touch area on the Right (R) earbud for 2 seconds.
• Previous Song: Long-tap the touch area on the Left (L) earbud for 2 seconds.
• Answer/End Call: Double-tap the touch area on either earbud.
• Reject Call: Long-tap the touch area on either earbud for 2 seconds.
• Activate Voice Assistant (Siri, Google Assistant): Triple-tap the touch area on either earbud.

4.3. Single Earbud Mode

You can use either the left or right earbud independently. Simply take one earbud out of the charging case, and it will automatically connect to your device. The other earbud can remain in the case or be used later.

4.4. Making and Receiving Calls

The earbuds feature ENC (Environmental Noise Cancellation) microphones for clear calls.

Image 4.2: Illustration demonstrating 40dB noise reduction for crystal-clear calls, even in noisy environments.

• Answer/End Call: Double-tap the touch area on either earbud.
• Reject Call: Long-tap the touch area on either earbud for 2 seconds.

5. Maintenance

5.1. Cleaning

• Regularly clean the earbuds and charging case with a soft, dry, lint-free cloth.
• Do not use harsh chemicals, cleaning solvents, or strong detergents.
• Clean the charging contacts on both the earbuds and the case periodically to ensure proper charging.

5.2. Water Resistance (IP-X7)

The Drsaec J52 earbuds are rated IP-X7 waterproof, meaning they can withstand immersion in water up to 1 meter for 30 minutes. This makes them suitable for sports and protection against sweat, splashes, and rain.

Image 5.1: A woman in water wearing the Drsaec J52 earbuds, highlighting their IP-X7 waterproof rating and lightweight design.

Caution:

• Do not intentionally submerge the earbuds for extended periods or beyond the specified depth.
• The charging case is not waterproof.
• Ensure earbuds are completely dry before placing them back into the charging case to prevent damage.

5.3. Storage

• Store the earbuds in their charging case when not in use to protect them and keep them charged.
• Avoid storing in extreme temperatures (hot or cold) or in dusty/humid environments.

6. Troubleshooting

If you encounter any issues with your Drsaec J52 earbuds, please refer to the following common solutions:

• Earbuds not pairing:
  • Ensure both earbuds are charged.
  • Turn off Bluetooth on your device, then turn it back on.
  • Forget 'J52' from your device's Bluetooth list and try pairing again.
  • Place both earbuds back into the charging case, close the lid, wait a few seconds, then open the lid to re-initiate pairing mode.
• Only one earbud working:
  • Ensure both earbuds are charged.
  • Place both earbuds back into the charging case, close the lid, then open it again. This often resets the connection between the two earbuds.
  • Check if the protective film on the charging contacts was removed.
• No sound or low volume:
  • Increase the volume on both your device and the earbuds.
  • Ensure the earbuds are properly connected to your device.
  • Clean any debris from the earbud speaker mesh.
• Charging issues:
  • Ensure the USB-C cable is securely connected to both the case and the power source.
  • Clean the charging contacts on the earbuds and inside the case.
  • Try a different USB-C cable and power adapter.

If the problem persists after trying these steps, please contact customer support.

7. Specifications

Below are the technical specifications for the Drsaec J52 Wireless Earbuds:

Image 7.1: The earbuds are compatible with various devices, including smartphones, tablets, and laptops.

8. Warranty and Support

Drsaec products are designed for reliability and performance. For specific warranty information, please refer to the warranty card included in your product packaging or contact Drsaec customer support directly.

If you have any questions, require technical assistance, or need to report an issue, please contact our customer support team through the retailer's platform or the official Drsaec website. Please have your product model (J52) and purchase details ready when contacting support.
